FabiaTech Fanless Series User Manual

Small system - expansion box
Hide thumbs Also See for Fanless Series:
Table of Contents

Advertisement

Quick Links

Download this manual
FabiaTech Corporation
IPC Solution
Website:
http://www.fabiatech.com
Email:
support@fabiatech.com
Small System
– Expansion Box
Fanless Series
FX5637/S1/S2
User' Manual
JAN 2019
Version: 1.4
Part Number: FX5637X

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fanless Series and is the answer not in the manual?

Questions and answers

Related Manuals for FabiaTech Fanless Series

Summary of Contents for FabiaTech Fanless Series

  • Page 1 FabiaTech Corporation IPC Solution Website: http://www.fabiatech.com Email: support@fabiatech.com Small System – Expansion Box Fanless Series FX5637/S1/S2 User’ Manual JAN 2019 Version: 1.4 Part Number: FX5637X...
  • Page 2 FabiaTech shall not be reliable for technical or editorial errors or omissions, which may occur in this document. FabiaTech shall not be reliable for any indirect, special, incidental or consequential damages resulting from the furnishing, performance, or use of this document.

  • Page 3: Table Of Contents

    Table of Contents FX5637/S1/S2 User’ Manual ....................i Chapter 1 Introducing the FX5637 System ................1 Overview..........................1 Series Comparison Table .......................2 Layout............................3 Specifications..........................6 Packing List ..........................7 Chapter 2 Hardware Installation ....................9 Before Installation ........................9 To install Hardware- remove the bottom cover...........10 　...
  • Page 4 Power Setup ..........................54 Advanced CPU Controller ................55 　 Boot Setup ..........................60 Legacy > Boot Device Priority.................62 　 Chapter 4 Software Installation ....................63 System Driver .........................63 Windows 7/8/8.1 X86/X64- System Driver ...............63 VGA Driver..........................64 WIN7/8/8.1 X86/X64 Driver ..................64 USB Driver ..........................64 WIN7 X86/X64 Driver ....................64 Audio Driver...........................65 WIN7/8/8.1 X86/X64 Driver ..................65...

  • Page 5: Chapter 1 Introducing The Fx5637 System

    FabiaTech Corporation Chapter 1 Introducing the FX5637 System Overview The FX5637x is an embedded system with Intel® Core™ i7/i5/i3 (HASWELL) CPU module inside. This user’s manual provides information on the physical features, installation, and BIOS setup of the FX5637 series.

  • Page 6: Series Comparison Table

    FabiaTech Corporation Series Comparison Table Model FX5637 FX5637S1 FX5637S2 -i3/-i5 S1-i3/S1-i5 S2-i3/S2-i5 Intel ® Processor i7-4700EQ™ i3 -4102E™ i5-4422E™ Clock Speed 2.4GHz 1.6GHz 1.8GHz Smart Cache 3.4 GHz 2.9 GHz Intel® Turbo Boost Technology 2.0: Memory DDR3L/1600/1.35V 204 Pin-DIMM*1(Max.) Graphics Display...

  • Page 7: Layout

    FabiaTech Corporation Layout a. FX5637/i3/i5 ANTENNA DIGITAL I/O CFAST DISPLAY2 POWER BUTTON RESET DISPLAY3 LAN1 LAN2 1 0 1 CFAST 12~40V DC IN COM3 COM1 ANTENNA DC IN CARD 10101 +12~24V +12V ANTENNA COM4 COM2 LAN1 LAN2 EAR-PHONE...
  • Page 8 FabiaTech Corporation b. FX5637S1/S1-i3/S1-i5 ANTENNA DIGITAL I/O CFAST DISPLAY2 POWER BUTTON RESET DISPLAY3 LAN1 LAN2 1 0 1 CFAST 12~40V DC IN COM3 COM1 ANTENNA DC IN CARD 10101 +12~24V +12V ANTENNA COM4 SLOT COM2 LAN1 LAN2 EAR-PHONE...
  • Page 9 FabiaTech Corporation c. FX5637S2/S2-i3/S2-i5 ANTENNA DIGITAL I/O CFAST DISPLAY2 POWER BUTTON RESET DISPLAY3 LAN1 LAN2 1 0 1 CFAST 12~40V DC IN COM3 COM1 ANTENNA DC IN CARD 10101 +12~24V +12V ANTENNA COM4 SLOT COM2 LAN1 LAN2 EAR-PHONE...

