Blodgett BLP-30G Specifications

BLP-G
Gas Floor Model Braising Pan
with Power Tilt
OPTIONS AND ACCESSORIES
(AT ADDITIONAL CHARGE)
Faucets
Single pantry faucet with swing spout
Double pantry faucet with swing spout
Etched markings
Gallons
Litres
220 VAC, 1 phase, 60 Hz
Steam pan insert
Pan carrier
Correctional package
Project
Item No.
Quantity
CONSTRUCTION
OPERATION
STANDARD FEATURES
*
44 Lakeside Avenue, Burlington, VT 05401
Toll Free: (800) 331-5842 • Phone: (802) 860-3700 • Fax: (802) 864-0183
Model BLP-30G (30 gallon gas braising pan with power tilt)
Model BLP-40G (40 gallon gas braising pan with power tilt)
#4 Satin finish 10 gauge stainless steel pan with polished interior, front
hinged for easy tilting
Coved corners
5/8" thick stainless steel clad plate
Welded stainless steel pipe frame with bullet feet on front legs and
flanged adjustable feet on back legs
Front control console
Integrally mounted controls
Electronic ignition
Power switch
Thermostat
Cook indicator light
High temperature cut-off
Tilt switch
100-450°F (38-232°C) temperature range
Gas supply to burner shuts off automatically when pan is tilted
Electric motor driven screw jack for smooth and precise tilting
Spring assist hinged stainless steel cover with handle
Condensate guide
Removable pour strainer
Manual control
115VAC, 1 phase, 60 Hz
One year parts and labor warranty*
For all international markets, contact your local distributor.
BLODGETT
