FabiaTech Fanless Series User Manual

Small cube system
Hide thumbs Also See for Fanless Series:

Advertisement

Quick Links

FabiaTech Corporation
IPC Solution
Website:
http://www.fabiatech.com
Email:
support@fabiatech.com
Small Cube System
Fanless Series
FX5639/FX5639L
User' Manual
MAR 2019
Version: 2.0
Part Number: FX5639

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fanless Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for FabiaTech Fanless Series

  • Page 1 FabiaTech Corporation IPC Solution Website: http://www.fabiatech.com Email: support@fabiatech.com Small Cube System Fanless Series FX5639/FX5639L User’ Manual MAR 2019 Version: 2.0 Part Number: FX5639...
  • Page 2 FabiaTech shall not be reliable for technical or editorial errors or omissions, which may occur in this document. FabiaTech shall not be reliable for any indirect, special, incidental or consequential damages resulting from the furnishing, performance, or use of this document.
  • Page 3: Table Of Contents

    Table of Contents FX5639/FX5639L User’ Manual..................i Chapter 1 Introducing the FX5639 System ................1 Overview..........................1 Series Comparison Table .......................2 Layout............................3 Specifications..........................5 Packing List ..........................6 Chapter 2 Hardware Installation ....................9 Before Installation ........................9 To install Hardware- remove the bottom cover...........10  ...
  • Page 4 Realtek PCIe GBE Family Controller (MAC) ..........55   Chipset ...........................56 North Bridge.......................57   South Bridge.......................60   Security...........................64 Boot ............................66 Save & Exit ..........................68 Chapter 4 Software Installation ....................71 System Driver .........................71 WIN 7/8.1/10 -32/-64 Driver................71   VGA Driver..........................72 WIN 7/8.1/10 -32/-64 Driver................72  ...
  • Page 5 Dimension ..........................89...
  • Page 6: Chapter 1 Introducing The Fx5639 System

    FabIATech Corporation Chapter 1 Introducing the FX5639 System Overview The FX5639 is an embedded system with Intel® Celeron® Braswell low-power CPU module inside. This user’s manual provides information on the physical features, installation, and BIOS setup of the FX5639. Built to unleash the total potential of the Intel® Celeron® N3160 Quad-Core Processor, Able to support 1.6 GHz CPU, this system supports two 10/100/1000M...
  • Page 7: Series Comparison Table

    FabIATech Corporation Series Comparison Table Model FX5639 FX5639L System Processor Intel ® N3160 Celeron ® (Braswell) Clock Speed 1.6GHZ Cache 2M/L2 Burst Frequency 2.24 GHZ Graphics Display VGA/HDMI/DP Memory DDR3L-1333 204 Pin-DIMM*2 4GB / 8GB (Max.) Storage One CFAST Socket One 2.5’...
  • Page 8: Layout

    FabIATech Corporation Layout a. FX5639 ANTENNA RESET DISPLAY2 DISPLAY3 EAR-PHONE LAN2 LAN1 D I/O 12~24V CFAST POWER BUTTON DIGITAL I/O CFAST LINE IN ANTENNA DC IN COM3 COM1 ANTENNA 10101 DC12~24V COM4 SLOT COM2 LAN1 LAN2...
  • Page 9 FabIATech Corporation b. FX5639L ANTENNA RESET DISPLAY2 DISPLAY3 EAR-PHONE LAN2 LAN1 D I/O 12~24V CFAST POWER BUTTON DIGITAL I/O CFAST LINE IN ANTENNA DC IN COM3 COM1 ANTENNA 10101 DC12~24V COM4 SLOT COM2 LAN1 LAN2...
  • Page 10: Specifications

    FabIATech Corporation Specifications Processor Board – Intel ® Celeron ® Braswell N3160 Quad-Core Soc 1.6GHZ (Burst- 2.24GHz) Low Power Processor with 4GB DDR3L-RAM. I/O Outlets – Two 10/100/1000 base-TX Ethernet LAN ports Three USB 3.0 (front side) and four USB 2.0 (rear side) ports...
  • Page 11: Packing List