  • Page 10: Specifications

    FabiaTech Corporation Specifications Processor Board – 4th Generation Intel® Core™ i3/i5/i7 Processor (3M/6M Cache, Speed 1.6 GHz to 2.4 GHz (Intel® Turbo Boost Technology up 2.9Hz to 3.4GHz)) with 8GB DDR3L-RAM I/O Outlets – Two 10/100/1000 Base-T Ethernet LAN ports with RJ45 Two USB 3.0 (front side) and four USB 2.0 (rear side) ports...

  • Page 11: Packing List

    FabiaTech Corporation Packing List Upon receiving the package, verify the following things. Should any of the mentioned happens, contact us for immediate service. • Unpack and inspect the FX5637 package for possible damage that may occur during the delivery process.
  • Page 12 FabiaTech Corporation Optional Items for FX5637S2: • FB4730- 2 Slot (32bit) PCI riser card. (PN: 0153010001G) • FB4745- 1 Slot 32bit PCI + 1 slot PCIE riser card. (PN: 0120010004R) • FB4756- 2 Slot 32bit PCIE riser card. (PN: 0153010006G) •...

  • Page 13: Chapter 2 Hardware Installation

    FabiaTech Corporation Chapter 2 Hardware Installation This chapter introduces the system connectors & jumper settings, and guides you to apply them for field application. Before Installation Before you install the system, make sure you follow the following descriptions. 1. Before removing the cover, shut down the operation System and disconnect power switch to off and unplug AC-to DC Adapter cable.

  • Page 14: To Install Hardware- Remove The Bottom Cover

    FabiaTech Corporation To install Hardware- remove the bottom cover If you are installing following hardware items, you can remove the bottom cover. They include SATA 2.5" HDD inside, mini PCIE WLAN or GPRS module, PCI or PCIE Riser card kit, PCI or PCIE expansion card and DDR3L-RAM module to the FX5637.
  • Page 15 FabiaTech Corporation a2.FX5637S1- Use a cross-head screwdriver to remove ten screws that secure the bottom cover. a3.FX5637S2- Use a cross-head screwdriver to remove fourteen screws that secure the bottom cover.
  • Page 16 FabiaTech Corporation b. Installing CFAST Compact Flash Note: The CFAST Compact Flash socket supports CFAST Compact Flash Modules. c. Installing FX5637K1 Anti-Vibration kit (Option) – Fixed DDR3L RAM Module If you may extend additional fixed thermal pad and heat sink with 6 screws on FX5637, See as following figure.
  • Page 17 FabiaTech Corporation d. Installing PCIE Mini Card Module FX5637 supports 2 PCIE mini card sockets; you may extend additional PCIE mini card module and SIM card to system. Connect to the antenna cable from front and rear side antenna holes to GPRS or Wireless LAN module and install the SIM card for GPRS.
  • Page 18 FabiaTech Corporation e. Installing Hard Disk Screw up the Hard disk device to HDD metal frame and connect the SATA HDD cable and power cable. See following figures. Note: Be careful with the pin orientation when installing connectors and the cables.CN8 is used to connect a SATA 2.5"...
  • Page 19 FabiaTech Corporation f. Installing PCI or PCIE Riser Card kit (Optional) - for Expansion Card FX5637S1/S2 provides FB4705 kit- 1 slot PCI bus, FB4744 kit -1 slot PCIE bus, FB4745 kit- 1 slot PCI and 1 slot PCIE bus, FB4730 kit -2 slot PCI bus and FB4756 kit -2 slot PCIE bus.
  • Page 20 FabiaTech Corporation g. To installing Expansion Card – PCI/PCIE Card If you are installing Expansion PCI or PCIE hardware interface card, you can remove the bottom side cover. The following figure will guide you how to install PCI/PCIE interface card inside the FX5637 system and screw the L-Type Metal on the PCI/PCIE card Bracket and expansion card holder.
  • Page 21 FabiaTech Corporation g2. Installing PCI and PCIE Expansion Card- for FX5637S2 g2-1. Installing FX5637K3 Kit (Optional) - Expansion card holder FX5637K3 (OPTION)
  • Page 22 FabiaTech Corporation h. Installing the FX5636K1 –Wall Mounting Please refer to the following figure for installing the FX5637x with universal fixers. h1.FX5637 h2.FX5637S1...
  • Page 23 FabiaTech Corporation h3.FX5637S2...

