FabiaTech Fanless Series User Manual

Panel pc system
Hide thumbs Also See for Fanless Series:
Table of Contents

Advertisement

Quick Links

Download this manual
FabiaTech Corporation
IPC Solution
Website:
http://www.fabiatech.com
Email:
support@fabiatech.com
Panel PC System
Fanless Series
FP8152
User's Manual
MAR 2017
Version: 1.2
Part Number: FP8152

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fanless Series and is the answer not in the manual?

Questions and answers

Related Manuals for FabiaTech Fanless Series

Summary of Contents for FabiaTech Fanless Series

  • Page 1 FabiaTech Corporation IPC Solution Website: http://www.fabiatech.com Email: support@fabiatech.com Panel PC System Fanless Series FP8152 User’s Manual MAR 2017 Version: 1.2 Part Number: FP8152...
  • Page 2 FabiaTech shall not be reliable for technical or editorial errors or omissions, which may occur in this document. FabiaTech shall not be reliable for any indirect, special, incidental or consequential damages resulting from the furnishing, performance, or use of this document.

  • Page 3: Table Of Contents

    Table of Contents FP8152 User’s Manual ......................i Chapter 1 Introducing the FP8152 Panel PC................1 Overview..........................1 Series Comparison Table .......................2 Layout............................3 Specifications..........................4 Packing List ..........................6 Chapter 2 Hardware Installation ....................7 Before Installation ........................7 To install hardware- Remove the Side Cover ..........8 　...
  • Page 4 Boot Setup ..........................50 Legacy > Boot Device Priority.................52 　 Chapter 4 Software Installation ....................53 System Driver .........................53 Windows 7/8/8.1 X86/X64- System Driver ...............53 VGA Driver..........................54 WIN7/8/8.1 X86/X64 Driver ..................54 USB Driver ..........................54 WIN7 X86/X64 Driver ....................54 Audio Driver...........................55 WIN7/8/8.1 X86/X64 Driver ..................55 LAN Driver (Intel I210AT &...

  • Page 6: Chapter 1 Introducing The Fp8152 Panel Pc

    FabiaTech Corporation Chapter 1 Introducing the FP8152 Panel PC Overview The FP8152 is 15-inch TFT Panel PC, this panel PC with Intel® Core™ i5 -4422E (Haswell) CPU module inside and touch screen device, this user’s manual provides information on the physical features, installation, and BIOS setup.

  • Page 7: Series Comparison Table

    FabiaTech Corporation Series Comparison Table Model FP8152T System Processor Intel ® i5-4422E™ (HasWell) Clock Speed 1.8 GHz Intel® Turbo Boost 2.9 GHz Technology 2.0: (Max Frequency) Memory DDR3L/1333,1600/1.35V 204 Pin-DIMM*2(Max.) 8GB/16GB Multi I/O Two RS232/RS422/RS485 and Four RS232 USB 2.0 / 3.0...

  • Page 8: Layout

    FabiaTech Corporation Layout FP8152 POWER BUTTON DIGITAL IO RESET DISPLAY2 COM5 COM3 COM1 DC IN SLOT EAR-PHONE LAN1 LAN2 COM6 COM4 COM2 ANTENNA ANTENNA...

  • Page 9: Specifications

    FabiaTech Corporation Specifications Processor Board – 4th Generation Intel® Core™ i5-4422E (Dual Core 1.8GHz,3MB L3 Cache, 25 Watts and support Intel® Turbo Boost Technology up to 2.9GHz) low power processor with 8GB DDR3L-RAM I/O Outlets – Two PCIe 10/100/1000 base-TX Ethernet LAN ports with RJ45...
  • Page 10 FabiaTech Corporation Dimensions – 400mm (D) x 64.9mm (W) x 307mm (H) Certifications- EMC: CE/FCC Others- Front panel protection Approval: IP65 Compliant Weight: 7.6 Kg (Standard packing)

  • Page 11: Packing List

    FabiaTech Corporation Packing List Upon receiving the package, verify the following things. Should any of the mentioned happens, contact us for immediate service. • Unpack and inspect the FP8152package for possible damage that may occur during the delivery process. •...