    FabIATech Corporation Packing List Upon receiving the package, verify the following things. Should any of the mentioned happens, contact us for immediate service. • Unpack and inspect the FX5639 package for possible damage that may occur during the delivery process.
  • Page 12 FabIATech Corporation Option Items for FX5639: • FB4705- 1 Slot (32bit) PCI riser card. (PN: 0153000001G) • FB4744- 1 Slot PCIE riser card. (PN: 0120010003R) Option Items for FX5639L: • FB4730- 2 Slot (32bit) PCI riser card. (PN: 0153010001G) •...
  • Page 13 FabIATech Corporation...
  • Page 14: Chapter 2 Hardware Installation

    FabIATech Corporation Chapter 2 Hardware Installation This chapter introduces the system connectors & jumper settings, and guides you to apply them for field application. Before Installation Before you install the system, make sure you follow the following descriptions. 1. Before removing the cover, shut down the operation System and disconnect power switch to off and unplug AC-to DC Adapter cable.
  • Page 15: To Install Hardware- Remove The Bottom Cover

    FabIATech Corporation To install Hardware- remove the bottom cover If you are installing following hardware items, you can remove the bottom cover. They include SATA 2.5" HDD inside, mini PCIE WLAN or GPRS module, PCI or PCIE Riser card kit, PCI or PCIE expansion card and DDR3L-RAM module to the FX5639.
  • Page 16 FabIATech Corporation c. Installing Memory If you may extend additional memory to system, see as following figure. The So- DIMM socket supports 2GB to 4GB (Max. 8GB) of DDR3L RAM modules. Installing memory module to DIMM1 socket, when only one memory module. We recommend that installing dual channel (DIMM1 &...
  • Page 17 FabIATech Corporation e. Installing PCIe Mini Card Module FX5639x supports PCIe mini card socket; you may extend additional PCIe mini card module and SIM card to system. Connect to the antenna cable from rear and front side antenna holes to GPRS or Wireless LAN module and install the SIM card for GPRS.
  • Page 18 FabIATech Corporation f. Installing PCI or PCIE Riser Card kit (Option) - for Expansion Card FX5639 and FX5639L provides FB4705 kit- 1 slot PCI bus, FB4744 kit -1 slot PCIE bus, FB4745 kit- 1 slot PCI and 1 slot PCIE bus, FB4730 kit -2 slot PCI bus, If you are installing the riser card kit for Expansion PCIE hardware, you can remove the bottom cover.
  • Page 19 FabIATech Corporation g. To installing Expansion Card – PCI/PCIE Card If you are installing Expansion PCI or PCIE hardware interface card, you can remove the bottom side cover. The following figure will guide you how to install PCI/PCIE interface card inside the FX5639 system and screw the L-Type Metal on the PCI/PCIE card Bracket and expansion card holder.
  • Page 20 FabIATech Corporation h. Installing the FX5636K1 –Wall Mounting Please refer to the down side figure for installing the FX5639/FX5636L with universal fixers. h1.FX5639 h2.FX5639L...
  • Page 21 FabIATech Corporation i. Installing the Rubber Feet i1.FX5639 i2.FX5639L...
  • Page 22: Led Indicators (On The Front Panel)

    FabIATech Corporation LED Indicators (On the Front Panel) The Power Button and HDD LED’s have two distinctive statuses: Off for inactive operation and blinking light for activity. And the 2 LED’s for LAN ports. The LAN1 and LAN2 LED’s (Green) indicate on-line/access status of LAN1 and LAN2 respectively.
  • Page 23 FabIATech Corporation 1. Connecting the VGA port DB15 Signal Green Blue Hsync Vsync DDC Data DDC Clock 5 & 10 Digital Ground 6,7,8 Analog Ground Others Not Used Connecting the Display port Display Port Connecting the COM ports The DB9 COM3/4 is standard RS232 serials port, and the DB9-COM1/2 is designed for multiple proposes.
  • Page 24 FabIATech Corporation Connecting the LAN ports The RJ45 connector with 2 LED’s for LAN. The right side LED (orange) indicates data is being accessed and the left side LED (green) indicates on-line status. (On indicates on-line and off indicates off-line) The following lists the pin assignment of RJ45.
  • Page 25 FabIATech Corporation Digital I/O Connector The system provides 2-in and 2-out isolated digital I/O, output port is an open collector, you will need connections external voltage of Digital (+) and digital (-) connector. D I/O DI/O Signal Bit Location IN-1...
  • Page 26: Connecting The Dc Power And Power Button