  • Page 24: Led Indicators (On The Front Panel)

    FabiaTech Corporation LED Indicators (On the Front Panel) The Power Button and HDD LED have two distinctive statuses: Off for inactivity and blinking light for active operation. And the 2 LED’s for LAN ports. The LAN1 and LAN2 LED’s (Green) indicate on-line/access status of LAN1 and LAN2 respectively.
  • Page 25 FabiaTech Corporation 1. A VGA (CRT) connector is provided for VGA signals. DB15 Signal Green Blue Hsync Vsync DDC Data DDC Clock 5 & 10 Digital Ground 6,7,8 Analog Ground Others Not Used Connecting the Display2 (HD) and Display3 (Display port)
  • Page 26 FabiaTech Corporation Connecting the LAN ports The RJ45 connector with 2 LED’s for LAN. The right side LED (orange) indicates data is being accessed and the left side LED (green) indicates on-line status. (On indicates on-line and off indicates off-line) The following lists the pin assignment of RJ45.
  • Page 27 FabiaTech Corporation Digital I/O Connector The system provides 2-in and 2-out isolated digital I/O. Output port is an open collector; you need external voltage to support Digital (+) and digital (-) connectors. D I/O DI/O Signal Bit Location DI-1 Digital-IN1...

  • Page 28: Connecting The Dc Power And Power Button

    FabiaTech Corporation Connecting the DC Power and Power Button Power is supplied through an external AC/DC power adapter or power DC In. Take reference to the technical specification section for information about AC/DC power input voltage. See following figure. DC-Power Jack: Plug External AC/DC power adapter into DC-jack (2) plug the cable into hole (1), then pull up the end of the cable (3).

  • Page 29: Internal Connector And Jumper Setting

    FabiaTech Corporation Internal Connector and Jumper Setting The COM1 and COM2 are designed for multiple proposes. Using JP6 (COM1) or JP5 (COM2) is to select RS485 terminator resistor. JP3 and JP4 are used to select 3VSB /3.3V voltage with PCIE mini card module (See a PCIE mini card module specification.) JP1 is used to clear CMOS data, and other connectors are reserved...
  • Page 30 FabiaTech Corporation c. JP3/JP4: Select 3VSB/3.3V Voltage for PCIE Mini Card Module When installing the PCIE Mini card module, if the card doesn’t work properly (See a PCIE module card specification pin-24 3.3VAUX.), you can select 3VSB/3.3V voltage. (Defaulted 2, 3 closed.) JP3/JP4 3.3V StandBy/3.3VSB...

  • Page 31: Chapter 3 Bios Setup

    FabiaTech Corporation Chapter 3 BIOS Setup This chapter describes the BIOS setup. Overview BIOS are program located on a Flash memory chip on a circuit board. It is used to initialize and set up the I/O peripherals and interface cards of the system, which includes time, date, hard disk drive, and connected devices such as the video display, diskette drive, USB device, and the USB keyboard.

  • Page 32: Boot Manager Setup

    FabiaTech Corporation Press “ESC” or “Delete” key enter to BIOS Setup screen Boot Manager Setup Use this screen to specify the order in which the system checks for the device to boot from. To access this screen, select Boot Option Menu on the Boot Manager...

