OPERATION AND MAINTENANCE MANUAL
DC-TYPE Automatic Non Carbon-Brush Series
KILEWS INDUSTRIAL CO., LTD.
KILEWS WEST USA INC. - 6945 LTC PKWY - PORT ST LUCIE, FL 34986
PHONE (772) 293-0071 FAX (772) 465-4368 EMAIL SALES@KILEWSWEST.COM
SKD-BN5012L
SKD-BN5019L
SKD-BN5012LF
SKD-BN5017LF
SKD-BN5012P
SKD-BN5019P
SKD-BN5012PF
SKD-BN5017PF
www.kilewswest.com
Advertisement
Table of Contents
Related Manuals for Kilews SKD-BN5012L
Summary of Contents for Kilews SKD-BN5012L
- Page 1 DC-TYPE Automatic Non Carbon-Brush Series KILEWS INDUSTRIAL CO., LTD. www.kilewswest.com KILEWS WEST USA INC. - 6945 LTC PKWY - PORT ST LUCIE, FL 34986 PHONE (772) 293-0071 FAX (772) 465-4368 EMAIL SALES@KILEWSWEST.COM...
-
Page 2: Important Safety Information Enclosed
NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. WARNING ... -
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. -
Page 4: Additional Information Shall Be Provide
4) Power tool Use and Care a) Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. b) Do not use power tool if switch does not turn it on or off. -
Page 5: Do Not Operate This Tool Without Protective Earth Connected
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. - Page 6 Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in the “OFF “position and tool is unplugged. 2) Do not allow chemicals such as acetone, benzene, thinner, trichloroethylene ketone, or other similar chemicals to come in contact with the screwdriver housing as damage will result.
-
Page 7: Description Of Operation
Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by fingertip, and it will be unlocked. Thus, the bit can be freely attached and detached (single finger notion type) select such a bit whose shank is equal to the size shown below. ... -
Page 8: Do Not Attempt To Repair This Electric Screw Driver
2. All repairs and maintenance of this tool and its word must be performed by an authorized service center. 3. KILEWS is not responsible for customer modification of tools for applications on which KILEWS was not consulted. -
Page 9: Specifications
1# & 2# 1 Pcs. Each SKD-BN5017F with BIT 1# & 2# 1 Pcs. Each 2. Suspension rack and Torque fixing ring acceptable for use with the tool are available from KILEWS catalogue. 3. Torque Fixing Ring (KC-6C) 1 Pcs ... -
Page 10: Torque Adjustment Operation
3. The power supplier will generate low power when the button of the power controller is switched to "LO." Also, the electric screwdriver's torque output setting value should be adjusted to middle torsion value accordingly. 4. Please refer to Kilews website http://www.kilews.com for the detail component list. - Page 12 BN5012P BN5019P NO PARTS NO PARTS NAME-E PARTS NAME-C Q'ty NO PARTS NO PARTS NAME-E PARTS NAME-E Q'ty 1 AA50001-16N CORD ASSEMBLY 2M 電源線2M 32 GA91284 GEAR CASE 上離合器筒 AA50001-139N CORD ASSEMBLY 3M "I/O Signal Control Box" TYPE 電源線 3M (訊號傳輸控制裝置) 33 GN30321 MAIN BEARING 離合器主軸承...
