Blodgett KLT-20G Specifications

KLT-G
Gas Floor Model Tilting Kettle
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Draw Off valves and accessories
2" (50mm) draw off valve
3" (76mm) draw off valve
2" (50mm) dairy valve
3" (76mm) dairy valve
Perforated strainer for draw off
Solid stainless steel disc for draw off valve
Etched markings
Gallons
Litres
Spring assist hinged stainless steel cover
316 stainless steel liner for 60 gallon models
Triple basket assembly
Graduated measuring strip
Strainer hook
Pour strainer
Correctional package
Project
Item No.
Quantity
CONSTRUCTION
OPERATION
STANDARD FEATURES
*
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model KLT-20G - 20 gallon (76 litres) gas floor model tilting kettle
Model KLT-40G - 40 gallon (151 litres) gas floor mode tilting kettle
Model KLT-60G - 60 gallon (227 litres) gas floor mode tilting kettle
304 stainless steel construction
2/3 jacketed with factory sealed distilled water enclosure
Hemispherical design on bottom of kettle for superior heat circulation
Drip proof stainless steel console
Legs fitted with two hole adjustable flanged feet for securing to floor
Self-locking tilt mechanism with trunnions connected to the gear and
control consoles permit the kettle to tilt forward 90° for emptying
Stainless steel control housing
316 stainless steel liner for 20 and 40 gallon models
High efficiency power burner system
Integrally mounted controls
Power switch
Pressure switch
Direct immersion thermostat
Water sight glass
Cook indicator light
Pressure gauge
Low water light
Low water shut off
Pressure relief valve
165-275°F (74-135°C) temperature range
Manual control
Stainless steel faucet bracket
120 VAC, 1 phase, 60 Hz
One year parts and labor warranty*
For all international markets, contact your local distributor.
BLODGETT
