Operating Instructions
Levelflex FMP50
Guided Level-Radar
Level measurement in liquids
BA01051F/00/EN/02.12
71206420
Valid as of version
01.00.zz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Levelflex FMP50 and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Levelflex FMP50

Summary of Contents for Endress+Hauser Levelflex FMP50

  • Page 1 Operating Instructions Levelflex FMP50 Guided Level-Radar Level measurement in liquids BA01051F/00/EN/02.12 71206420 Valid as of version 01.00.zz...

  • Page 3: Table Of Contents

    Levelflex FMP50 Table of contents Table of contents 6.2.4 Notes on the process connection ..28 Important document information ..6 6.2.5 Securing the probe ....29 About this document .
  • Page 4 11.8.4 Transmission of the event meassages to the Index tables of Endress+Hauser parameters ..63 bus ......90 9.6.1 Setup Transducer Block .
  • Page 5 Levelflex FMP50 Table of contents Description of device parameters (operating menu) ....114 19.1 "Display/operation" menu ....115 19.2 "Setup"...

  • Page 6: Important Document Information

    The document types listed are available: • On the CD supplied with the device • In the Download Area of the Endress+Hauser Internet site: www.endress.com ® Download 1.1.3 Safety Instructions (XA) for Levelflex FMP50 Depending on the approval, the following Safety Instructions (XA) are supplied with the device.

  • Page 7: Document Conventions

    Levelflex FMP50 Important document information Feature Approval Safety Instructions Safety Instructions HART PROFIBUS FOUNDATION Fieldbus CSA C/US IS Cl.I,II,III Div.1 Gr.A-G, NI Cl.1 Div.2, Ex ia XA00530F XA00571F CSA C/US XP Cl.I,II,III Div.1 Gr.A-G, NI Cl.1 Div.2, Ex d XA00529F XA00570F FM IS Cl.I Div.1 Gr.

  • Page 8: Electrical Symbols

    Important document information Levelflex FMP50 1.2.2 Electrical symbols Symbol Meaning Direct current A terminal to which DC voltage is applied or through which direct current flows. A0011197 Alternating current A terminal to which alternating voltage (sine-wave) is applied or through which alternating current flows.

  • Page 9: Symbols In Graphics

    Levelflex FMP50 Important document information Symbol Meaning Series of steps … Result of a sequence of actions à Help in the event of a problem A0013562 1.2.5 Symbols in graphics Symbol Meaning 1, 2, 3 ... Item numbers Series of steps …...

  • Page 10: Basic Safety Instructions

    The manufacturer is not liable for damage caused by improper or non-designated use. Verification for borderline cases: For special measured materials and cleaning agents, Endress+Hauser is glad to provide ► assistance in verifying the corrosion resistance of wetted materials, but does not accept any warranty or liability.

  • Page 11: Operational Safety

    It fulfills general safety requirements and legal requirements. It also conforms to the EC directives listed in the device-specific EC declaration of conformity. Endress+Hauser confirms this fact by applying the CE mark. Endress+Hauser...

  • Page 12: Product Description

    Product description Levelflex FMP50 Product description Product design 3.1.1 Compact device Levelflex A0013771 Design of the Levelflex å 1 Electronics housing Process connection (Thread) Rope probe End-of-probe weight Rod probe Endress+Hauser...

  • Page 13: Electronics Housing

    Levelflex FMP50 Product description 3.1.2 Electronics housing A0012422 Design of the electronics housing å 2 Electronics compartment cover Display module Main electronics module Cable glands (1 or 2, depending on instrument version) Nameplate I/O electronics module Terminals (pluggable spring terminals)
  • Page 14 Product description Levelflex FMP50 US Patents EP Patents 6.481.276 6.512.358 1 301 914 6.559.657 1 020 735 6.640.628 6.691.570 6.847.214 7.441.454 7.477.059 1 389 337 7.965.087 Endress+Hauser...

  • Page 15: 4 Incoming Acceptance And Product

    Levelflex FMP50 Incoming acceptance and product identification Incoming acceptance and product identification Incoming acceptance DELIVERY NOTE 1 = 2 A0013696 A0016870 Is the order code on the delivery note (1) identical to the order code on the product sticker (2)?

