VE Series Rack
User Manual
Version
V1.0
Revision date March 15, 2019
BOM
31013940
Vertiv provides customers with technical support.
Users may contact the nearest Vertiv local sales
office or service center.
Copyright © 2019 by Vertiv Co., Ltd.
All rights reserved. The contents in this document
are subject to change without notice.
Vertiv Co., Ltd.
Address: Block B2, Nanshan I Park ,No.1001
Xueyuan Road ,Nanshan District, Shenzhen
518055 P.R.China
Homepage: www.Vertiv.com
E-mail: Vertiv.service@vertivco.com
Advertisement
Table of Contents
Related Manuals for Vertiv VE Series
Summary of Contents for Vertiv VE Series
- Page 1 维 谛 技 术 有 限 公 司 为 客 户 提 供 全 方 位 的 技 术 支 Users may contact the nearest Vertiv local sales 持 ， 用 户 可 与 就 近 的 维 谛 技 术 有 限 公 司 办 事 处...
- Page 2 Vertiv Co., Ltd. Notice The purchased products, services, and features are stipulated by the contract made between Vertiv Co., Ltd. and the customer. All or part of the products, services, and features described in this document may not be within the purchasing scope or the usage scope.
- Page 3 Thank you for purchasing products from Vertiv Co., Ltd.! Before operating, please read the safety instructions and precautions provided by Vertiv Co., Ltd. carefully. All the “Notes” in this manual do not represent the precautions to be observed rather are also given as supplementary information. Only qualified trained personnel should be allowed to install before operation.
-
Page 4: Table Of Contents
3.4. Removing and Replacing the Top Cover ......................21 3.5. Adjusting the Bottom Panel (optional) ......................23 3.6. Removing the Front and Rear Door ........................23 3.7. Rack Grounding Points ............................25 3.8. Rack Main Grounding Points ..........................28 Vertiv | VE Series Rack | User Manual... - Page 5 3.11. Baying the VE Rack ............................30 3.12. Installing and Removing the Floating Nut ......................32 3.13. Fixing the Rack on the Floor ..........................33 3.14. Toxic and Harmful Substances or Element Identification Table ................ 34 Vertiv | VE Series Rack | User Manual...
-
Page 6: Chapter 1: Product Overview
Chapter 1: Product Overview VE Series rack (referred to as the rack) is a high-quality rack manufactured by Vertiv Co., Ltd. for the installation and placement of 19-inch rack hardware equipment in accordance with industry standards (EIA-310-E). It also includes servers, voice, data, internet network equipment, UPS and batteries, etc. -
Page 7: Features
• Compatible with top and bottom cabling mode, convenient on-site wiring. • Installation and disassembly are convenient by using built-in side panel. • Supports a variety of rack-based cold aisle solutions, such as SmartAisle. Vertiv | VE Series Rack | User Manual... - Page 8 • The front door can be reversed to fit with left or right opening. • Reliable grounding of all parts of the rack to ensure safe operation. • Meets RoHS environmental protection. Vertiv | VE Series Rack | User Manual...
-
Page 9: Appearance And Components
The appearance and components of the rack are shown in Figure 1-3. • VE Series Rack User Manual (referred to as user manual) includes drawings with SR-V061120 as an example. The appearance and configuration of the rack shall be based on the rack actually received by the customer. - Page 10 Pre-Installation Preparation Front Rear Door PDU/Cable Side Bottom Model Frame Beam Door (mesh) Management Rails Panel Cover Panel (mesh) Bracket SR-V061220SF SR-V061220SA SR-V061222SF SR-V061222SA SR-V081120SF SR-V081120SA SR-V081122SF SR-V081122SA SR-V081220SF SR-V081220SA SR-V081222SF SR-V081222SA Vertiv | VE Series Rack | User Manual...
