Desono™
MASK4C(T) / MASK6C(T) Loudspeaker
Installation & Operation Guide
PRODUCT DESCRIPTION
The Desono MASK4C(T) / MASK6C(T) surface mount
loudspeakers deliver crystal clear sound for all your public
address and background music needs. Available in black or
white, the coated paper cone woofer and silk dome tweeter
result in a high SPL and extremely low distortion, ensuring
unprecedented clarity over the entire frequency spectrum.
The ClickMount bracket enables all audio connections to
be made at the bracket. Pre-defined horizontal and vertical
notches in the bracket make loudspeaker adjustments fast
and repeatable. To complete the installation, simply 'click'
the loudspeaker in place.
The loudspeakers are designed for outdoor applications
such as patios or concourses, and are an ideal choice for
both indoor and outdoor distributed audio applications that
demand superior speech intelligibility and full range music
reproduction. The loudspeakers are of rigid construction to
withstand extreme conditions.
A: 9300 S.W. Gemini Drive Beaverton, OR 97008 USA
FEATURES
• Weather-resistant (aluminium grille)
• Wall and ceiling mountable with ClickMount click & connect
• Connectors with passthrough and 0.14 – 4 mm² solid or
stranded wire capacity
• Glass fibre reinforced ClickMount bracket with integrated
spirit level
• 3 stage overload protection
• Asymmetric tweeter horn design
• Coated 4.25"LF driver for MASK4C(T) and 6.5" LF driver for
MASK6C(T)
• Horn loaded silk dome tweeter
• Rotatable logo
• 70W power handling for MASK4C(T) and 200W for
MASK6C(T)
• Low Impedance (8 and 16 ohm) and 70V/100V operation (on
T versions)
• Integrated safety nut for SAFCAB (supplied)
• The installer can mount the ClickMount and connect the
speaker cables while the speakers are still safely packed
inside the packing carton.
• Incorporated 5° downward listening angle