  • Page 16: Product Identification

    Are the CD-ROMs (product documentation, operating tool) and documentation present? If required (see nameplate): Are the Safety Instructions (XA) present? If one of the conditions does not comply, contact your Endress+Hauser distributor. Product identification The following options are available for identification of the measuring device: •...

  • Page 17: Nameplate

    Levelflex FMP50 Incoming acceptance and product identification 4.2.1 Nameplate 92 (3.62) Order code: Ser. no.: Ext. ord. cd.: LN = MWP: Lref = Mat.: DeviceID: Dev.Rev.: if modification see sep. label Date: mm (in) 19 18 17 16 A0010725 Nameplate of the Levelflex å...
  • Page 18 Incoming acceptance and product identification Levelflex FMP50 Approval: ATEX II 1/3G Ex ic(ia) IIC T6 ATEX II 3G Ex nA IIC T6 ATEX II 3G Ex ic IIC T6 ATEX II 1/3G Ex nA(ia) IIC T6 *ATEX II 1/2G Ex ia IIC T6, 1/2D Ex ia IIIC IP6x...
  • Page 19 Levelflex FMP50 Incoming acceptance and product identification Display, Operation: W/o, via communication SD02 4-line, push buttons + data backup function Special version, TSP-no. to be sepc. Housing: GT19 dual compartment, Plastics PBT GT20 dual compartment, Alu coated Special version, TSP-no. to be sepc.
  • Page 20 Incoming acceptance and product identification Levelflex FMP50 Additional Operation Language: Japanese Korean Czech Calibration: 5-point linearity protocol Special version, TSP-no. to be sepc. Service: (Multiple options can be selected) Customized parametrization HART Customized parametrization PA Customized parametrization FF W/o Tooling DVD (FieldCare setup) Special version, TSP-no.

  • Page 21: Storage, Transport

    Levelflex FMP50 Storage, Transport Storage, Transport Storage conditions • Permitted storage temperature: –40 to +80 °C (–40 to +176 °F) • Use the original packaging. Transport product to the measuring point WARNING Risk of injury if the hosuing breaks away! Transport the measuring device to the measuring point in its original packaging or at the ►...

  • Page 22: Mounting

    Mounting Levelflex FMP50 Mounting Mounting dimensions 6.1.1 Dimensions of the electronics housing 78 (3.07) 90 (3.54) A0015133 Housing GT19 (Plastics PBT); Dimensions in mm (in) å 4 90 (3.54) 78 (3.07) A0015134 Housing GT20 (Alu coated); Dimensions in mm (in) å...

  • Page 23: Dimensions Of The Mounting Bracket

    Levelflex FMP50 Mounting 6.1.2 Dimensions of the mounting bracket 122 (4.8) 140 (5.5) 175 (6.9) 158 (6.2) Ø 42 ... 60 mm (inch) (1-1/4 ... 2) A0014793 Mounting bracket for the electronics housing å 6 Wall mounting Pipe mounting For the "Sensor remote" device version (see feature 060 of the product structure), the mounting bracket is part of the delivery.

  • Page 24: Fmp50 : Dimensions Of Process Connection And Probe

    Mounting Levelflex FMP50 6.1.3 FMP50 : Dimensions of process connection and probe (4.8) = 100 (4) ø82.5 ø59.35 (ø3.25) (ø2.34) SW36 AF36 ¾ NPT¾ ø4 (ø0.16) ø8 (ø0.31) ø22 (ø0.87) mm (in) A0012644 Mounting bracket for probe design "Sensor remote" (Feature 600) Thread ISO228 G3/4 or ANSI MNPT3/4 (Feature 100) Rod probe 8mm or 1/3"...

  • Page 25: Mounting Requirements

    Levelflex FMP50 Mounting Mounting requirements 6.2.1 Suitable mounting position A0012606 Mounting distances • Distance (A) between wall and rod or rope probe: – for smooth metallic walls: > 50 mm (2") – for plastic walls: > 300 mm (12") mm to metallic parts outside the vessel –...

  • Page 26: Applications With Restricted Mounting

    Mounting Levelflex FMP50 When mounting the electronics housing into a recess (e.g. in a concrete ceiling), observe a minimum distance of 100 mm (4 inch) between the cover of the terminal compartment / electronics compartment and the wall. Otherwise the connection compartment / electronics compartment is not accessible after installation.