    FabIATech Corporation Connecting the DC Power and Power Button Power is supplied through an external AC/DC power adapter or power DC In. Check the technical specification section for information about AC/DC power input voltage. See following figure and a side pictures.
  • Page 27: Internal Connector And Jumper Setting

    FabIATech Corporation Internal Connector and Jumper Setting The CN13- COM5 and CN15- COM6 are RS232 Serial ports, CN9 is Parallel port; those RS232, parallel connectors by use the option interface cable to transfer DB9, and DB25 with bracket on the system board inside the FX5639/L, and J6 is used to select clear CMOS data.
  • Page 28 FabIATech Corporation b. CN13/CN15: COM5 & COM6 RS232 Serial Ports Header (2.0mm) The CN13 and CN15 is 10-pin 2.0mm header; use the serial port adapter cables (Option) are used to transfer 10-pin IDC connector into standard DB9 connectors. DB-9 CN13/CN15...
  • Page 29 FabIATech Corporation...
  • Page 30: Chapter 3 Bios Setup

    FabIATech Corporation Chapter 3 BIOS Setup This chapter describes the BIOS setup. Overview BIOS are a program located on a Flash memory chip on a circuit board. It is used to initialize and set up the I/O peripherals and interface cards of the system, which includes time, date, hard disk drive, the internal bus and connected devices such as the video display, diskette drive, and the keyboard.
  • Page 31: Bios Functions

    FabIATech Corporation BIOS Functions On the menu, you can perform the following functions 1. Main 2. Advanced ACPI Settings IT8786 Super IO Configuration Hardware Monitor Serial Port Console Redirection CPU Configuration Thermal Configuration SATA Configuration Network Stack Configuration CSM Configuration...
  • Page 32: Keyboard Convention

    FabIATech Corporation Keyboard Convention On the BIOS, the following keys can be used to operate and manage the menu: Function [↑][↓] The Up and Down keys allow you to select item. [←][→] The Left and Right keys allow you to select screen.
  • Page 33: Main Setup

    FabIATech Corporation Main Setup This section describes BIOS version information and basic system hardware configuration. If the CPU board is already installed in a working system, you will not need to select this option anymore. System Date & Time Setup Highlight the <Date>...
  • Page 34: Advanced Setup

    FabIATech Corporation Advanced Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as USB Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 35: Acpi Settings

    FabIATech Corporation ACPI settings This filed specifies allow you set this value to utilize the ACPI (Advanced Configuration and Power Interface) specification. Enable ACPI Auto Configuration This item allows users to enable or disable BIOS ACPI Auto configuration. Available Options: Disabled, Enabled...
  • Page 36 FabIATech Corporation Available Options: Suspend Disabled and S3 (Suspend to RAM) Default setting: S3 (Suspend to RAM) Lock Legacy Resource This item allows users to enable or disable Lock of Legacy Resources. Available Options: Disabled, Enabled Default setting: Disabled...
  • Page 37: It8786 Super Io Configuration

