Blodgett BLG-30G Specifications

BLG-G
Gas Floor Model Braising Pan
with Manual Gear Box Tilt
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Enclosed support for faucet assemblies
Etched markings
Gallons
Litres
Draw off valves
2" (50mm) draw off valve
3" (76mm) draw off valve
220 VAC, 1 phase, 60 Hz
Pan carrier (40 gal. only)
Steam pan insert
Correctional package
Project
Item No.
Quantity
CONSTRUCTION
OPERATION
STANDARD FEATURES
*
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model BLG-30G (30 gallon gas braising pan with manual gear box tilt)
Model BLG-40G (40 gallon gas braising pan with manual gear box tilt)
#4 finish 10 gauge stainless steel pan with polished interior
One piece coved corner stainless steel pan with angled front for easy
pour
Narrow footprint
5/8" thick stainless steel clad plate
Permanent lubricated, self-contained gear box tilt mechanism
Welded stainless steel tubular legs with bullet feet on front legs and
flanged feet on back legs, all adjustable for leveling
Integrally mounted controls
Ignition indicator light
Thermostat with integral power switch
Thermostat indicator light
High temperature cut-off
100-450°F (38-232°C) temperature range
Spring assist hinged stainless steel cover with handle
No-drip condensate guide
Removable pour strainer
Manual tilt action
Solid state temperature control
3 trial, direct spark ignition
Standard voltage options
120 VAC, 1 phase, 60 hz
One year parts and labor warranty*
For all international markets, contact your local distributor.
BLODGETT