  • Page 12: Chapter 2 Hardware Installation

    FabiaTech Corporation Chapter 2 Hardware Installation This chapter introduces the system connectors and guides you to apply them for field application. Before Installation Before you install the system, make sure you follow the following descriptions. 1. Before removing the cover, shut down the operation System and disconnect power switch to off and unplug AC cable.

  • Page 13: To Install Hardware- Remove The Side Cover

    FabiaTech Corporation To install hardware- Remove the Side Cover If you are installing following hardware items, you can remove the side cover. The following figure will guide you how to install SATA 2.5" HDD, CFAST Compact Flash, mini PCIe WLAN or GPRS module to the FP8152T and how to install the FP8152T fixers.
  • Page 14 FabiaTech Corporation b. Installing SATA Hard disk and CFAST Faster Screws up the Hard disk device to HDD metal frame then insert to SATA slot and screws up metal frame to system. See following figure. b1: Fasten Screws the SATA HDD into the HDD Metal Frame M3*P0.5...
  • Page 15 FabiaTech Corporation c. Installing PCIe Mini Card Module FP8152T supports PCIe mini card socket; you may extend additional PCIe mini card module and SIM card to system. Connect to the antenna cable from side cover antenna holes to GPRS or Wireless LAN module and install the SIM card for GPRS.
  • Page 16 FabiaTech Corporation d. To installing Expansion Card – PCI/PCIE Card If you are installing Expansion PCIE or PCI hardware interface card, you can remove the side cover. The following figure will guide you how to install PCIE interface card inside the FP8152 and screw the L-Type Metal on the PCIE card Bracket and expansion card holder.
  • Page 17 FabiaTech Corporation e. Installing the universal fixers on FP8152 Please refer to the back side figure for installing the FP8152T with universal fixers. e1. FP8152K1 (Optional) – Mounting Kit with VESA 75/100 mm Standards M3*P0.5 e2. Embedded Wall mounting WALL...

  • Page 18: I/O Peripheral Connectors

    FabiaTech Corporation I/O Peripheral Connectors View from the bottom side, if you are connecting the monitor, LAN, COM, Digital I/O, Audio, VGA, HD-Display Port, and USB to the FP8152. See following figure and a side pictures. a. Bottom Side of FP8152 Panel PC...
  • Page 19 FabiaTech Corporation Connecting the LAN ports The RJ45 connector with 2 LED’s for WAN/LAN. The left side LED (orange) indicates data is being accessed and the right side LED (green) indicates on-line status. (On indicates on-line and off indicates off-line)The following lists the pin assignment of RJ45.
  • Page 20 FabiaTech Corporation Digital I/O Connector The FP8152 provides 4-in and 4-out isolated digital I/O, output port is an open collector, you will need connections external voltage of Digital (+) and digital (-) connector. D I/O DI/O Signal Bit Location Digital Voltage...

  • Page 21: Connecting The Dc Power And Power Button

    FabiaTech Corporation Connecting the DC Power and Power Button Power is supplied through an external power DC In. See following figure and a side pictures. DC Power Connector: Use external 2-pin apartable terminal block. DC12~24V DC +12V~+24V, 70VA minimum Power Button & Reset Push Button: Pushing the Power button once will switch the FP8152 on and off, depending on system BIOS (Chipset >...

  • Page 22: Chapter 3 Bios Setup

    FabiaTech Corporation Chapter 3 BIOS Setup This chapter describes the BIOS setup. Overview BIOS are program located on a Flash memory chip on a circuit board. It is used to initialize and set up the I/O peripherals and interface cards of the system, which includes time, date, hard disk drive, and connected devices such as the video display, diskette drive, USB device, and the USB keyboard.

  • Page 23: Boot Manager Setup

    FabiaTech Corporation Press “ESC” or “Delete” key enter to BIOS Setup screen Boot Manager Setup Use this screen to specify the order in which the system checks for the device to boot from. To access this screen, select Boot Option Menu on the Boot Manager...