    FabIATech Corporation IT8786 Super IO Configuration This section describes the function of Super I/O settings.
  • Page 38 FabIATech Corporation Serial Port 1/2 Configuration These fields select the I/O port address for Serial port 1/2. Serial Port This item allows users to select the enable or disable Serial port. Available Options: Enabled, and Disabled. Default setting: Enabled Device Setting COM1-3F8/IRQ4/COM2-2F8/IRQ3 COM1/2 Port Set Select This item allows users can select RS-232, RS-422 and RS-485 of select COM1.
  • Page 39 FabIATech Corporation Serial Port 3/4 Configuration These fields select the I/O port address for Serial port 3/4. Serial Port This item allows users to select the enable or disable Serial port. Available Options: Enabled, and Disabled. Default setting: Enabled Device Setting COM3-3E8/IRQ11/COM4-2E8/IRQ10...
  • Page 40 FabIATech Corporation Serial Port 5/6 Configuration These fields select the I/O port address for Serial port 5/6(Option RS232 Interface Cable with bracket). Serial Port This item allows users to select the enable or disable Serial port. Available Options: Enabled, and Disabled.
  • Page 41: Hardware Monitor Configuration

    FabIATech Corporation Hardware Monitor Configuration On the Hardware Monitor Setup screen, you can monitor the system, +3.3V voltage, and VBAT voltage…...
  • Page 42: Serial Port Console Redirection

    FabIATech Corporation Serial Port Console Redirection This option turns on console redirection support in the BIOS and is the default setting. The remote access feature requires the use of the COM1 connector located at the rear panel of the FX5639.
  • Page 43 FabIATech Corporation Console Redirection Setting Terminal Type This field is selecting the target terminal type. Available Options: VT100, vt100+, VT-UTFB, and PC_ANS1 Default setting: VT100 Bits per Second This field is select Serial ports can use baud rate. Just keep in mind that speed must match terminal setting.
  • Page 44 FabIATech Corporation Parity This field is select Serial ports can use parity mode. Just keep in mind parity must match terminal setting. Available Options: None, Even, Mark, and Spcae Default setting: None Stop Bit This field is select Serial ports can use any mode. Just keep in mind that the bits per second and stop bits must match terminal setting.
  • Page 45 FabIATech Corporation Legacy OS Redirection Resolution On Legacy OS, the Number of Rows and Columns supported redirection Available Options: 80x24, and 80x25 Default setting: 80x24 Putty Keypad This item is select Function Key and Keypad on Putty Available Options: VT100, LINUX, XTERMR6, SCO, ESCN and VT400...
  • Page 46 FabIATech Corporation Console Redirection (OBM/EMS) This field is select console redirection Enable or disable. Serial Port for Out-of-Band Management/ Windows Emergency Management Services (EMS) Available Options: Enabled and Disabled Default setting: Disabled Console Redirection Setting – Out of Band Mgmt Port Microsoft Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port.
  • Page 47 FabIATech Corporation Flow Control The flow control can prevent data loss from buffer overflow. When sending data, if the receiving buffers are full, a 'stop' signal can be sent to stop the data flow. Once the buffers are empty, a 'start' signal can be sent to re-start the flow. Hardware flow control uses two wires to send start/stop signals.
  • Page 48: Cpu Configuration

    FabIATech Corporation CPU Configuration You can use this screen to select options for the CPU information. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 49 FabIATech Corporation Intel Virtualization Technology When enabled, a VMM can utilize the additional hardware capabilities provided by Vander pool Technology. Available Options: Disabled, and Enabled Default setting: Enabled Power Technology This field allows the users to enable or disable the Power Manager feature.
  • Page 50 FabIATech Corporation Turbo Model This field allows users to enable or disable Turbo Mode. Available Options: Disabled, and Enabled Default setting: Enabled P-STATE Coordination This field allows users to enable or disable P-STATE Coordination Type. Available Options: HW_ALL, SOFT_ALL, SW_ANY...
  • Page 51: Thermal Configuration Parameters

    FabIATech Corporation Thermal Configuration Parameters You can use this screen to select options for the Thermal Configuration. Critical Trip Point This value controls the temperature of the ACPI critical Trip Point - the point in which the OS will shut the system off.
  • Page 52: Sata Configuration

    FabIATech Corporation SATA Configuration You can use this screen to select options for the IDE devices Configuration. SATA Controller This item allows users to enable or disable SATA Controller. Available Options: Disabled, and Enabled Default setting: Enabled SATA Interface Speed This item allows users can select SATA speed.
  • Page 53: Network Stack Configuration

