Blodgett KCH-30DS Specifications

KCH-DS
Direct Steam Modular Cabinet Base Kettle
with Heavy Duty Hydraulic Tilt
Shown with optional faucet
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Etched markings
Gallons
Litres
Strainers
Solid
Perforated
Strainer hook
316 stainless steel liner for 60 gallon
50 PSI (345 kPa) high pressure operation for higher
cooking temperature
Graduated measuring strip
220 volt power supply
Project
Item No.
Quantity
CONSTRUCTION
STANDARD FEATURES
*
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model KCH-30DS - 30 gallon (114 litres) direct steam cabinet base kettle
with hydraulic tilt
Model KCH-40DS - 40 gallon (151 litres) direct steam cabinet base kettle
with hydraulic tilt
Model KCH-60DS - 60 gallon (227 litres) direct steam cabinet base kettle
with hydraulic tilt
Stainless steel kettle mounted in enclosed cabinet base
2/3 jacketed
Hemispherical design on bottom of kettle for superior heat circulation
316 stainless steel interior cooking surface for added corrosion resist-
ance for 30 and 40 gallon
1/2 HP hydraulic tilt system for complete emptying of kettle. Tilting may
be stopped at any time without the kettle tilting back.
Stainless steel counter top
Steam control valve mounted in counter top
Polished stainless steel doors with magnetic latches
2" (50mm) sanitary draw off valve
Deck mounted hot and cold water fill faucet
Steam trap assembly
Removable swing drain and strainer
One piece stainless steel spring assist cover
6" stainless steel legs with hold down feet at rear
Removable pan support
120VAC, single phase, 60 hz
One year parts and labor warranty*
For all international markets, contact your local distributor.
BLODGETT