  • Page 24: Device Manager Setup

    FabiaTech Corporation Device Manager Setup You can use this screen to select options for the Devices List Configuration. Device Manager is a Super I/O chipset on the system board that controls the basic serial port functions, and hardware monitor.
  • Page 25 FabiaTech Corporation SIO ITE8786E IO Configuration This section describes the function of Super I/O (ITE8787E) settings. Serial Port A/B This item allows users to enable and disable Serial Port A/B (COM1/2). If set to Auto, is EFI/OS chooses configuration. Available Options: Disabled, Enabled and Auto...
  • Page 26 FabiaTech Corporation COM Port 1/2 Select Function These fields item can select RS-232, RS-422 and RS-485 of select port 1/2. Available Options: RS-232, RS-422 and RS485 Default setting: RS-232 Serial Port C/D This item allows users to enable and disable Serial Port C/D (COM3/4). If set to Auto, is EFI/OS chooses configuration.
  • Page 27 FabiaTech Corporation Hardware Monitor On the Hardware Monitor screen, you can monitor the CPU temperature, CPU voltage, and 3.3V voltage…...

  • Page 28: Scu Setup

    FabiaTech Corporation SCU Setup On the menu, you can perform the following functions 1. Main 2. Advanced Boot Configuration Peripheral Configuration SATA Configuration Thermal Configuration Video Configuration USB Configuration Chipset Configuration PCI Configuration Console Configuration Chipset PCIE Controller 3. Security...

  • Page 29: Keyboard Convention

    FabiaTech Corporation Exit Saving Changes: Exit system setup after saving the changes.F10 key can be used for this operation. Save Change Without Exit: Save changes and without exiting system. Exit Discarding Changes: Exit system setup without saving any changes. ESC key can be used for this operation.

  • Page 30: Main Setup

    FabiaTech Corporation Main Setup This section describes basic system hardware configuration, CPU information, system clock setup and BIOS version information. If the CPU board is already installed in a working system, you will not need to select this option anymore.

  • Page 31: Advanced Setup

    FabiaTech Corporation Advanced Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...

  • Page 32: Boot Configuration

    FabiaTech Corporation Boot Configuration Boot Up Num-Lock This field is used to activate the Num Lock function upon system boot. If the setting is on, after a boot, the Num Lock light is lit, and user can use the number key.

  • Page 33: Peripheral Configuration

    FabiaTech Corporation Peripheral Configuration This section describes the function of peripheral settings. Azalia Controller This field specifies the internal Azalia codec Control. Available Options: Auto, Enabled and Disabled Default setting: Auto...

  • Page 34: Sata Configuration

    FabiaTech Corporation SATA Configuration You can use this screen to select options for the SATA Configuration Settings. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 35 FabiaTech Corporation SATA Port0/1 Hot plug The system SATA HDD corresponding SATA port 0 hot plugs, this item allows users to enable or disable SATA port 0. Available Options: Disabled, and Enabled Default setting: Disabled Spin-Up Device The item supports staggered Spin-Up (SSS) in AHCI Host Capability register Bit 27.

  • Page 36: Video Configuration

    FabiaTech Corporation Video Configuration You can use this screen to select options for the video Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 37 FabiaTech Corporation Internal Graphics Internal Graphics Device This field is select internal graphics controller device to Enabled or Disabled. Available Options: Enabled, Disabled, and Auto Default setting: Auto IGD – Aperture Size This field specifies the system memory size that can be used by the Internal Graphics Device (IGD).
  • Page 38 FabiaTech Corporation Available Options: 0MB, 32MB, 64MB, 96MB, 128MB, 160MB, 192MB, 224MB, 256MB, 288MB, 320MB, 352MB, 384MB, 416MB, 448MB, 480MB, 512MB, and 1024MB Default setting: 32 MB IGD – DVMT Size This field specifies allows you to select the maximum amount of graphics memory of DVMT 5.0 to be shared with the system memory.

  • Page 39: Usb Configuration

    FabiaTech Corporation USB Configuration You can use this screen to select options for the USB Configuration. USB BIOS Support The USB BIOS Support refers to the USB mouse, USB keyboard and USB storage support. Normally if this option is not enabled; any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded.
  • Page 40 FabiaTech Corporation XHCI The item XHCI (eXtensible Host Controller Interface) a workaround for specification for Universal Serial Bus 3.0 support. Available Options: Disabled, Auto, Smart Auto, and Enabled Default setting: Disabled...