    FabIATech Corporation Network Stack Configuration Network Stack This field specifies the PXE boot ROM of the onboard LAN chip. Available Options: Disabled, and Enabled Default setting: Disabled IPV4/IPV6 Support This field specifies the Enable Ipv4 or Ipv6 PXE Boot Support.
  • Page 54: Csm Configuration

    FabIATech Corporation CSM Configuration The CSM (Compatibility Support Module) is Option ROM Execution, boot options filter, etc. CSM Support This item allows users to enable or disable CSM. Available Options: Disabled, and Enabled Default setting: Enabled Boot Option Filter This option controls Legacy/UEFI ROMs priority.
  • Page 55 FabIATech Corporation GateA20 Active UPON REQUEST - GA20 can be disabled using BIOS services. ALWAYS - do not allow disabling GA20; this option is useful when any RT code is executed above 1MB. Available Options: UPON REQUEST, and ALWAYS Default setting: UPON REQUEST...
  • Page 56: Usb Configuration

    FabIATech Corporation USB Configuration You can use this screen to select options for the USB Configuration. Legacy USB Support Legacy USB Support refers to the USB mouse and USB keyboard support. Normally if this option is not enabled; any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded.
  • Page 57 FabIATech Corporation USB Mass Storage Driver Support Mass storage device emulation type. If the emulation FDD, recommended formatted as FAT32 format. Available Options: Disabled, and Enabled Default setting: Enabled USB transfer time-out The time-out value for control, bulk, and interrupt transfers.
  • Page 58 FabIATech Corporation Device power-up delay > Select “Manual“ Device Power-Up delay in second Delay range is 1..40 seconds, in one second increments Available Options: 1, 5, 10, 20, 30, and 40 Sec Default setting: 5 Sec Generic Storage Device 1.01 Mass storage device emulation type.
  • Page 59: Security Configuration

    FabIATech Corporation Security Configuration You can use this screen to select TXE Configuration.
  • Page 60: Realtek Pcie Gbe Family Controller (Mac)

    FabIATech Corporation Realtek PCIe GBE Family Controller (MAC) On the LAN Information screen, you can see the LAN Chipset information, when setting the Launch PXE OpROM Policy to UEFI Only of CSM Boot.
  • Page 61: Chipset

    FabIATech Corporation Chipset This section describes the configuration of the board’s chipset features. • North Bridge • South Bridge...
  • Page 62: North Bridge

    FabIATech Corporation North Bridge You can use this screen to select options for the North Bridge Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 63 FabIATech Corporation Intel IGD Configuration GOP Configuration > GOP Driver The Item is Enable GOP Driver will unload VBIOS; Disable it will load VBIOS. Available Options: Disabled, and Enabled Default setting: Enabled Integrated Graphics Device The Item can select Enable: Enable Integrated Graphics Device (IGD) when selected as the Primary Video Adaptor.
  • Page 64 FabIATech Corporation GFX Boost The Item is can Select Enable/Disable GFX Boost. Available Options: Disabled, and Enabled Default setting: Disabled PAVC The Item is can Select Enable/Disable Protected Audio Video Control. Available Options: Disabled, and Enabled Default setting: Disabled DVMT Pre- Allocated The Item is select DVMT 5.0 Pre-Allocated (Fixed) graphics memory size used by the...
  • Page 65: South Bridge

    FabIATech Corporation South Bridge You can use this screen to select options for the South Bridge Configuration. South Bridge is a chipset on the motherboard that controls the USB, LAN port, and audio function. Restore AC Power Lose This field specifies the option controls how the PC will behave once power is restored following a power outage (or other unexpected or ungraceful shutdown).
  • Page 66 FabIATech Corporation Azalia HD Audio Audio Controller This item allows users to enable or disable Azalia Controller. Available Options: Disabled, and Enabled Default setting: Enabled...
  • Page 67 FabIATech Corporation USB Configuration XHCI Mode The item XHCI (eXtensible Host Controller Interface) a workaround for specification for Universal Serial Bus 3.0 support. If an “OS Selection” selected is windows 8, the “USB.2.0 (EHCI) support would be set to Disabled. (For Windows 8.x)
  • Page 68 FabIATech Corporation PCI Express Configuration PCI Express Port 3/4 The PCI Express Root Port 3/4 item, allows users to enable or disable on PCIe Express Bus signals. Available Options: Disabled, and Enabled Default setting: Enabled...
  • Page 69: Security