  • Page 33: Device Manager Setup

    FabiaTech Corporation Device Manager Setup You can use this screen to select options for the Devices List Configuration. Device Manager is a Super I/O chipset on the system board that controls the basic serial port functions, and hardware monitor.
  • Page 34 FabiaTech Corporation First Super IO Configuration This section describes the function of First Super I/O (WinBound83627) settings. Serial Port 1/2 This item allows users to enable and disable Serial Port 1/2(COM1/2). If set to Auto, is EFI/OS chooses configuration. Available Options: Disabled, Enabled and Auto...
  • Page 35 FabiaTech Corporation COM Port 1/2 Select Function These fields item can select RS-232, RS-422 and RS-485 of select port 1/2. Available Options: RS-232, RS-422 and RS485 Default setting: RS-232 Hardware Monitor On the Hardware Monitor screen, you can monitor the CPU temperature, CPU...
  • Page 36 FabiaTech Corporation Second Super IO Configuration This section describes the function of Super I/O FINTEK81216 settings. Serial Port 3/4 This item allows users to enable and disable Serial Port 3/4(COM3/4). If set to Auto, is EFI/OS chooses configuration. Available Options: Disabled, Enabled and Auto...

  • Page 37: Scu Setup

    FabiaTech Corporation SCU Setup On the menu, you can perform the following functions 1. Main 2. Advanced Boot Configuration Peripheral Configuration SATA Configuration Thermal Configuration Video Configuration USB Configuration Chipset Configuration PCI Configuration Console Configuration Chipset PCIE Controller 3. Security...

  • Page 38: Keyboard Convention

    FabiaTech Corporation Exit Saving Changes: Exit system setup after saving the changes.F10 key can be used for this operation. Save Change Without Exit: Save changes and without exiting system. Exit Discarding Changes: Exit system setup without saving any changes. ESC key can be used for this operation.

  • Page 39: Main Setup

    FabiaTech Corporation Main Setup This section describes basic system hardware configuration, CPU information, system clock setup and BIOS version information. If the CPU board is already installed in a working system, you will not need to select this option anymore.

  • Page 40: Advanced Setup

    FabiaTech Corporation Advanced Setup Select the Advanced tab from the setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Boot Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...

  • Page 41: Boot Configuration

    FabiaTech Corporation Boot Configuration Boot Up Num-Lock This field is used to activate the Num Lock function upon system boot. If the setting is on, after a boot, the Num Lock light is lit, and user can use the number key.

  • Page 42: Peripheral Configuration

    FabiaTech Corporation Peripheral Configuration This section describes the function of peripheral settings. Azalia Controller This field specifies the internal Azalia codec Control. Available Options: Auto, Enabled and Disabled Default setting: Auto...

  • Page 43: Sata Configuration

    FabiaTech Corporation SATA Configuration You can use this screen to select options for the SATA Configuration Settings. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 44 FabiaTech Corporation SATA Port0/1 Hot plug The system SATA HDD corresponding SATA port 0 hot plugs, this item allows users to enable or disable SATA port 0. Available Options: Disabled, and Enabled Default setting: Disabled Spin-Up Device The item supports staggered Spin-Up (SSS) in AHCI Host Capability register Bit 27.

  • Page 45: Video Configuration

    FabiaTech Corporation Video Configuration You can use this screen to select options for the video Configuration. Use the up and down <Arrow> keys to select an item. Use the <Plus> and <Minus> keys to change the value of the selected option.
  • Page 46 FabiaTech Corporation Internal Graphics Internal Graphics Device This field is select internal graphics controller device to Enabled or Disabled. Available Options: Enabled, Disabled, and Auto Default setting: Auto IGD – Aperture Size This field specifies the system memory size that can be used by the Internal Graphics Device (IGD).
  • Page 47 FabiaTech Corporation Available Options: 0MB, 32MB, 64MB, 96MB, 128MB, 160MB, 192MB, 224MB, 256MB, 288MB, 320MB, 352MB, 384MB, 416MB, 448MB, 480MB, 512MB, and 1024MB Default setting: 32 MB IGD – DVMT Size This field specifies allows you to select the maximum amount of graphics memory of DVMT 5.0 to be shared with the system memory.

