MODEL SPECIFICATIONS:

Product Specification (Elite 2 PRO)
Type of laser:
Guaranteed optical output:
Suitable for:
Control signal:
Scanning system:
Scan angle:
Safety:
Weight:
Package Includes:
R | G | B [mw]:
Beam size [mm]:
Beam divergence:
Modulation:
Power requirements:
Consumption:
Operation temperature:
Ingress rating:
System features:
Laser safety features:
Notice:
Dimensions [cm]:
full-colour, semiconductor diode laser system
2,100mW
small to medium indoor / outdoor laser shows and laser graphic
displays
Pangolin FB4 - Ethernet, ArtNet, DMX, ILDA out | PC, Lighting
Console, Autoplay
35,000 points per second @ 8°
50°
fully complies with the latest EN 60825-1, and FDA regulations
8 kg
Heavy duty flight case, power cord, 10m ethernet (rj45) signal cable,
E-STOP box with 10m cable, set of 4 safety keys, remote interlock
bypass, Pangolin QuickShow laser control and creation software is
available for download.
500 | 500 | 1000
5 x 3
<1mrad [full angle]
Analog 100 kHz
100-230V/50Hz
max. 150W
10-40 °C
IP 20
All the adjustments such as power output of each colour, X & Y axes
invert, X & Y size and position, etc. are managed by inbuilt FB4
control system. Scanning system protection, daisy chain of
emergency STOP signal for multiple system "one-hit" operation,
internal fuse.
Keyed interlock, emission delay, magnetic interlock, scan-fail safety,
mechanical shutter, adjustable aperture masking plate.
*Due to Advanced Optical Correction technology used in our laser
systems the optical power output of each laser colour within the
system may slightly differ from the specification of respective laser
module(s) installed. This does not affect the total guaranteed power
output.
Length: 238
Width: 246
Height: 175