-
Page 11: Chapter 2: Pre-Installation Preparation
Adjusting and removing casters and feet. Sleeve Wrench Remove hexagonal screws or bolts from casters and pallet fixtures. Gradienter Display its horizontal status when leveling the rack. Allen Wrench Used to adjust the rack feet. Vertiv | VE Series Rack | User Manual... -
Page 12: Threaded Accessories
When selecting road transport, roads without too many bumps are strongly recommended. The entire packaged rack is shown in Figure 2-4, it’s size and weight is shown in Table 2-3. Figure 2-4 Whole Package Rack Vertiv | VE Series Rack | User Manual... - Page 13 When handling, ensure that the maximum tilt angle on both sides of the rack does not exceed 15°, see Figure 2-6. ° < Figure 2-6 Maximum tilt angle on both sides of the rack (front view) Vertiv | VE Series Rack | User Manual...
-
Page 14: Unpacking
2. Slide the rack carefully towards the wooden board from the rear of the pallet through the caster and feet of the rack, then slide slightly to the ground, as shown in Figure 2-8. Vertiv | VE Series Rack | User Manual... - Page 15 Figure 2-10, VE series racks are equipped with four M12 hoisting threaded holes at the top of the rack (hoisting ring needs to be owned by the user) to remove the 2200mm height rack from the pallet using cranes or...
- Page 16 Pre-Installation Preparation Hoisting Hoisting threaded threaded hole 4 hole 1 Hoisting Hoisting threaded threaded hole 3 hole 2 Figure 2-10 Rack Hoisting Hole Pallet Figure 2-11 Removing the Pallet Vertiv | VE Series Rack | User Manual...
- Page 17 • By default the feet adjustment in VE series rack at factory is at the highest position. • Racks of 2200mm height do not contain casters and feet, pay high attention to safety during pallet disassembly.
-
Page 18: Equipment Room Requirements
. However, the rack’s internal bearing equipment is different and the weight-bearing requirements of the equipment room are also different. To estimate the requirements, please consult the nearest Vertiv Co., Ltd. office or service center. Vertiv | VE Series Rack | User Manual... -
Page 19: Chapter 3: Installation Instructions
M5 combination screws for reference), move the right front EIA rail from position A (factory mounting position) to position B (user desired position), use M5 combination screws to lock the EIA rails. Vertiv | VE Series Rack | User Manual... - Page 20 1 2 . 5 m m Figure 3-2 Diagram of Crossbeam Silkscreen 3. Use the same method mentioned in steps 1 and 2 to adjust the remaining two EIA rails. Vertiv | VE Series Rack | User Manual...
-
Page 21: Adjusting Pdu/Cable Management Bracket (Optional)
The steps of removing the side panel are as follows: 1. Use the key to twist the lock core to the open position, as shown in Figure 3-4, and toggle the latch inwards with your finger. Vertiv | VE Series Rack | User Manual... - Page 22 2. Pull the top of the side panel outwards from the rack frame, as shown in Figure 3-5 and lift it up to remove the side panel. Side panel Figure 3-5 Side Panel Disassembly 3. Similarly remove the other side panel. Vertiv | VE Series Rack | User Manual...
- Page 23 3. Use the key to twist the lock core to the closing position and complete the side panel lock. Latch of side panel Figure 3-7 Side Panel Mounting 4. Similarly mount the side panel on the other side. Vertiv | VE Series Rack | User Manual...
-
Page 24: Removing And Replacing The Top Cover
3.4. Removing and Replacing the Top Cover Top Cover Cabling Hole Size Figure 3-8 shows the VE series 600mm and 800mm wide rack top cover cabling hole size (in mm). 1 0 0 1 0 0 Rear of rack Back of rack... - Page 25 Figure 3-10 Disassembly of Top Cover Mounting Top Cover The VE series racks are equipped with tool-free disassembly of the top cover. When mounting the top cover as shown in Figure 3-11, insert the top cover in the frame with slight jerk to the spring-loaded plunger, and pull the top cover downwards to align with the top of the rack.
