- Page 1 KLT-12G GAS FIRED FLOOR MODEL TILTING KETTLE INSTALLATION – OPERATION – MAINTENANCE BLODGETT OVEN COMPANY IMPORTANT NOTES FOR INSTALLATION AND OPERATION www.blodgett.com 44 Lakeside Avenue, Burlington, Vermont 05401 USA Telephone: (802) 658-6600 Fax: (802) 864-0183 S00073 Rev B (7/13)
-
Page 2: Important Notes For Installation And Operation
It is recommended that this manual be read thoroughly and that all instructions be followed carefully. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. -
Page 3: Table Of Contents
TABLE OF CONTENTS DESCRIPTION PAGE IMPORTANT NOTES FOR INSTALLATION AND OPERATION ......2 SERVICE CONNECTIONS ................. 4 INTRODUCTION ....................5 INSTALLATION INSTRUCTIONS ................ 6 OPERATING INSTRUCTIONS ................9 CLEANING INSTRUCTIONS ................11 PERIODIC MAINTENANCE ................13 SERVICE ......................14 TROUBLESHOOTING ..................17 APPENDIX A Material Safety Data Sheet .............. -
Page 4: Service Connections
2.0 SERVICE CONNECTIONS Unless otherwise specified, Field Wire Electrical Connection to be 120 Volts, 60 Hz. single phase with grounding wire. Unit furnished with 8 ’ cord and 3 prong plug.Total max amps 2.0. GAS CONNECTION: Supply gas through 3/4” pipe. NATURAL 6”-14”... -
Page 5: Introduction
3.0 INTRODUCTION DESCRIPTION Model KLT-12G (12 gallon capacity) gas fired, self-contained, tilting kettle. The kettle has a jacket of double-wall construction forming a sealed reservoir around the lower two-thirds of the kettle. The reservoir is charged with distilled water. The kettle is equipped with a “clean lock” to hold kettle in cooking position or tilted 105 degrees for ease of cleaning. -
Page 6: Installation Instructions
4.0 INSTALLATION INSTRUCTIONS INSTALLATION CODES AND STANDARDS Installation must conform with local codes, or in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or the Natural Gas and Propane Installation Code, CSA B149.1, as applicable. 1. - Page 7 GAS CONNECTION WARNING: Do not connect the appliance to the electrical supply until after the gas connection has been made. CAUTION: The pipe thread compound used when installing pipes must be a type that is resistant to the action of liquified petroleum or propane gases.
- Page 8 INSTALLATION Uncrate carefully. Report any hidden freight damage to the freight company immediately. Ideally an exhaust system should be directly above the appliance to exhaust combustion gases generated by the unit. The appliance is intended for use on noncombustible floors. The minimum clearance from combustible and noncombustible floor construction is 0"...
-
Page 9: Operating Instructions
5.0 OPERATING INSTRUCTIONS FRONT PANEL CONTROLS: Power Switch This switch turns the main power to the unit on and off. It must be turned on to heat the kettle. It should be turned off when the kettle will not be in use for long periods. Thermostat Selects the desired internal kettle operating temperature. - Page 10 TILTING INSTRUCTIONS Your kettle has the standard “Clean Lock” feature and may not be tilted without disengaging the tilt knob located on the console at the top left. This feature locks the kettle in the upright position and also allows the operator to lock the kettle at 105 degrees for ease of cleaning. Follow these steps to tilt kettle: 1.
-
Page 11: Cleaning Instructions
CLEANING INSTRUCTIONS WARNING: Disconnect the power supply to the appliance before cleaning or servicing. WARNING: Never spray water into electric controls or components! CAUTION: The equipment and its parts are hot. Use care when operating, cleaning and servicing. CAUTION: Do not use cleaning agents that are corrosive. Your kettle should be cleaned immediately after each use or when cooking a different product. - Page 12 WHAT TO DO IF SURFACE RUST APPEARS Metal utensils should never be used as they will scratch the surface of the equipment and rust may begin to form. To remove surface accumulation of rust from the inadvertent use of such utensils, the following procedure may be used.
-
Page 13: Periodic Maintenance
WHAT TO DO IF SURFACE RUST APPEARS (Continued) TO REMOVE HEAT TINT: Darkened areas sometimes appear on stainless steel surfaces where the area has been subjected to excessive heat. These darkened areas are caused by thickening of the protective surface of the stainless steel and is not harmful. Heat tint can normally be removed by the foregoing, but tint which does not respond to this procedure calls for a vigorous scouring in the direction of the polish lines using SCOTCH-BRITE™... -
Page 14: Service
8.0 SERVICE GENERAL NOTICE: Contact the factory, the factory representative or local service company to perform maintenance and repairs. In order to avoid problems, check that the unit has been connected to the gas supply type and voltage for which it was supplied. This can be done by examining the rating plate that lists the gas type and voltage for which the unit was manufactured. - Page 15 SERVICE TECHNICIAN: Bypass the thermostat by removing the wire on terminal 8 and install on piggy back on terminal 10. Ignition and temperature light will come on. Turn on unit and allow it to reach approximately 35 psi. Rotate knob on pressure switch clockwise to increase, counterclockwise to decrease.