  • Page 41: Chipset Configuration

    FabiaTech Corporation Chipset Configuration VT-d The Item is Check to enable VT-d function on MCH. Available Options: Disabled, and Enabled Default setting: Enabled After G3 On This field is specify what state to go to when power is re-applied after power failure (G3 State).The states S0(G0) is working of power state, the states S5(G2) is soft off of...
  • Page 42 FabiaTech Corporation Max TOLUD This field is Max value of TOLUD; Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. Available Options: Dynamic, 1GB, 1.25GB, 1.5GB, 1.75GB, 2GB, 2.25GB, 2.5GB, 2.75GB, 3GB, and 3.25GB...

  • Page 43: Console Redirection Setup

    FabiaTech Corporation Console Redirection Setup This option turns on Console Redirection Setup for remote access support in the BIOS and is the default setting. The console remote access feature requires the use of the serial port connector located at the back side of the system.
  • Page 44 FabiaTech Corporation Available Options: COM_1, COM_2, COM_3, COM_4, PCI Device, and All Device Ports. Default setting: COM_1 Terminal Type This field is selecting the target terminal type. Available Options: VT100, vt100+, VT-UTFB, and PC_ANS1 Default setting: VT100 Baud Rate This field is select Serial ports can use baud rate. Just keep in mind that speed must match terminal setting.
  • Page 45 FabiaTech Corporation C (Console).R (Redirection) After Post These fields is select console redirection is active during post and during boot loader or always active or off active. (Some OSS may not work if set to Always) Available Options: Yes, and No...

  • Page 46: Chipset Pcie Controller

    FabiaTech Corporation Chipset PCIE Controller You can use this screen to select options for the PCIE controller Configuration. PCIe LAN1/LAN2 Controller This field specifies the Enabled or Disable of the onboard LAN1 and LAN2 chip. Available Options: Disabled, Enabled Default setting: Enabled...

  • Page 47: Security Setup

    FabiaTech Corporation Security setup There are two security passwords: Supervisor and User. Supervisor a privileged person that can change the User password from the BIOS, According to the default setting, both access passwords are not set up and are only valid after you set the password from the BIOS.
  • Page 48 FabiaTech Corporation 5. Select the Disabled or Enabled. Enabled: System will ask input password on post time. Disabled: System will ask input password on post time. When go to BIOS setup. 6. Point to Save Settings and Exit and press Enter. (or Press F10) 7.

  • Page 49: Power Setup

    FabiaTech Corporation Power Setup The Power menu allows user to set or control various parameters on power manager, and sleep states. Wake on LAN This item is can select Enabled to integrated LAN to wake up the system. Available options: Enabled, Disabled...

  • Page 50: Advanced Cpu Controller

    FabiaTech Corporation Advanced CPU Controller You can use this screen to select options for the CPU controller Configuration. Hardware Prefetcher This field specifies the Enabled or Disable to turn on/turn off the MLC (Mid Level Cache, L2 Cache) streamer prefetcher.
  • Page 51 FabiaTech Corporation HT Support This field specifies can select Auto or Disabled of Hyper-Threading. Available Options: Disabled, and Auto Default setting: Auto Excute Disable Bit This field specifies is XD can prevent certain classes of malicious buffer overflow attacks when combined with supporting OS.
  • Page 52 FabiaTech Corporation Config TDP Configurations You can use this screen to select options for the CPU controller Configuration. Configurable TDP Boot Mode This field specifies is Configure TDP Mode as Nominal / Up / Down for windows OS. Available Options: Nominal, Up, and Down...
  • Page 53 FabiaTech Corporation Custom Configurable TDP Setting Custom ConfigTDP Count This field specifies is Configure the number of custom ConfigTDP levels required. Note: this must be 1 if Configurable TDP Lock is enabled. Available Options: 1, and 0 Default setting: 1...
  • Page 54 FabiaTech Corporation Custom Setting 0 Long Term Power Limit This field specifies is Long Term Power Limit (aka Power Limit 1) value in Watts. XE SKU: any value can be programmed. Overclocking SKU: Value must be between Max and Min Power Limits. Other SKUs: This Value must be between Min Power Limit and TDP Limit.

  • Page 55: Boot Setup

    FabiaTech Corporation Boot Setup Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Legacy, to go to the sub menu for that item. You can display a Boot BIOS Setup option by highlighting it using the <Arrow>...
  • Page 56 FabiaTech Corporation Available Options: Disabled, and Enabled Default setting: Disabled Network Stack This field specifies the PXE boot ROM of the onboard LAN chip. Available Options: Disabled, Enabled Default setting: Disabled Add Boot Options This field specifies the position in boot order for shell, network and removable.

