OPERATION AND MAINTENANCE MANUAL
BSD-3000L
BSD-3200L
BSD-3300L
BSD-6200L
BSD-6600L
BSD-6600LF
BSD-8000L
BSD-8200L
BSD-8800L
BSD-8800LF
LOW VOLTAGE
METAL ASSEMBLY SCREW DRIVER
WWW.KILEWS.COM.CN
KILEWS ELECTRIC TOOLS（SHANGHAI）CO., LTD.
No.367, 2nd Xinjian Road, Xuhang Town, Jiading District, Shanghai 201808 China
Tel: 86-21-59556022
Fax: 86-21-59553779
OSH-D07E
Advertisement
Related Manuals for Kilews BSD-3000L
Summary of Contents for Kilews BSD-3000L
- Page 1 OPERATION AND MAINTENANCE MANUAL BSD-3000L BSD-3200L BSD-3300L BSD-6200L BSD-6600L BSD-6600LF BSD-8000L BSD-8200L BSD-8800L BSD-8800LF LOW VOLTAGE METAL ASSEMBLY SCREW DRIVER WWW.KILEWS.COM.CN KILEWS ELECTRIC TOOLS（SHANGHAI）CO., LTD. No.367, 2nd Xinjian Road, Xuhang Town, Jiading District, Shanghai 201808 China Tel: 86-21-59556022 Fax: 86-21-59553779 OSH-D07E...
- Page 2 BSD-3000 Series NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING Important safety information enclosed.
-
Page 3: General Safety Rules
All manuals and user guides at all-guides.com BSD-3000 Series 1. General Safety Rules Read all instructions Failure to follow all instructions listed below may result WARNING! in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 All manuals and user guides at all-guides.com BSD-3000 Series g) If devices are provided for the connection of dust extraction and collection facilitys, ensure these are connected and properly used. Use of these devices can reduce dust related hazards. 4) Power tool Use and Care a) Do not force the power tool.
- Page 5 All manuals and user guides at all-guides.com BSD-3000 Series 2. Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in the “ OFF “ position and tool is unplugged. 2) Do not allow chemicals such as acetone, benzene, thinner, trichloroethylene ketone, or other similar chemicals to come in contact with the screwdriver housing as damage will result.
-
Page 6: Specifications
All manuals and user guides at all-guides.com BSD-3000 Series 3. Specifications REQUIREMENTS This tool requires an power controller BSP-32HL-40W( input：220VAC 50/60HZ output：24/32VDC) BSP-32VR-40W(input：220VAC 50/60HZ output：24-32VDC) BSP-32HL-60W(input：100-240VAC 50/60HZ output：24/32VDC) BSP-32VR-60W(input：100-240VAC 50/60HZ output：24-32VDC) DATA 1: BSD-3000L BSD-3200L BSD-3300L MODEL Input voltage(DC) 32VDC Rated input Kgf.cm 0.3-3.5 0.6-7... - Page 7 All manuals and user guides at all-guides.com BSD-3000 Series DATA2: BSD- BSD- BSD- BSD- BSD- BSD- BSD- MODEL 6200L 6600L 6600LF 8000L 8200L 8800L 8800LF Input voltage(DC) 32VDC Rated input Kgf.cm 1 ~12 3~16 5~18 7~24 8~30 2~10 Bit torque Lbf.in 0.89~10.44 2.57~13.89...
-
Page 8: Description Of Operation
All manuals and user guides at all-guides.com BSD-3000 Series 4. Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. Thus, the bit can be freely attached and detached (single finger notion type) select such a bit whose shank is equal to the size shown below. - Page 9 BIT 2 Pce. BSD-8800LF with BIT 1# &2 # 1 Pce. Each 2.Carbon Brush :2 Pcs, Those 2 Pcs brush are spare parts. 3.Suspension rack and Torque fixing ring acceptable for use with the tool are available from KILEWS catalogue.
-
Page 10: Do Not Attempt To Repair This Electric Screw Driver
6. Do not remove any labels. Replace any damaged label. CAUTION 1. The use of other than genuine KILEWS replacement parts may Result in decreased tool performance and increased maintenance, and may invalidate all warranties. 2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. - Page 11 All manuals and user guides at all-guides.com...
- Page 12 All manuals and user guides at all-guides.com BSD-3000L 3200L 3300L NO PARTS NO PARTS NAME-E Q'ty NO PARTS NO PARTS NAME-E Q'ty CORD ASSEMBLY 2M IDLE GEAR FOR "3300L" 1 AA50001N GH28191-1 2 PZ50160 CONNECTOR ASS'Y 32 GG28211 GEAR SEAT"3000L&3200L"...
- Page 13 All manuals and user guides at all-guides.com...
- Page 14 All manuals and user guides at all-guides.com 6200L 6600L NO PARTS NO PARTS NAME-E Q'ty NO PARTS NO PARTS NAME-E Q'ty AA50001N CORD ASSEMBLY 2M GH20241 IDLE GEAR AA50001-1N CORD ASSEMBLY 3M GG20271 GEAR SEAT PZ50160 CONNECTOR G20101 CENTRAL GEAR CJ20011 SUSPENSION RING GA30311-7...
- Page 15 All manuals and user guides at all-guides.com...
- Page 16 All manuals and user guides at all-guides.com 6600LF NO PARTS NO PARTS NAME-E Q'ty NO PARTS NO PARTS NAME-E Q'ty AA50001N CORD ASSEMBLY 2M GA30311-7 GEAR CASE AA50001-1N CORD ASSEMBLY 3M GN30321 MAIN BEARING PZ50160 CONNECTOR GC30341 CJ20011 SUSPENSION RING GP30351 STEEL BALLS GU30361...
- Page 17 All manuals and user guides at all-guides.com...
- Page 18 All manuals and user guides at all-guides.com 8000L 8200L 8800L PARTS NO PARTS NAME-E Q'ty NO PARTS NO PARTS NAME-E Q'ty AA50001N CORD ASSEMBLY 2M MI31221 PILOT ROD PZ50160 CONNECTOR GK21181 "C"RING CJ20011 SUSPENSION RING GI21191 IRON WASHER CC21011-3 GH20241 IDLE GEAR FOR "8000L"...
- Page 19 All manuals and user guides at all-guides.com...
- Page 20 All manuals and user guides at all-guides.com 8800LF PARTS NO PARTS NAME-E Q'ty PARTS NO PARTS NAME-E Q'ty AA50001N CORD ASSEMBLY 2M GK21181 "C"RING PZ50160 CONNECTOR GI21191 IRON WASHER CJ20011 SUSPENSION RING G21301 SPACER CC21011-3 TRIGGER ASSEMBLY GH21221-1 IDLE GEAR CC21011-6 TRIGGER ASSEMBLY -ESD GG21231-1...
- Page 21 All manuals and user guides at all-guides.com NO PARTS NO PARTS NAME-E Q'ty CORD NS-26 1.5M-Chinese AA60005 CORD NS-26 1.5M-Australia AA60005-D CORD NS-26 1.5M-American AA60005-A CORD NS-26 1.5M-Europe AA60005-E CORD NS-26 1.5M-India AA60005-I CORD NS-26 1.5M-UK AA60005-U HOUSING 32V 60W HI/LO P11011-3 HOUSING 32V 40W HI/LO P11012-3...
- Page 22 All manuals and user guides at all-guides.com KILEWS ELECTRIC TOOLS（SHANGHAI）CO., LTD. E-mail:service@kilews.com.cn http://www.kilews.com.cn...