- Page 16 ADDING WATER When the “Low Water” light is on, additional water is required and the following steps must be followed: Unit should be completely cold and off. Lift handle of pressure relief valve to release the remaining vacuum in the kettle (relief valve is at left rear of kettle).
-
Page 17: Troubleshooting
9.0 TROUBLESHOOTING Unit does not come on: Power switch and/or thermostat is “OFF”. Unit is not plugged in. Main power supply is off. Tilt micro switch out of alignment or faulty. Unit is on electrically but does not heat: Gas supply to the unit is “OFF”. The manual shut-off valve is “OFF”. -
Page 18: Appendix A Material Safety Data Sheet
APPENDIX ‘A’ MATERIAL SAFETY DATA SHEET PREPARATION INFORMATION: Prepared for use in Canada by: E H & S Product Regulatory Management Department DOW CHEMICAL CANADA INC. P.O. Box 1012 Sarnia, Ontario, N7T 7K7 (800) 331-6451 1. CHEMICAL PRODUCT AND COMPANY IDENTIFICATION IN CASE OF EMERGENCY: Fort Saskatchewan, Alberta: (780) 998-8282 Sarnia, Ontario: (519) 339-3711... - Page 19 S HAZARDS IDENTIFICATION EMERGENCY OVERVIEW Ε Ε Clear yellow liquid. Odourless. Avoid temperatures above 450 F, 232 POTENTIAL HEALTH EFFECTS (See Section 11 for toxicological data.) EYE: May cause slight transient (temporary) eye irritation. Corneal injury is unlikely. Mists may cause eye irritation. SKIN CONTACT: Prolonged contact is essentially nonirritating to skin.
- Page 20 4. FIRST AID EYES: Flush eyes with plenty of water. SKIN: Wash off in flowing water or shower. INGESTION: No adverse effects anticipated by this route of exposure incidental to proper industrial handling. INHALATION: Remove to fresh air if effects occur. Consult a physician. NOTE TO PHYSICIAN: No specific antidote.
- Page 21 possibly resulting in spontaneous combustion. Container may rupture from gas generation in a fire situation. EXTINGUISHING MEDIA: Water fog or fine spray, carbon dioxide, dry chemical, foam. Alcohol resistant foams (ATC type) are preferred if available. General purpose synthetic foams (including AFFF) or protein foams may function, but much less effectively.
- Page 22 S EXPOSURE CONTROLS/PERSONAL PROTECTION ENGINEERING CONTROLS: Provide general and/or local exhaust ventilation to control airborne levels below the exposure guidelines. PERSONAL PROTECTIVE EQUIPMENT EYE/FACE PROTECTION: Use safety glasses. Safety glasses should be sufficient for most operations; however, for misty operations wear chemical goggles. SKIN PROTECTION: Use gloves impervious to this material.
- Page 23 contact with strong acids HAZARDOUS DECOMPOSITION PRODUCTS: Hazardous decomposition products depend upon temperature, air supply and the presence of other materials. HAZARDOUS POLYMERIZATION: Will not occur. 11. TOXICOLOGICAL INFORMATION (See Section 3 for Potential Health Effects. For detailed toxicological data, write or call the address or non-emergency number shown in Section 1).
- Page 24 OF WATER. All disposal methods must be in compliance with all Federal, State/Provincial and local laws and regulations. Regulations may vary in different locations. Waste characterizations and compliance with applicable laws are the responsibility solely of the waste generator. THE DOW CHEMICAL COMPANY HAS NO CONTROL OVER THE MANAGEMENT PRACTICES OR MANUFACTURING PROCESSES OF PARTIES HANDLING OR USING THIS MATERIAL.
- Page 25 U.S. REGULATIONS SARA 313 INFORMATION: To the best of our knowledge, this product contains no chemical subject to SARA Title III Section 313 supplier notification requirements. SARA HAZARD CATEGORY: This product has been reviewed according to the EPA “Hazard Categories” promulgated under Sections 311 and 312 of the Superfund Amendment and Reauthorization Act of 1986 (SARA Title III) and is considered, under applicable definitions, to meet the following categories: Not to have met any hazard category.
- Page 26 CANADIAN REGULATIONS WHMIS INFORMATION: The Canadian Workplace Hazardous Materials Information System (WHMIS) Classification for this product is: This product is not a “Controlled Product” under WHMIS. CANADIAN ENVIRONMENTAL PROTECTION ACT (CEPA) This product contains one or more substances which are not listed on the Canadian Domestic Substances List (DSL).