  • Page 48: Usb Configuration

    FabiaTech Corporation USB Configuration You can use this screen to select options for the USB Configuration. USB BIOS Support The USB BIOS Support refers to the USB mouse, USB keyboard and USB storage support. Normally if this option is not enabled; any attached USB mouse or USB keyboard will not become available until a USB compatible operating system is fully booted with all USB drivers loaded.
  • Page 49 FabiaTech Corporation XHCI The item XHCI (eXtensible Host Controller Interface) a workaround for specification for Universal Serial Bus 3.0 support. Available Options: Disabled, Auto, Smart Auto, and Enabled Default setting: Disabled...

  • Page 50: Chipset Configuration

    FabiaTech Corporation Chipset Configuration VT-d The Item is Check to enable VT-d function on MCH. Available Options: Disabled, and Enabled Default setting: Enabled After G3 On This field is specify what state to go to when power is re-applied after power failure (G3 State).The states S0(G0) is working of power state, the states S5(G2) is soft off of...
  • Page 51 FabiaTech Corporation Max TOLUD This field is Max value of TOLUD; Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. Available Options: Dynamic, 1GB, 1.25GB, 1.5GB, 1.75GB, 2GB, 2.25GB, 2.5GB, 2.75GB, 3GB, and 3.25GB...

  • Page 52: Console Redirection Setup

    FabiaTech Corporation Console Redirection Setup This option turns on Console Redirection Setup for remote access support in the BIOS and is the default setting. The console remote access feature requires the use of the serial port connector located at the back side of the system.
  • Page 53 FabiaTech Corporation Available Options: COM_1, COM_2, COM_3, COM_4, PCI Device, and All Device Ports. Default setting: COM_1 Terminal Type This field is selecting the target terminal type. Available Options: VT100, vt100+, VT-UTFB, and PC_ANS1 Default setting: VT100 Baud Rate This field is select Serial ports can use baud rate. Just keep in mind that speed must match terminal setting.
  • Page 54 FabiaTech Corporation C (Console).R (Redirection) After Post These fields is select console redirection is active during post and during boot loader or always active or off active. (Some OSS may not work if set to Always) Available Options: Yes, and No...

  • Page 55: Chipset Pcie Controller

    FabiaTech Corporation Chipset PCIE Controller You can use this screen to select options for the PCIE controller Configuration. PCIe LAN1/LAN2 Controller This field specifies the Enabled or Disable of the onboard LAN1 and LAN2 chip. Available Options: Disabled, Enabled Default setting: Enabled...

  • Page 56: Security Setup

    FabiaTech Corporation Security setup There are two security passwords: Supervisor and User. Supervisor a privileged person that can change the User password from the BIOS, According to the default setting, both access passwords are not set up and are only valid after you set the password from the BIOS.
  • Page 57 FabiaTech Corporation 5. Select the Disabled or Enabled. Enabled: System will ask input password on post time. Disabled: System will ask input password on post time. When go to BIOS setup. 6. Point to Save Settings and Exit and press Enter. (or Press F10) 7.

  • Page 58: Power Setup

    FabiaTech Corporation Power Setup The Power menu allows user to set or control various parameters on power manager, and sleep states. Wake on LAN This item is can select Enabled to integrated LAN to wake up the system. Available options: Enabled, Disabled...

  • Page 59: Advanced Cpu Controller

    FabiaTech Corporation Advanced CPU Controller You can use this screen to select options for the CPU controller Configuration. Hardware Prefetcher This field specifies the Enabled or Disable to turn on/turn off the MLC (Mid Level Cache, L2 Cache) streamer prefetcher.
  • Page 60 FabiaTech Corporation HT Support This field specifies can select Auto or Disabled of Hyper-Threading. Available Options: Disabled, and Auto Default setting: Auto Excute Disable Bit This field specifies is XD can prevent certain classes of malicious buffer overflow attacks when combined with supporting OS.
  • Page 61 FabiaTech Corporation Config TDP Configurations You can use this screen to select options for the CPU controller Configuration. Configurable TDP Boot Mode This field specifies is Configure TDP Mode as Nominal / Up / Down for windows OS. Available Options: Norminal, Up, and Down...
  • Page 62 FabiaTech Corporation Custom Configurable TDP Setting Custom ConfigTDP Count This field specifies is Configure the number of custom ConfigTDP levels required. Note: this must be 1 if Configurable TDP Lock is enabled. Available Options: 1, and 0 Default setting: 1...
  • Page 63 FabiaTech Corporation Custom Setting 0 Long Term Power Limit This field specifies is Long Term Power Limit (aka Power Limit 1) value in Watts. XE SKU: any value can be programmed. Overclocking SKU: Value must be between Max and Min Power Limits. Other SKUs: This Value must be between Min Power Limit and TDP Limit.