  • Page 57: Legacy > Boot Device Priority

    FabiaTech Corporation Legacy > Boot Device Priority Use this screen to specify the order in which the system checks for the device to boot from. To access this screen, select Normal or Advance of Normal Boot Menu on the Boot Setup screen.

  • Page 58: Chapter 4 Software Installation

    FabiaTech Corporation Chapter 4 Software Installation Chapter 4 Software Installation The enclosed DVD diskette includes VGA, Audio, System, USB and LAN driver. To The enclosed DVD diskette includes VGA, Audio, System, USB and LAN driver. To install and configure you FX5638 system, you need to perform the following steps.

  • Page 59: Vga Driver

    FabiaTech Corporation VGA Driver WIN7/8/8.1 X86/X64 Driver Step 1: To install the VGA driver, insert the DVD ROM into the DVD ROM device, and enter DRIVER>VGA>HASWELL >WIN32 or >WIN64. Step 2: Execute Setup.exe file. Step 3: The screen shows the SETUP type. Press any key to enter the main menu.

  • Page 60: Audio Driver

    FabiaTech Corporation Audio Driver WIN7/8/8.1 X86/X64 Driver Step 1: To install the AUDIO driver, insert the CD ROM into the CD ROM device, and enter DRIVER>AUDIO>ALC888>WIN8 > WIN32, or WIN64. Step 2: Execute 32bit_Win7_Win8_Win81_R273.exe file. Step 3: The screen shows the SETUP type. Press any key to enter the main menu.

  • Page 61: Touch Screen Driver

    FabiaTech Corporation Touch Screen Driver WIN WES7/WIN7/WIN8.1 Driver Step 1: To install the Touch Screen driver, insert the CD ROM into the CD ROM device, and enter DRIVER>TouchScreen>PM6500>USB_RS232>Windows. Step 2: Execute Setup.exe file. Just click [Next >] button to continue installation.
  • Page 62 FabiaTech Corporation Step 4: When ready to install the driver. Click “Install”. Step 5: When the window below shows up, please select “yes” for installing PenMount as mouse mode; select “no” for digitizer mode. If your operating system doesn’t support Windows tablet input, digitizer device can’t be used, therefore you have to select “yes”...
  • Page 63 FabiaTech Corporation Step 6: A Windows Notifying of installation completion appears. Click “Finish”. Step 7: Users can check the situation of controllers in Device Manager. If the controller is set up well, there will be messages as the following picture.

  • Page 64: Configure Penmount Driver Utility

    FabiaTech Corporation Step 8: As soon as driver installation finishes, the icon of PenMount monitor. Configure PenMount driver Utility The controller is displayed on the Panel List box. Users can get the information of interface type for each controller. Select one device after added more than one device at the panel list window.
  • Page 65 FabiaTech Corporation Configure Device 0 (PenMount 6000 USB) < Calibrate > This function offers two ways to calibrate your touch screen. ‘Standard Calibration’ adjusts most touch screens while ‘Advanced Calibration’ adjusts aging touch screens. Standard Calibration Click this button and arrows appear pointing to red squares. Use your finger or stylus to touch the red squares in sequence.
  • Page 66 FabiaTech Corporation To calibrate your Touch Screen: 1. Please select a device then click “Configure”. You can also double click the device too. 2. Click “Standard Calibration” to start standard calibration or “Advanced Calibration” to start Advanced Calibration. Advanced Calibration You can Uses 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens.
  • Page 67 FabiaTech Corporation <Setting> Operation Mode This mode enables and disables mouse’s ability of dragging on-screen icons— useful for configuring POS terminals. Pen Input Emulation Select this mode and mouse will emulate Windows Vista pen input device operation, by which no mouse event will be sent until the touch is dragged out of range or released from the screen.
  • Page 68 FabiaTech Corporation <Edge Compensation> This page is the edge compensation settings. You can adjust the settings from 0 to 30 for accommodating the difference of each touch panel. <About> This panel displays information about the PenMount controller and driver version...
  • Page 69 FabiaTech Corporation Multiple Monitors The multiple monitors function supports two to six touch screen displays for one system. PenMount drivers for Windows 7, 8.1, and 10 32/64bit, support Multiple Monitors. This function supports from two to four touch screen displays for one system.
  • Page 70 FabiaTech Corporation Tools <Draw> Tests or demonstrates the PenMount touch screen operation. The display shows touch location. Click Draw to start. Touch the screen with your finger or a stylus and the drawing screen registers touch activity such left, right, up, down, pen up, and...
  • Page 71 FabiaTech Corporation <Right Button Icon> The function simulates the right button function of a mouse. Click the right button and the user can only touch the screen once and the driver changes the touch definition to the left button. <Double Click Speed>...

