Dhollandia DH-AB Series Operation Manual

Dhollandia DH-AB Series Operation Manual

Mobile column lift
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
edition
DH-AB*
OPERATION MANUAL
Manufacturer:
DHOLLANDIA N.V.
Zoomstraat 9
9160 LOKEREN (Belgium)
Tel : +32 (0)9 349 06 92
Fax : +32 (0)9 349 09 77
e-mail : info@dhollandia.be
website : www.dhollandia.com
Read the manual in its entirety before operating the mobile column lift.
Keep this manual with the machine, as reference for the operator and maintenance personnel.
[Type here]
Order ref: MD037.EN Doc: USE_DHAB_CE_EN_2019
Rev: 1 Date: NOV 13, 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DH-AB Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dhollandia DH-AB Series

Summary of Contents for Dhollandia DH-AB Series

  • Page 1 9160 LOKEREN (Belgium) Tel : +32 (0)9 349 06 92 Fax : +32 (0)9 349 09 77 e-mail : info@dhollandia.be website : www.dhollandia.com Read the manual in its entirety before operating the mobile column lift. Keep this manual with the machine, as reference for the operator and maintenance personnel.

  • Page 2: Table Of Contents

    Switching off the mobile column lift ............................. 30 DECALS....................................... 31 10.1 Main decals ..................................31 10.2 Tire adaptor ..................................32 10.3 Lift forks ....................................32 MEANING OF SAFETY AND WARNING SIGNS ........................33 END NOTE ....................................35 ATTACHMENT 1 ....................................36 DHOLLANDIA...

  • Page 3: Understanding Safety And Warning Signs

    Prior to operating the lift, make sure you understand the safety and warning signs used, and read them in conjunction with the instructions in this manual.  If in doubt, DO NOT operate the lift. Contact your national DHOLLANDIA distributor. See page 3 for contact info. All trademarks stated in this manual are registered trademarks of their suppliers. DHOLLANDIA...

  • Page 4: Contact Information And Disclaimers

    NOTICE Please confirm you have reviewed the most up-to-date version of this manual prior to operation of the associated DHOLLANDIA mobile column lift. See below for instructions to download the latest version of the manual.

  • Page 5: General Introduction

    4 INTENDED USE DHOLLANDIA mobile column lifts are designed to lift vehicles and shall be used exclusively to lift vehicles within the limits of the load chart, in compliance with the operation and safety instructions described in this manual. DO NOT use the mobile column lift for other purposes.

  • Page 6: Identification

     Every DHOLLANDIA mobile column lift is identified by and labelled with a unique 8-digit serial number (with or without a space between the first and last 4 digits). Use this number for any inquiry on a particular lift, or when ordering replacement parts.
  • Page 7 Levelling valve: manually operated valve used to level the master and slave columns again if they are out of synchronization, and vehicle would be lifted askew. Work light L+R: light tube foreseeing additional lighting of the work area under the vehicle. DHOLLANDIA...

  • Page 8: Technical Specifications

    10.000 kg or 14.000 kg per pair as per client order. Check the serial number decal or capacity decal of the lift. Maximum lifting height 1500mm Main power source 3x400 volt Main fuse Control voltage 24 volt direct current Field of operation only indoor Operating temperature -15 to +50°C DHOLLANDIA...

  • Page 9: Safety Devices

    SAFETY DEVICES DHOLLANDIA mobile column lifts are equipped with multiple safety devices in order to ensure that vehicles can be lifted with maximum safety for the operator, any potential bystanders and the vehicle itself. The following safety devices are incorporated in the mobile...
  • Page 10 Fuses: the electric system is protected several fuses against short-circuits and amperage peaks. Decals [standard]. The mobile column lifts are supplied with a number of operation decals, load diagrams and safety decals. These decals must be kept clean and legible at all times, and replaced whenever required. DHOLLANDIA...

  • Page 11: Safety Instructions For Using The Mobile Column Lift

    DO NOT USE MOBILE COLUMN LIFT WITHOUT ADEQUATE SAFETY AND OPERATOR TRAINING  DHOLLANDIA mobile column lifts shall be exclusively used to lift vehicles, within the limits of the applicable load chart, in compliance with the operation and safety instructions in this manual.
  • Page 12 Inspect the mobile column lift prior to each use. If any unsafe condition exists or unusual noises or movements are noticed, DO NOT use the mobile column lift and contact an authorized DHOLLANDIA service agent for repair. Please see daily pre- operation inspection procedures under 7.4 on page 16.
  • Page 13  All electronic circuits can be considered live until power has been turned off by means of the main power switch.  When working on electronic parts or electrical circuits, always keep hands, feet and clothing dry. DHOLLANDIA...
  • Page 14 ALWAYS grasp the plug instead of pulling the cable while unplugging the main power cable.  Equipment should be completely cooled down while stored after usage.  Do not operate the mobile column lift in the vicinity of open containers of gasoline and other flammable products to avoid fire. DHOLLANDIA...

  • Page 15: Danger Zones, Risk Of Crush And Shear Injury

     ALWAYS operate the lift from a standing position on the ground, at a safe distance of min. 400 mm behind the master column and the electric control box.  ALWAYS keep hands and limbs clear of the moving parts of the lift. DHOLLANDIA...
  • Page 16  NEVER walk / work / stand under the mobile column lift or the vehicle while it is in motion and as long as the safety locks are not engaged. DHOLLANDIA...

  • Page 17: Recommended Daily Inspection Before Use

    DO NOT cover up any accidents or damage; it can be dangerous to you, your co-workers, and other persons. NOTICE Authorized DHOLLANDIA service agents may be found at www.dhollandia.com or by calling your regional DHOLLANDIA distributor. See page 3 for contact info.

