Settings Page Selections:
From the Settings page screen you can select one of the following selections:
Identity– This page allows the user to enter information that is necessary to identify
the meter. It gives an identity to a particular M66X. Each M66X should have
different information entered for its identity.
Input – This page allows for the selection of wiring configuration, setup of CT and
PT ratios, demand intervals, and TDD denominator. If option ordered, it also allows
setup of parameters for the KYZ pulse output.
Network – This page allows the user to change the network configuration settings
for IP address, gateway and router address.
Serial Port – This page allows user configuration for the serial port settings. Note
that if no serial port is ordered this setting won't appear.
Protocol – This page allows user configuration of the protocols – DNP or Modbus
IEC61850 – This page allows user to download and upload ICD and CID files
Time Sync – This page allows you to set the 60 Series to the PC time, a user-
defined time, or to setup SNTP Time Synchronization
Screen Enable - Allows the screens shown on the M660 display (front panel) to be
enabled or disabled by the user.
Custom Screens – Allows the user to set up custom display screens if the standard
screens don't meet their needs.
Load/Store Settings – This page allows you to save and retrieve settings for the
M66X meter
Password Security – This page allows the user to set a password and to enable or
disable access to front display configuration (M660)
Firmware Upload – This page allows the user an interface to browse for or type in
the location on their PC of new firmware for purposes of uploading to the unit.
Trend Recorder – This page allows for configuring the trend recorder settings.
EtherNet/IP Device Configuration – Enables or disables this capability if option is
purchased and allows for setting an Encapsulation Inactivity Timeout. Please refer
to section 4 of the PowerPlex II and 60 Series EtherNet/IP Protocol Manual,
ML0048 for more information.
