Configure The Serial Interface; Configure The Frame Relay Virtual Interface; Create The Pvc And Assign An Ip Address - ADTRAN NetVanta Series Quick Configuration Manual

The NetVanta Network Interface Modules (NIMs) use a slot/port notation for interface
identification. All non-modular interfaces built into the base unit (e.g., the Ethernet port) are
identified using 0 as the slot number.

Configure the Serial Interface

The following steps demonstrate configuring a serial network interface.
1. At the (config)# prompt, enter interface serial 1/1 to activate the interface configuration
mode for the serial network interface.
2. Enter serial-mode v35 to configure the serial interface for use with the V.35 adapter cable
(P/N 1200873L1).
3. Enter no shutdown to activate the interface to pass data.
Configure the Virtual PPP Interface
Skip to

Configure the Frame Relay Virtual Interface

The following steps outline configuring a Frame Relay virtual interface (labeled 1) using a single
DLCI back to the corporate router (defined as DLCI 16).
1. At the (config)# prompt, enter interface fr 1 to create a Frame Relay virtual interface
labeled 1.
2. If the default setting of ansi was changed, enter frame-relay lmi-type ansi to configure
Frame Relay virtual interface 1 to use ANSI (Annex D) signaling.
3. Enter no shutdown to activate the virtual interface to pass data.
4. Enter exit to return to the Global Configuration mode.
5. The unit has a factory default PPP 1 interface. Enter the command no ppp 1 to remove this
interface.

Create the PVC and Assign an IP Address

1. At the (config)# prompt, enter interface fr 1.16 to create a PVC assigned to Frame Relay
virtual interface 1. This activates the configuration parameters for the PVC. Your prompt
should now display (config-fr 1.16)#.
2. Enter frame-relay interface-dlci 16 to assign DLCI 16 to this PVC.
3. Enter ip address 192.168.72.1 255.255.255.252 to assign an IP address of 192.168.72.1 for
this PVC using a 30-bit subnet mask.
4. Enter no shutdown to activate the virtual interface to pass data.
5. Enter exit to return to the Global Configuration mode.
6. If you are configuring the NetVanta for use in a Frame Relay application and have completed
this step, skip to Create the Cross-Connect on page 4.
The default encapsulation is RFC 1490 or IETF. Make certain the remote unit uses the
same encapsulation for Frame Relay.
64200866L1-42C Technical Support 1-888-4ADTRAN (1-888-423-8726)
on page 4 for PPP configuration.
3