  • Page 27: Notes On The Mechanical Load Of The Probe

    Levelflex FMP50 Mounting 6.2.3 Notes on the mechanical load of the probe Tensile load limit of rope probes Sensor Feature 060 Probe Tensile load limit [kN] FMP50 LA, LB Rope 4mm (1/6") 316 Bending strength of rod probes Sensor Feature 060...

  • Page 28: Notes On The Process Connection

    Mounting Levelflex FMP50 Bending torque [M] on rod probes, diameter 8mm (1/3”) 20.0 18.0 16.0 14.0 12.0 10.0 v=0.5m/s v=0.7m/s v=1.0m/s Probe length [ ] in meters A0014182-EN 6.2.4 Notes on the process connection Probes are mounted to the process connection with threaded connections or flanges. If during this installation there is the danger that the probe end moves so much that it touches the tank floor or cone at times, the probe must, if necessary, be shortened and fixed down (®...

  • Page 29: Securing The Probe

    Levelflex FMP50 Mounting 6.2.5 Securing the probe Securing rope probes A0012609 Sag of the rope: ³ 1 cm per 1m of the probe length (0.12 inch per 1 ft of the probe length) Reliably grounded end of probe Reliably isolated end of probe Mounting and contact with a bolt Mounting kit isolated (®...

  • Page 30: Special Mounting Conditions

    NOTICE Welding may damage the main electronics module. Before welding: Ground the probe and dismount electronics. ► 6.2.6 Special mounting conditions Bypasses and stilling wells For information on bypass solutions from Endress+Hauser please contact your Endress +Hauser sales representative. Endress+Hauser...
  • Page 31 Levelflex FMP50 Mounting A0014129 Mounting in a stilling well Mounting in a bypass • Pipe diameter: > 40 mm (1.6") for rod probes • Rod probe installation can take place up to a diameter size of 100 mm. In the event of larger diameters, FMP51 with a coax probe is recommended.
  • Page 32 Mounting Levelflex FMP50 Underground tanks A0014142 Use FMP51 with a coax probe for nozzles with large diameters in order to avoid reflections at the nozzle wall. Installation at an angle A0014145 • For mechanical reasons, the probe should be installed as vertically as possible.
  • Page 33 Levelflex FMP50 Mounting Non-metallic vessels A0012527 Non-metallic vessel Metal sheet or metal flange To measure, Levelflex with a rod probe needs a metallic surface at the process connection. Therefore: Mount a metal sheet with a diameter of at least 200 mm (8") to the probe at the process connection.
  • Page 34 Mounting Levelflex FMP50 Mounting conditions: • The probe must be mounted directly to the tank wall (no open space) • A plastic half pipe with a diameter of approx. 200 mm (8"), or some other protective unit, must be affixed externally to the probe to prevent any influences on the measurement.
  • Page 35 Levelflex FMP50 Mounting Vessels with heat insulation If process temperatures are high, the device must be included in normal tank insulation to prevent the electronics heating up as a result of heat radiation or convection. The insulation may not exceed beyond the points labeled "MAX" in the drawings.

  • Page 36: Mounting The Device

    Mounting Levelflex FMP50 Mounting the device 6.3.1 Required mounting tools • For mounting thread 3/4": Hexagonal wrench 36 mm • To shorten rod or coax probes: Saw • To shorten rope probes: – Allen key AF 3 mm (for 4mm ropes) or AF 4 mm (for 6 mm ropes) –...

  • Page 37: Mounting The Device

    Levelflex FMP50 Mounting 4 / 6 mm 0.16 / 0.25 inch 5/15 Nm A0012453 1. Loosen the 3 Allen set screws using an Allen key AF3 (for 4mm ropes) or AF4 (for 6 mm ropes). Note: The set screws have got a clamping coating in order to prevent accidental loosening.

  • Page 38: Mounting The "Sensor Remote" Version

    Mounting Levelflex FMP50 • Tighten with the hexagonal nut only: – Thread 3/4": Hexagonal wrench 36 mm – Thread 1-1/2": Hexagonal wrench 55 mm • Maximum permissible torque: – Thread 3/4": 45 Nm – Thread 1-1/2": 450 Nm • Recommended torque when using the supplied aramid fibre seal and a process pressure of 40 bar (580 psi): –...
  • Page 39 Levelflex FMP50 Mounting CAUTION The plugs of the connection cable may be damaged by mechanical stress. Mount the probe and the electronics housing tightly before connecting the cable. ► Lay the cable such that it is not exposed to mechanical stress. Minimum bending radius: 100 ►...