    FabIATech Corporation Security Security Setup provides both Administrator and User password. If you use both passwords, the Administrator password must be set first. The system can be configured so that all users must enter a password every time the system boots or when Setup is executed, using either the Administrator password or User password.
  • Page 70 FabIATech Corporation Clear Old Password Select Administrator/user password item, press <Enter> and type current password, at the next dialog press <Enter> to Clear Old Password.
  • Page 71: Boot

    FabIATech Corporation Boot Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Device Priority, to go to the sub menu for that item. You can display a Boot BIOS Setup option by highlighting it using the <Arrow>...
  • Page 72 FabIATech Corporation Quiet Boot This item allows users to enable or disable Quiet boot option. If Enable, an OEM LOGO is shown instead of POST messages. Available Options: Disabled, and Enabled Default setting: Disabled Fast Boot This field is used to activate the fast boot function of the system. When set to Enabled, boot with initialization of a minimal set of devices required to launch active boot option.
  • Page 73: Save & Exit

    FabIATech Corporation Save & Exit Save Changes and Exit When you have completed the system configuration changes, select this option to save the changes and Exit , so the new system configuration parameters can take effect. Discard Changes and Exit Select this option to quit without making any modifications to the system configuration.
  • Page 74 FabIATech Corporation Discard Changes and Reset Select this option to reboot the system without saving the changes done in the setup configuration. Save Changes When you have completed the system configuration changes, select this option to save your system configuration and continue. For some of the options it required to reset the system to take effect.
  • Page 75 FabIATech Corporation...
  • Page 76: Chapter 4 Software Installation

    FabIATech Corporation Chapter 4 Software Installation The enclosed DVD diskette includes FX5639 VGA, System, Audio, LAN and USB driver. To install and configure you system, you need to perform the following steps. Note: The Windows 7 installation media does not include native driver support for USB 3.0- XHCI driver, so during installation, when you get to the screen to select...
  • Page 77: Vga Driver

    FabIATech Corporation VGA Driver WIN 7/8.1/10 -32/-64 Driver Step 1: To install the VGA driver, insert the CD ROM into the CD ROM device, and enter DRIVER>VGA>Braswell>WIN32> or >WIN64>. Step 2: Execute Setup.EXE file. Step 3: The screen shows the SETUP type. Press any key to enter the main menu.
  • Page 78: Lan Driver (Rtl 8111F)

    FabIATech Corporation LAN Driver (RTL 8111F) WIN 7 Driver X86/X64 Driver Step 1: To install the LAN driver, insert the CD ROM into the CD ROM device, and enter DRIVER>LAN>RTL8111F>WIN7. If your system is not equipped with a CD ROM device, copy the LAN driver from the CD ROM to CF.
  • Page 79: Txe Driver

    FabIATech Corporation TXE Driver WIN7/8.1/10 X86/X64 Driver Step 1: To install the TXE driver, insert the CD ROM into the CD ROM device, and enter DRIVER>TXE>Braswell>. Step 2: Execute SETUPTXE.exe file. Step 3: The screen shows the SETUP type. Press any key to enter the main menu.
  • Page 80: Efi Bios Flash Utility

    FabIATech Corporation EFI BIOS Flash Utility In the <UTILITY> directory, there is the fpt64_281.zip EFI BIOS flash tool (Include fpt64_281.efi and fparts.txt file), Follow these steps to upgrade BIOS: Step 1: Uncompress the fpt64_281.zip BIOS flash tool and copy new BIOS file to the root directory of USB-Stick.
  • Page 81: Watchdog Timer