  • Page 64: Boot Setup

    FabiaTech Corporation Boot Setup Select the Boot tab from the setup screen to enter the Boot BIOS Setup screen. You can select any of the items in the left frame of the screen, such as Legacy, to go to the sub menu for that item. You can display a Boot BIOS Setup option by highlighting it using the <Arrow>...
  • Page 65 FabiaTech Corporation Available Options: Disabled, and Enabled Default setting: Disabled Network Stack This field specifies the PXE boot ROM of the onboard LAN chip. Available Options: Disabled, Enabled Default setting: Disabled Add Boot Options This field specifies the position in boot order for shell, network and removable.

  • Page 66: Legacy > Boot Device Priority

    FabiaTech Corporation Legacy > Boot Device Priority Use this screen to specify the order in which the system checks for the device to boot from. To access this screen, select Normal or Advance of Normal Boot Menu on the Boot Setup screen.

  • Page 67: Chapter 4 Software Installation

    FabiaTech Corporation Chapter 4 Software Installation The enclosed DVD diskette includes VGA, Audio, System, USB and LAN driver. To install and configure you FX5637 system, you need to perform the following steps. System Driver Windows 7/8/8.1 X86/X64- System Driver Installs Intel QM87 system Chipset, the driver include the Core PCI, ISAPNP, PCIE, USB and IDE/SATA Device Drive.

  • Page 68: Vga Driver

    FabiaTech Corporation VGA Driver WIN7/8/8.1 X86/X64 Driver Step 1: To install the VGA driver, insert the DVD ROM into the DVD ROM device, and enter DRIVER>VGA>HASWELL >WIN32 or >WIN64. Step 2: Execute Setup.exe file. Step 3: The screen shows the SETUP type. Press any key to enter the main menu.

  • Page 69: Audio Driver

    FabiaTech Corporation Audio Driver WIN7/8/8.1 X86/X64 Driver Step 1: To install the AUDIO driver, insert the CD ROM into the CD ROM device, and enter DRIVER>AUDIO>ALC888>WIN8 > WIN32, or WIN64. Step 2: Execute 32bit_Win7_Win8_Win81_R273.exe file. Step 3: The screen shows the SETUP type. Press any key to enter the main menu.

  • Page 70: Watchdog Timer

    FabiaTech Corporation Watchdog Timer This section describes how to use the Watchdog Timer, including disabled, enabled, and trigger functions. The system is equipped with a programmable time-out period watchdog timer. You can use your own program to enable the watchdog timer. Once you have enabled the watchdog timer, the program should trigger the I/O every time before the timer times out.

  • Page 71: Watchdog Timer Setting

    FabiaTech Corporation Watchdog Timer Setting The watchdog timer is a circuit that may be used from your program software to detect system crashes or hang-ups. The watchdog timer is automatically disabled after reset. Once you have enabled the watchdog timer, your program must trigger the watchdog timer every time before it times out.

  • Page 72: Watchdog Timer Enabled

    FabiaTech Corporation Watchdog Timer Enabled To enable the watchdog timer, you have to output a byte of timer factor to the watchdog register whose address is 2Eh and data port is 2fH. The following is an Assemble program, which demonstrates how to enable the watchdog timer and set the time-out period at 28 seconds.

