Summary of Contents for Blodgett KLT-100E
- Page 1 KLT-E Series ELECTRIC TRI-LEG TILTING KETTLE INSTALLATION – OPERATION – MAINTENANCE BLODGETT OVEN COMPANY www.blodgett.com 44 Lakeside Avenue, Burlington, Vermont 05401 USA Telephone (800) 331-5842, (802) 860-3700 Fax: (802) 864-0183 S00051 Rev B (12/05)
-
Page 2: Important Notes For Installation And Operation
IMPORTANT NOTES FOR INSTALLATION AND OPERATION It is recommended that this manual be read thoroughly and that all instructions be followed carefully. This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. -
Page 3: Table Of Contents
TABLE OF CONTENTS DESCRIPTION Important Notes for Installation and Operation 1.0 Service Connections 2.0 Installation Instructions 3.0 Introduction 4.0 Operation Instructions 5.0 Cleaning Instructions 6.0 General Maintenance 7.0 Troubleshooting Appendix A, Material Safety Data Sheet PAGE... -
Page 4: Service Connections
ELECTRICAL CONNECTION TO BE AS SPECIFIED ON DATA PLATE Available kW MODEL STD. OPT. PHASE KLT-20E KLT-30E KLT-40E 24, 33 KLT-60E 24, 33 KLT-80E KLT-100E MODEL CAPACITY UNITS 20 U.S. gal. inches KLT-20E 76 litres 30 U.S. gal. inches KLT-30E 114 litres 40 U.S. gal. -
Page 5: Installation Instructions
INSTALLATION AND SERVICE CONNECTIONS 2.0 INSTALLATION INSTRUCTIONS UNPACKING Immediately after unpacking, check for possible shipping damage. If the kettle is found to be damaged, save the packaging material and contact the carrier within 15 days of delivery. Before installing, verify that the electrical service agrees with the specifications on the rating plate located on the right side of the tilt console. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS A Control Box with power supply equivalent to electrical rating of the kettle should be located conveniently nearby. 1. Remove the wiring compartment cover and make electrical connections per wiring diagram located inside the control housing cover panel. A waterproof electrical connection from power supply to rear of control housing must be provided. -
Page 7: Introduction
The heating elements are thermostatically controlled to provide precise temperatures throughout the range from slow simmer to rolling boil. All tilting kettles are intended to be permanently floor mounted on legs with adjustable flanged feet. A sealed stainless steel tilt mechanism permits the kettle to tilt forward a full 90º for complete emptying. -
Page 8: Functioning Mode
FUNCTIONING MODE All electrically powered self steam generating kettles consist of a jacket containing a permanent solution of water and antifreeze sufficient to completely immerse and protect replaceable electric heating elements. To minimize tampering, the Safety Valve is plumbed toward the rear of the kettle jacket. -
Page 9: Operation Instructions
4.0 OPERATION INSTRUCTIONS WARNING: The kettle and its parts are hot. Use care when operating, cleaning and servicing the kettle. 1. Ensure that the external electrical service to kettle is on. 2. Check pressure gauge for correct cold kettle reading. Reading should be in the green area of the gauge indicating 25 - 30 In. - Page 10 When cooking is finished set thermostat knob and power switch to OFF position. Pour finished product from kettle using tilt handle. Be careful to avoid splashing. Add water to kettle for cleaning purposes. Wash kettle thoroughly. See CLEANING procedure, next section.
-
Page 11: Cleaning Instructions
5.0 CLEANING INSTRUCTIONS CAUTION: Do not use cleaning agents that are corrosive. WARNING: Disconnect the power supply to the appliance before cleaning or servicing. WARNING: Never spray water into electric controls or components! CAUTION: The equipment and its parts are hot. Use care when operating, cleaning and servicing. -
Page 12: Draw-Off Valve Cleaning
DRAW-OFF VALVE CLEANING 1. If equipped with a tangent draw-off valve, turn the large hex nut on the draw-off valve counterclockwise until it is completely disengaged from the threads. Grasp the valve knob and slowly pull out the valve stem. Wash the valve stem, disk and handle. Insert a nylon brush, wet with detergent and water, into the valve body and tangent draw-off tube. -
Page 13: Stainless Steel
1. Use undiluted white vinegar with a non-abrasive scouring pad (plastic) or cloth on the affected area to remove the rust stain. The appliance should not be heated and remain at room temperature during the entire cleaning process. 2. If the stain resists removal, additional exposure time with vinegar may be required, to a maximum of one hour. -
Page 14: General Maintenance
6.0 GENERAL MAINTENANCE No general maintenance is required other than adhering to the Cleaning Procedure instructions. WARNING: Contact the factory, the factory representative or local service company to perform maintenance and repairs. -
Page 15: Troubleshooting
7.0 TROUBLESHOOTING 7.1 LOW WATER LEVEL Proper water level must be maintained within the jacket for the kettle to operate. Depletion of water may occur from excessive opening of or leakage through the safety relief valve. If water is below required operating level, either initially at start-up or during use, the kettle will automatically shut off and the LOW WATER signal light will come on. - Page 16 7.0 TROUBLESHOOTING (Continued) 7.2 EXTREMELY SLOW COOKING TIME 1. If the cooking time is abnormally slow, then the difficulty may be due to air being present in the kettle jacket. To remove air, follow AIR VENTING INSTRUCTIONS. 2. If the kettle will not reach and maintain Pressure Gauge zone in the green area on the gauge when cold, a slow leak may have developed in the jacket.