    FabIATech Corporation Watchdog Timer This section describes how to use the Watchdog Timer, including disabled, enabled, and trigger functions. The FX5639 is equipped with a programmable time-out period watchdog timer. You can use your own program to Enabled the watchdog timer. Once you have enabled the watchdog timer, the program should trigger the I/O every time before the timer times out.
  • Page 82: Watchdog Timer Setting

    FabIATech Corporation Watchdog Timer Setting The watchdog timer is a circuit that may be used from your program software to detect system crashes or hang-ups. The watchdog timer is automatically disabled after reset. Once you have enabled the watchdog timer, your program must trigger the watchdog timer every time before it times out.
  • Page 83: Watchdog Timer Enabled

    FabIATech Corporation Watchdog Timer Enabled To enable the watchdog timer, you have to output a byte of timer factor to the watchdog register whose address is 2eh and data port is 2fH. The following is a Demo program, which demonstrates how to enable the watchdog timer and set the time-out period at 28 seconds.
  • Page 84: Digital I/O (Gpio) Programming

    FabIATech Corporation Digital I/O (GPIO) programming The following is a Demo program, which demonstrates how to read and write the data of GPIO. ;---------------------------------------------------------------------------------------------------------------- ; Configuration the Digital IO port is A03h-(GPO) Bit6, Bit7/ A05h-(GPI) Bit 1, Bit 2. ; A03h-Bit6/Bit7 (GPO-0 ~ GPO-1, Write data) When set to a “1”, respective GPO port is programmed as ‘High’.
  • Page 85 FabIATech Corporation...
  • Page 86: Chapter 5 Technical Reference

    FabIATech Corporation Chapter 5 Technical Reference This section outlines the errors that may occur when you operate the system, and also gives you the suggestions on solving the problems. Topic include: Technical Reference Dimension Technical Reference Physical and Environmental Temperature: Operating - 20°C ~ 55°C...
  • Page 87: Serial Ports

    FabIATech Corporation Serial Ports The ACEs (Asynchronous Communication Elements ACE1 to ACE2) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the receiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits.
  • Page 88 FabIATech Corporation Bit 2: Enable Receiver Line Status Interrupt (ELSI) Bit 3: Enable MODEM Status Interrupt (EDSSI) Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0 Bit 7: Must be 0 Interrupt Identification Register (IIR) Bit 0: “0”...
  • Page 89 FabIATech Corporation Bit 6: Set Break Bit 7: Divisor Latch Access Bit (DLAB) MODEM Control Register (MCR) Bit 0: Data Terminal Ready (DTR) Bit 1: Request to Send (RTS) Bit 2: Out 1 (OUT 1) Bit 3: Out 2 (OUT 2)
  • Page 90 FabIATech Corporation Bit 5: Data Set Ready (DSR) Bit 6: Ring Indicator (RI) Bit 7: Received Line Signal Detect (RSLD) Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1 Bit 9 Bit 2: Bit 2...
  • Page 91: Parallel Ports

    FabIATech Corporation Parallel Ports Register Address Port Address Read/Write Register Base + 0 Write Output data Base + 0 Read Input data Base + 1 Read Printer status buffer Base + 2 Write Printer control latch Printer Interface Logic The parallel portion of the Winbond 83627 makes the attachment of various devices that accept eight bits of parallel data at standard TTL level.
  • Page 92 FabIATech Corporation Bit 7: This signal may become active during data entry, when the printer is off-line during printing, or when the print head is changing position or in an error state. When Bit 7 is active, the printer is busy and cannot accept data.
  • Page 93 FabIATech Corporation Bit 5: Direction control bit. When logic 1, the output buffers in the parallel port are disabled allowing data driven from external sources to be read; when logic 0 they work as a printer port. This bit is write-only.
  • Page 94: Appendix

    FabIATech Corporation Appendix Dimension a. FX5639...
  • Page 95 FabIATech Corporation b. FX5639-FX5636k1 universal fixers R2.25 R4.5 208(REF) 90(REF) 228(REF)
  • Page 96 FabIATech Corporation c. FX5639L...
  • Page 97 FabIATech Corporation d. FX5639L-FX5636k1 universal fixers R2.25 R4.5 208(REF) 113(REF) 228(REF)