  • Page 73: Watchdog Timer Disabled

    FabiaTech Corporation Watchdog Timer Disabled To disable the watchdog timer, simply write a 00H to the watchdog register. ;------------------------------------------------------------------------------------------ ; Enter the extended function mode, interruptible double-write ;------------------------------------------------------------------------------------------ dx,2eh ; Enter to extended function mode al,87h dx,al dx,al ;------------------------------------------------------------------------------------------------------------------------ ; Logical device 8, configuration register CRF5 Bit 3(Sec./Min.), CRF6 Bit 0~7 (Count.) ;------------------------------------------------------------------------------------------------------------------------...

  • Page 74: Ttl I/O (Di-0/Di-1, Do-0/Do-1) Programming

    FabiaTech Corporation TTL I/O (DI-0/DI-1, DO-0/DO-1) programming The following is an Assembly program, which demonstrates how to set the GPIO (DI-0/DI-1, DO-0/DO-1) type and how to read and write values. ;------------------------------------------------------------------------------------------ ; Enter the extended function mode, interruptible double-write ;------------------------------------------------------------------------------------------ dx, 2eh ;...
  • Page 75 FabiaTech Corporation ; Exit extended function mode ;------------------------------------------ dx,2eh al,aah dx,al...
  • Page 76 FabiaTech Corporation...

  • Page 77: Chapter 5 Technical Reference

    FabiaTech Corporation Chapter 5 Technical Reference This section provider description the hardware that may occur when you operate the system, and also gives you the suggestions on solving the problems. Topic include: Technical Reference FX5637X Dimension Technical Reference Physical and Environmental Temperature: Operating -20°C ~ 50°C...

  • Page 78: I/O Port Address Map

    FabiaTech Corporation I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses, which also becomes the identity of the device. There is a total of 1K-port address space available. The following table lists the I/O port addresses used on the Industrial CPU Card.

  • Page 79: Interrupt Request Lines (Irq)

    FabiaTech Corporation Interrupt Request Lines (IRQ) There are a total of 15 IRQ lines available on the Industrial CPU Card. Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on the Industrial CPU Card.

  • Page 80: Serial Ports

    FabiaTech Corporation Serial Ports The ACEs (Asynchronous Communication Elements ACE1 to ACE2) are used to convert parallel data to a serial format on the transmit side and convert serial data to parallel on the receiver side. The serial format, in order of transmission and reception, is a start bit, followed by five to eight data bits, a parity bit (if programmed) and one, one and half (five-bit format only) or two stop bits.
  • Page 81 FabiaTech Corporation Bit 2: Enable Receiver Line Status Interrupt (ELSI) Bit 3: Enable MODEM Status Interrupt (EDSSI) Bit 4: Must be 0 Bit 5: Must be 0 Bit 6: Must be 0 Bit 7: Must be 0 Interrupt Identification Register (IIR) Bit 0: “0”...
  • Page 82 FabiaTech Corporation Bit 5: Stick Parity Bit 6: Set Break Bit 7: Divisor Latch Access Bit (DLAB) MODEM Control Register (MCR) Bit 0: Data Terminal Ready (DTR) Bit 1: Request to Send (RTS) Bit 2: Out 1 (OUT 1) Bit 3: Out 2 (OUT 2)
  • Page 83 FabiaTech Corporation Bit 4: Clear to Send (CTS) Bit 5: Data Set Ready (DSR) Bit 6: Ring Indicator (RI) Bit 7: Received Line Signal Detect (RSLD) Divisor Latch (LS, MS) Bit 0: Bit 0 Bit 8 Bit 1: Bit 1...

  • Page 84: Appendix

    FabiaTech Corporation Appendix Dimension a. FX5637...
  • Page 85 FabiaTech Corporation a-1. FX5637 with FX5636k1 universal fixers...
  • Page 86 FabiaTech Corporation b. FX5637S1...
  • Page 87 FabiaTech Corporation b-1. FX5637S1 with FX5636k1 universal fixers...
  • Page 88 FabiaTech Corporation c. FX5637S2...
  • Page 89 FabiaTech Corporation c-1. FX5637S2 with FX5636k1 universal fixers...