- Page 17 7.5 AIR VENTING INSTRUCTIONS Check vacuum/pressure gauge when the kettle is cold. Gauge should be in the green vacuum zone, indicating a vacuum between 25-30 In. Hg (630 - 730 mm Hg). If not, air must be vented (removed) for proper heating. Use the following procedures to vent air. 1.
-
Page 18: Appendix A, Material Safety Data Sheet
APPENDIX ‘A’ MATERIAL SAFETY DATA SHEET PREPARATION INFORMATION: Prepared for use in Canada by: 1. CHEMICAL PRODUCT AND COMPANY IDENTIFICATION IN CASE OF EMERGENCY: Product:: DOWFROST* HD HEAT TRANSFER FLUID, DYED Product Code: 04632 Effective Date: 2/20/01 DOW CHEMICAL CANADA INC. P.O. - Page 19 MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Product Code: 04632 Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 2. HAZARDS IDENTIFICATION EMERGENCY OVERVIEW Clear yellow liquid. Odourless. Avoid temperatures above 450EF, 232EC. POTENTIAL HEALTH EFFECTS (See Section 11 for toxicological data.) EYE: May cause slight transient (temporary) eye irritation.
-
Page 20: First Aid
MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 4. FIRST AID EYES: Flush eyes with plenty of water. SKIN: Wash off in flowing water or shower. INGESTION: No adverse effects anticipated by this route of exposure incidental to proper industrial handling. - Page 21 MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Product Code: 04632 Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 HAZARDOUS COMBUSTION PRODUCTS: During a fire, smoke may contain the original material in addition to unidentified toxic and/or irritating compounds. Hazardous combustion products may include and are not limited to carbon monoxide and carbon dioxide.
-
Page 22: Handling And Storage
MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Product Code: 04632 Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 6. ACCIDENTAL RELEASE MEASURES (See Section 15 for Regulatory Information) PROTECT PEOPLE: Use appropriate safety equipment. For additional information, refer to Section 8, Exposure Controls/ Personal Protection. -
Page 23: Toxicological Information
MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 EXPOSURE GUIDELINES: Propylene glycol: AIHA WEEL is 50 ppm total, 10 mg/m3 aerosol only. 9. PHYSICAL AND CHEMICAL PROPERTIES APPEARANCE/PHYSICAL STATE: ODOUR: VAPOUR PRESSURE: VAPOUR DENSITY:... -
Page 24: Ecological Information
MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 SKIN: The LD50 for skin absorption in rabbits is >10,000 mg/kg. INGESTION: The oral LD50 for rats is 20,000 - 34,000 mg/kg. MUTAGENICITY: In vitro mutagenicity studies were negative. -
Page 25: Transport Information
MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 FOR UNUSED & UNCONTAMINATED PRODUCT, the preferred options include sending to a licensed, permitted: recycler, reclaimer, incinerator or other thermal destruction device. As a service to its customers, Dow can provide names of information resources to help identify waste management companies and other facilities which recycle, reprocess or manage chemicals or plastics, and that manage used drums. - Page 26 MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 U.S. REGULATIONS SARA 313 INFORMATION: To the best of our knowledge, this product contains no chemical subject to SARA Title III Section 313 supplier notification requirements. SARA HAZARD CATEGORY: This product has been reviewed according to the EPA “Hazard Categories”...
-
Page 27: Canadian Regulations
MATERIAL SAFETY DATA SHEET Product: DOWFROST* HD HEAT TRANSFER FLUID, DYED Product Code: 04632 Effective Date: 02/20/01, Date Printed: 07/10/02, MSD: 002239 CANADIAN REGULATIONS WHMIS INFORMATION: The Canadian Workplace Hazardous Materials Information System (WHMIS) Classification for this product is: This product is not a “Controlled Product” under WHMIS. CANADIAN ENVIRONMENTAL PROTECTION ACT (CEPA) This product contains one or more substances which are not listed on the Canadian Domestic Substances List (DSL).
