Summary of Contents for Viotek GFI27QXA

  • Page 1 GFI27QXA GAMING MONITOR USER MANUAL In order to continue serving our customers and providing the best products, our product information including our user manuals may receive updates from time to time. Please check our website for the latest user manuals and product materials.
  • Page 3: Table Of Contents

    Table of Contents Section 1: Safety Precautions..............4 Section 2: Box Contents .................5 Section 3: Product Overview ..............6 3.1 – Monitor Buttons .................6 3.2 – Monitor Ports ................6 Section 4: Stand Installation ..............7 Section 5: Shading Plate Installation ............8 Section 6: Mount Installation ..............9 Section 7: Basic Operation ..............10 Section 8: Indicator Light ...............10 Section 9: OSD ..................11...
  • Page 4: Section 1: Safety Precautions

    VIOTEK shall not be held responsible for injury or damage of products or persons ®...
  • Page 5: Section 2: Box Contents

    Section 2: Box Contents Left Side Shading Monitor x 1 Stand Stem x 1 Stand Base x 1 Plate x 1 Top Left Shading Right Side Shading Top Right Shading Top Middle Shading Plate x 1 Plate x 1 Plate x 1 Plate x 1 NO.
  • Page 6: Section 3: Product Overview

    Section 3: Product Overview 3.1 – Monitor Buttons M Menu Button: Press to display the OSD menu or enter sub-menus. Up Button: Press to move up in the menus. Down Button: Press to move down in the menus. E Exit Button: Press to exit. Power Button: Press to turn the monitor on/off.
  • Page 7: Section 4: Stand Installation

    Section 4: Stand Installation Keep the foam underneath the monitor before attaching the stand. 1. Open the package and take out the monitor with foam still attached. Gently place it on a desktop or table. 2. Take out the stem and base. Insert the stem into the base then use the included screwdriver and two NO.1 screws to fasten base to the stem.
  • Page 8: Section 5: Shading Plate Installation

    Section 5: Shading Plate Installation 1. With the stand fully assembled, place the monitor on a flat, level desktop or table. Then take out the shading plates to get ready for installing. Right Side Shading Left Side Shading Plate x 1 Plate x 1 Top Right Shading Top Middle Shading...
  • Page 9: Section 6: Mount Installation

    Section 6: Mount Installation 1. Open the package and take out the product with foam still attached. Gently place it on a desktop or table. Remove the extra parts and the foam covering the monitor. If the monitor is already attached to the stand, remove the stand. 2.
  • Page 10: Section 7: Basic Operation

    Section 7: Basic Operation 1. Insert one end of the DisplayPort (DP) cable into your PC’s graphics card. Two DP cables are included for your convenience. An HDMI cable (not included) may also be used. 2. Connect the other end of the cable to the corresponding connector on your monitor.
  • Page 11: Section 9: Osd

    Section 9: OSD The On-Screen Display (OSD) Menu may be used to adjust your monitor’s settings and appears on screen after turning on the monitor and pressing the M button. When using the monitor for the first time, settings will automatically adjust to optimal settings according to your computer’s configuration.
  • Page 12: Osd Menu Functions

    9.1 – OSD Menu Functions Main Menu Sub-Menu Options Description Auto Source NONE Auto switch to HDMI or DP signal HDMI 1 NONE Switch to HDMI signal input Input HDMI 2 Source DP 1 NONE Switch to DP signal input Brightness 0-100 Adjust display brightness...
  • Page 13 Main Menu Sub-Menu Options Description Off, PIP Mode, PBP Select PIP/PBP modes according to the Multi-Window 2Win, PBP 4Win number of input signals etc. DP-1, DP-2, HDMI- Select according to input signal for PIP/ Sub Win2 Input 1, HDMI-2 PBP mode Multi- DP-1, DP-2, HDMI- Select according to input signal for PIP/...
  • Page 14: Section 10: Rgb, Led Effects And Gameplus

    Section 10: RGB, LED Effects and Gameplus • Press any one of the buttons (M, , , E, ) to activate the navigation window. • Press ( ) to switch Gameplus modes. According to the needs of your game, choose the corresponding game icon. These game icons are primarily designed to optimize your aim during FPS games, though they can be used for other scenarios.
  • Page 15: Section 11: Troubleshooting

    Section 11: Troubleshooting The screen is blank • Press the power button to turn the monitor on. • Confirm the brightness and contrast settings are set normally. • Check if the indicator light is flashing. If so, there is no signal from your video source. •...
  • Page 16: Section 12: Specifications

    Section 12: Specifications Item Detail Model Number GFI27QXA Screen Size 27” Curvature None Panel Type Viewing Angle H178° / V178° Aspect Ratio 16:9 Resolution 3840 x 2160p Backlight E-LED LED Indicator Power on: White (solid); Power saving: White (flashing) Typical Brightness 350 cd/m Default Color Temp.
  • Page 17: Section 13: Three-Year Limited Hardware Warranty

    Warranty services are provided by Viotek Warranty Pro (“WP”). If a hardware defect arises and a valid claim is received within the Warranty Period, at its option and to the extent permitted by law, WP will: (1) repair the hardware defect by using new or refurbished parts that are equivalent to new in performance and reliability;...
  • Page 18 DECLARATION OF CONFORMITY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. FCC RELATED INFORMATION: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
