Product Specification (Elite 5 PRO)
Type of laser:
Guaranteed optical output: >5,100mW
Suitable for:
Control signal:
Scanning system:
Scan angle:
Safety:
Weight:
Package Includes:
R | G | B [mw]:
Beam size [mm]:
Beam divergence:
Modulation:
Power requirements:
Consumption:
Operation temperature:
Ingress rating:
System features:
Laser safety features:
Notice:
Dimensions [cm]:
full-color, semiconductor diode laser system
medium to large sized indoor / outdoor laser shows and laser graphic
displays
Pangolin FB4 - Ethernet, ArtNet, DMX, ILDA out| PC, Lighting
Console, Autoplay
35,000 points per second @ 8°
50°
fully complies with the latest EN 60825-1, and FDA regulations
8 kg
Heavy duty flight case, power cord, 10m ethernet (rj45) signal cable,
E-STOP box with 10m cable, set of 4 safety keys, remote interlock
bypass, Pangolin QuickShow laser control and creation software is
available for download..
1200 | 1700 | 2400
3 x 4
<1mrad [full angle]
Analog 100 kHz
100-230V/50Hz
max. 150W
10-40 °C
IP20
All the adjustments such as power output of each color, X & Y axes
invert, X & Y size and position, etc. Scanning system protection, daisy
chain of emergency STOP signal for multiple system "one-hit"
operation, internal fuse (same as on 2w and 3w).
Keyed interlock, emission delay, magnetic interlock, scan-fail safety,
mechanical shutter, adjustable aperture masking plate.
*Due to Advanced Optical Correction technology used in our laser
systems the optical power output of each laser color within the system
may slightly differ from the specification of respective laser module(s)
installed. This does not affect the total guaranteed power output.
Length: 255
Width: 233
Height: 168
