Plug and fitting sizes and
torques
30
Series 45 J Frame Open Circuit Axial Piston Pumps
If any plugs or fittings are removed from the unit during service, install and torque as indicated
here. This drawing is a composite. Your configuration may differ but here is the appropriate
wrench size and torque:
Plug locations, sizes, and torques
J041
1
/ inch
4
27 - 47 N•m
[20 - 35 lbf•ft]
J041A
K070A
520L0607 • Rev AI • Sep 2013
K040
3
/ inch
8
55 - 135 N•m
[40 - 100 lbf•ft]
K040A
K070
3
/ inch
8
55 - 135 N•m
[40 - 100 lbf•ft]
E101 257
