This Operator's Manual is an integral part of the safe operation of this machine and must
be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety
and Operation Instructions contained in this manual before operating the equipment. C01-
Cover
®
BUSH HOG
2501 Griffin Ave.
Selma, AL 36703
334-874-2700
www.bushhog.com
OPERATOR'S MANUAL
© 2019 Alamo Group Inc.
Model CLR
Landscape Rake
Part No. 50058120
$0.00
Advertisement
Table of Contents
Related Manuals for Bush Hog CLR
Summary of Contents for Bush Hog CLR
- Page 1 Model CLR Landscape Rake Published 09/19 Part No. 50058120 OPERATOR’S MANUAL This Operator's Manual is an integral part of the safe operation of this machine and must be maintained with the unit at all times. READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment.
- Page 2 BEFORE YOU START! Read the safety messages on the implement and shown in your manual. Observe the rules of safety and common sense! For future reference, record your Bush Hog product model number and serial number. Dealer Telephone Model Number...
-
Page 3: Table Of Contents
It is the Retail Customer’s responsibility to deliver the product to the authorized Bush Hog Dealer, from whom he purchased it, for service or replacement of defective parts which are covered by warranty. -
Page 4: Warranty
2. If the unit has been subjected to misapplication, abuse, misuse, negligence, fire or other accident. 3. If parts not made or supplied by Bush Hog have been used in connection with the unit, if, in the sole judge- ment of Bush Hog such use affects its performance, stability or reliability. -
Page 5: Dealer Preparation Check List
DEALER PREPARATION CHECK LIST LANDSCAPE RAKE BEFORE DELIVERING MACHINE — The following check list should be completed. Use the Operator’s Manual as a guide. 1. Assembly completed. 2. All fasteners torqued to specifications given in Torque Chart. 3. All decals in place and readable. (See decal page.) 4. -
Page 6: Safety Precautions
IMPORTANT SAFETY PRECAUTIONS This symbol is used to call attention to safe- ty precautions that should be followed by the operator to avoid accidents. When you see this symbol, carefully read the message that follows and heed its advice. Failure to comply with safety precautions could result in serious bodily injury. -
Page 7: Laws And Regulations
IMPORTANT FEDERAL LAWS AND REGULATIONS* CONCERNING EMPLOYERS, EMPLOYEES AND OPERATIONS. *(This section is intended to explain in broad terms the concept and effect of the following federal laws and regulations. It is not intended as a legal interpretation of the laws and should not be considered as such). U.S. -
Page 8: Specifications
SPECIFICATIONS Figure 1 CLR LRC 48 LRC 60 Rake Width 48” 60” HItch Type Category I Category I Tractor HP 24 (Maximum) 24 (Maximum) Rake Pivot 18° & 36° Frt. & Rr. 18° & 36° Frt. & Rr. Mast Pivot King Pin 1”... -
Page 9: Operation
FIELD ADJUSTMENTS CAUTION CLR SERIES - To change the operating angle, WHEN EQUIPMENT IS TRANSPORTED, remove the index pin and align the frame adjusting USE NECESSARY DEVICES REQUIRED BY hole with one of the five angle settings by pivoting LOCAL REGULATIONS FOR ADEQUATE the rake. -
Page 10: Safety Decals
To promote safe operation, Bush Hog supplies safety decals on all products manufactured. Because damages can occur to safety decals either through shipment, use or reconditioning, Bush Hog will, upon request, provide safety decals for any of our products in the eld at no charge. Contact your authorized Bush Hog dealer for more information. -
Page 11: Torque Specifications
TORQUE SPECIFICATIONS Proper toque for American fasteners used on Bush Hog equipment. Recommended Torque in Foot Pounds (Newton Meters).* AMERICAN B O L T D IA M E T E R Bolt Head Markings W R E N C H (IN .) “... - Page 12 P.O. Box 1039 Selma, AL 36702-1039 Telephone (334) 874-2700 www.bushhog.com...