  • Page 18: Importance Of Preventative Maintenance

     If any anomalies or deficiencies arise, put the mobile column lift out of service immediately. Attach a clear and highly visible warning to the control box and lift columns.  Warn your supervisor.  Contact an authorized DHOLLANDIA service agent to repair the mobile column lift prior to any further use. NOISE ...

  • Page 19: Maximum Rated Capacity

     DHOLLANDIA disclaims liability for all personal bodily injury and / or property damage that results from overloading practices.  NEVER use only one lift column of the set. Lifting a vehicle with only one lift column can put the operator and bystanders at great risk of serious bodily injury or death;...

  • Page 20: Operation

    LOWER button: push the button to lower the lift forks and the   vehicle.  SAFETY DOWN button: push the button to lower the lift forks  and the vehicle onto the safety locks on the lift column. DHOLLANDIA...
  • Page 21 / off.  The slave column is equipped with an Emergency stop only. This switch is mounted at the side of the oil leak tank. It is used and operated as item [8] above. DHOLLANDIA...

  • Page 22: Preparations Before Lifting A Vehicle

    If the wheel has a rim, watch out when positioning the forks, to avoid damage to the rims (and to the mobile column lift).  Use the pallet jack mechanism to the lift columns until they fully rest at the ground. DHOLLANDIA...

  • Page 23: Use Of The Tire Adaptors

    Locking latch hooks behind the upright rib on the lift fork. The The locking latch sits in front of the upright rib on the lift fork. tire adaptor is properly secured. The tire adaptor is NOT secured. Do NOT continue this way. DHOLLANDIA...

  • Page 24: Connection Of The Master And Slave Column

    To make the hydraulic connection between the master and slave cylinder, insert the female coupling on the lose hydraulic hose onto the male coupling premounted just below the hydraulic power pack on the master column. Pull the coupling to verify it is properly fastened. DHOLLANDIA...
  • Page 25 The use of worn or damaged wire and hose looms can cause short circuiting of the electrical wiring and failure of the hydraulic hoses. This may put the operator and bystanders at great risk of serious bodily injury or death, as well as cause propery damage to the mobile column lift and the vehicle. DHOLLANDIA...

  • Page 26: Pairing Of Multiple Mobile Column Lifts

    A ring is mounted on the feet of the lift column to guide the wire and hose looms of both mobile column lifts behind the rear axle of the vehicle, grouped into 2 bundles protected by a protective sleeve. DHOLLANDIA...
  • Page 27 The use of worn or damaged wire and hose looms can cause short circuiting of the electrical wiring and failure of the hydraulic hoses. This may put the operator and bystanders at great risk of serious bodily injury or death, as well as cause propery damage to the mobile column lift and the vehicle. DHOLLANDIA...

  • Page 28: Lifting / Lowering The Vehicle - Use Of The Mobile Column Lift

     Failure to abide by these instructions can result in serious bodily injury or death to the operator or bystanders, as well as property damage to the mobile column lift and the vehicle. DHOLLANDIA...

  • Page 29: Levelling The Mobile Column Lifts

    The DH-AB* are designed to LIFT / LOWER principally level through the full stroke of the lift cylinders. If this is not the case, and disparities cannot be solved by means of the instructions in this section, contact DHOLLANDIA for further advice. See contact info on page 3.
  • Page 30 If levelling process is not successful, DO NOT use the mobile column lift, put it out of operation and contact an authorized DHOLLANDIA service agent for repair.  An easy way to check if both columns are level, is to start with the lift forks at approx. 200-300 mm above the ground. Turn the levelling valve counter clockwise.

  • Page 31: Switching Off The Mobile Column Lift

     If levelling process is not successful, DO NOT use the mobile column lift, put it out of operation and contact an authorized DHOLLANDIA service agent for repair. SWITCHING OFF THE MOBILE COLUMN LIFT  Never leave the mobile column lift unattended while a vehicle is still lifted off the ground. If works are not finished at the close of business, lower the vehicle to the ground.

  • Page 32: Decals

     NEVER remove or paint over any decal. Missing, worn or illegible warning decals must be immediately replaced. Get replacement decals from DHOLLANDIA. Contact your regional DHOLLANDIA distributor. See page 3 for contact info.  The operator should comply with all affixed safety and instructions decals. Be aware that the decals merely summarize the main points, and that the operator must know, understand, and comply with the full contents of the operation manual.

  • Page 33: Tire Adaptor

    10.2 TIRE ADAPTOR EXAMPLE EF0604.EN - Adaptor instructions and MAX load – placed on the side of the adaptor 10.3 LIFT FORKS EF0545 – WARNING – placed on each side of the fork. DHOLLANDIA...

  • Page 34: Meaning Of Safety And Warning Signs

    11 MEANING OF SAFETY AND WARNING SIGNS WARNING signs MANDATORY ACTION signs Overview and keep visual control over the Contact your regional DHOLLANDIA distributor. working area of the lift at all times. General warning sign used to alert the user to Consult the DHOLLANDIA website.
  • Page 35 Switch OFF the electrical power to the lift via the main battery disconnect switch and / or cabin switch. This is an operation to be executed manually (as opposed to an electrical function controlled by means of one of the control units). DHOLLANDIA...

  • Page 36: End Note

    Competent and regular preventative maintenance is essential to the operational reliability, and the safety of the operator and bystanders.  All maintenance and repair work should be performed by authorized DHOLLANDIA service agents, and using only authorized OEM DHOLLANDIA replacement parts. ...

  • Page 37: Attachment 1

    In case of “NOT OK”, put the mobile column lift out of service, switch off the main power and pull out the main power plug. Warn your supervisor and contact an authorized DHOLLANDIA service agent for repair. DHOLLANDIA...