  • Page 72: Watchdog Timer

    FabiaTech Corporation Watchdog Timer This section describes how to use the Watchdog Timer, including disabled, enabled, and trigger functions. The system is equipped with a programmable time-out period watchdog timer. You can use your own program to enable the watchdog timer. Once you have enabled the watchdog timer, the program should trigger the I/O every time before the timer times out.

  • Page 73: Watchdog Timer Setting

    FabiaTech Corporation Watchdog Timer Setting The watchdog timer is a circuit that may be used from your program software to detect system crashes or hang-ups. The watchdog timer is automatically disabled after reset. Once you have enabled the watchdog timer, your program must trigger the watchdog timer every time before it times out.

  • Page 74: Watchdog Timer Enabled

    FabiaTech Corporation Watchdog Timer Enabled To enable the watchdog timer, you have to output a byte of timer factor to the watchdog register whose address is 2eh and data port is 2fH. The following is a Demo program, which demonstrates how to enable the watchdog timer and set the time-out period at 28 seconds.

  • Page 75: Digital I/O (Gpio) Programming

    FabiaTech Corporation Digital I/O (GPIO) programming The following is a Demo program, which demonstrates how to read and write the data of GPIO. ;---------------------------------------------------------------------------------------------------------------- ; Configuration the Digital IO port is A06h-(GPO) Bit0, Bit1, Bit2, Bit3/ (GPI) Bit 4, Bit 5, ;...

  • Page 76: Chapter 5 Technical Reference

    FabiaTech Corporation Chapter 5 Technical Reference This section outlines the errors that may occur when you operate the system, and also gives you the suggestions on solving the problems. Topic include: Trouble Shooting for LCD Display and Touch Screen Technical Reference...

  • Page 77: Lcd Display Is Unstable

    FabiaTech Corporation When plug HD display port use windows extend monitor Function, touch device calibration is can’t complete adjust. Workaround: Go to Touch Configure PenMount driver Utility > Multiple Monitors. This function supports from two to four touch screen displays for one system.

  • Page 78: Serial Ports

    FabiaTech Corporation Serial Ports The ACEs (Asynchronous Communication Elements ACE1 to ACE2) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the receiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits.
  • Page 79 FabiaTech Corporation Bit 1: Enable Transmitter Holding Empty Interrupt (ETBEI) Bit 2: Enable Receiver Line Status Interrupt (ELSI) Bit 3: Enable MODEM Status Interrupt (EDSSI) Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0...
  • Page 80 FabiaTech Corporation Bit 5: Stick Parity Bit 6: Set Break Bit 7: Divisor Latch Access Bit (DLAB) MODEM Control Register (MCR) Bit 0: Data Terminal Ready (DTR) Bit 1: Request to Send (RTS) Bit 2: Out 1 (OUT 1) Bit 3: Out 2 (OUT 2)
  • Page 81 FabiaTech Corporation Bit 4: Clear to Send (CTS) Bit 5: Data Set Ready (DSR) Bit 6: Ring Indicator (RI) Bit 7: Received Line Signal Detect (RSLD) Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1...

  • Page 82: Appendix

    FabiaTech Corporation Appendix Dimension a. FP8152 380(REF.) 54.9 64.9 352.4 23.8...
  • Page 83 FabiaTech Corporation b. FP8152 - Wall Mounting Cut-Out Dimension 352.4 Cut out dimension 355 x 265 mm...
  • Page 84 FabiaTech Corporation c. FP8152K1 - Embedded Mounting with VESA 75*75/100*100 mm 110.2(REF.) 144(REF.) 12.5 75(REF.) R2.8 R5.0 M4*P0.7*9L...