-
Page 26: Adjusting The Bottom Panel (Optional)
3.5. Adjusting the Bottom Panel (optional) In some VE series rack models, the standard three-section type bottom panel is an optional accessory. The adjustment method of the three-section type bottom panel is as follows: Adjust the area of the air inlet on the bottom of the rack according to the need. Move the three sections of the bottom... - Page 27 Door Closing Method 1. Rotate the handle clockwise to its place and press the handle. 2. Insert the key into the keyhole, rotate the key 180° counterclockwise to close the door lock. Vertiv | VE Series Rack | User Manual...
-
Page 28: Rack Grounding Points
Installation Instructions Intelligent Door Lock Installation (optional) VE series racks are compatible with the intelligent door locks installation (specific type). For this specific installation method, refer to the Intelligent Door Lock User Manual, the schematic diagram after installation is shown in Figure 3-15. - Page 29 • When the rear door is grounded with the frame, the two rear doors to the left and right must b e connected to the frame grounding wire, the grounding position is identical. Vertiv | VE Series Rack | User Manual...
- Page 30 Side panel Side panel Cross beam 比 例 Grounding points Grounding points of side panel of cross beam Cross beam 2 ： 1 Figure 3-19 Rack Side Panel and Beam Grounding Points Vertiv | VE Series Rack | User Manual...
-
Page 31: Rack Main Grounding Points
Figure 3-20 Rack Main Grounding Points • Rack needs to be securely connected and guided by grounding wires, from the main grounding points to the external grounding position, otherwise there may be a risk of electric shock. Vertiv | VE Series Rack | User Manual... -
Page 32: Adjusting The Feet And Leveling The Rack
Adjusting the Feet and Leveling the Rack Adjusting the Feet VE series rack feet adjustment has two ways: Up and Down. Adjusting Mode on Feet 1. Insert the inner hexagonal wrench with a CR-V6 model (user-owned) in the inner hexagon hole of the feet... -
Page 33: Removing The Feet And Casters (Optional)
• Before putting the rack on its side, please remove the equipment installed in the rack. • In VE series rack, only 2000mm height racks contain feet and casters. 1. Place the rack side on the open ground, take care to protect the rack’s exterior surface. - Page 34 2. Use the M5 countersunk head screws to secure the rack to the frame of Rack 2, as shown in Figure 3-24. Front Front Baying kits Rack 2 door A Rack 1 door A amplified B amplified 比 例 Baying kits Figure 3-24 Baying the Rack in the Front Vertiv | VE Series Rack | User Manual...
-
Page 35: Installing And Removing The Floating Nut
There are 30 sets of floating nuts and screws configured with the rack, which are used to install the user equipment. The installation procedures of the floating nuts are as follows: Figure 3-26 Floating Nut Mounting Vertiv | VE Series Rack | User Manual... -
Page 36: Fixing The Rack On The Floor
(optional)”. Lead M12 screws through the M12 installation holes, which will appear after removing the feet, from underside of the rack to fix the rack on the floor. Figure 3-28 Position of installation hole at the bottom of the rack Vertiv | VE Series Rack | User Manual... -
Page 37: Toxic And Harmful Substances Or Element Identification Table
SJ/T-11363-2006. Vertiv Co., Ltd. has been committed to the design and manufacturing of environmentally-friendly products, it will reduce and eventually eliminate the hazardous substances in the products through unremitting efforts in research. However, limited by the current technical level, the following parts still contain hazardous substances due to the lack of reliable substitute or mature solution: The Copper alloy in the cable contains the lead that is smaller than 4%. - Page 38 © 2019 Vertiv Co., Ltd. All rights reserved. Vertiv and the Vertiv logo are trademarks or registered trademarks of Vertiv Co., Ltd. All other names and logos referred to are trade names, trademarks, or registered trademarks of their respective owners. While every precaution has been taken to ensure accuracy and completeness herein.