  • Page 40: Turning The Transmitter Housing

    Mounting Levelflex FMP50 6 Nm 6 Nm = 100 mm (4”) = 100 mm (4”) 6 Nm 6 Nm A0014794 Connecting the cable. There are the following possibilities: å 10 Angled plug at the probe Angled plug at the electronics housing 6.3.5...

  • Page 41: Turning The Display Module

    Levelflex FMP50 Mounting 6.3.6 Turning the display module 3 mm A0013905 1. If present (i.e. for devices with Dust-Ex/DIP approval): Loosen the securing clamp of the electronics compartment cover using an Allen key. 2. Unscrew cover of the electronics compartment from the transmitter housing.

  • Page 42: Electrical Connection

    Electrical connection Levelflex FMP50 Electrical connection Connection options 7.1.1 PROFIBUS PA / FOUNDATION Fieldbus A0011341 Terminal assignment PROFIBUS PA / FOUNDATION Fieldbus å 11 Without integrated overvoltage protection With integrated overvoltage protection Cable screen: Observe cable specifications (® ä 43)

  • Page 43: Connection Examples For The Switch Output

    Connection options 7.2.1 Cable specification FOUNDATION Fieldbus • Endress+Hauser recommends using twisted, shielded two-wire cables. • Terminals for wire cross-sections: 0.5 to 2.5 mm (20 to 14 AWG) • Cable outer diameter: 5 to 9 mm (0.2 to 0.35 in) For further information on the cable specifications, see Operating Instructions BA00013S "FOUNDATION Fieldbus Overview", FOUNDATION Fieldbus Guideline and IEC 61158-2...

  • Page 44: Overvoltage Protection

    < 1.5 pF Nominal arrest impulse voltage (8/20 ms) 10 kA External overvoltage protection HAW562 or HAW569 from Endress+Hauser are suited as external overvoltage protection. For detailed information please refer to the following documents: • HAW562: TI01012K • HAW569: TI01013K Connection data 7.3.1...

  • Page 45: Connecting The Measuring Device

    Levelflex FMP50 Electrical connection Connecting the measuring device WARNING Explosion hazard! Comply with the relevant national standards. ► Observe the specifications in the Safety Instructions (XA). ► Only use the specified cable glands. ► Check whether the supply voltage matches the specifications on the nameplate.
  • Page 46 Electrical connection Levelflex FMP50 Connect the cable in accordance with the terminal assignment (® ä 42). 8. When using screened cable: Connect the cable screen to the ground terminal. 9. Screw the cover onto the connection compartment. 10. For instruments with safety pin for the lid: Adjust the safety pin so that its edge is over the edge of the display lid.

  • Page 47: Post-Connection Check

    Levelflex FMP50 Electrical connection Post-connection check Are cables or the device undamaged (visual inspection)? Do the cables comply with the requirements? Do the cables have adequate strain relief? Are all cable glands installed, firmly tightened and correctly sealed? Does the supply voltage match the specifications on the transmitter nameplate? Is the terminal assignment correct (®...

  • Page 48: Operating Options

    å 14 Display module SD02, push buttons; cover must be open for operation Operating options via CDI interface (= Endress+Hauser Common Data Interface) 2.1 Computer with operating tool (FieldCare) 2.2 Commubox FXA291, connected to the CDI interface of the device 8.1.2...
  • Page 49 Levelflex FMP50 Operating options FF-HSE FF-H1 ENDRESS + HAUSER – FF-H1 A0017188 FOUNDATION Fieldbus system architecture with associated components å 16 Industrial network High Speed Ethernet FOUNDATION Fieldbus-H1 Linking Device FF-HSE/FF-H1 Bus Power Supply Safety Barrier Bus Terminator FFblue Bluetooth modem...

  • Page 50: The Operating Menu

    Operating options Levelflex FMP50 The operating menu 8.2.1 Structure Language Display/operation Parameter 1 Parameter 2 Parameter N Setup Setup parameter 1 Setup parameter 2 Setup parameter N Enter access code Advanced setup Parameter 1 Parameter N Submenu 1 Submenu N...

  • Page 51: Submenus And User Roles

    Levelflex FMP50 Operating options 8.2.2 Submenus and user roles The submenus are designed for different user roles. A user role is defined by typical tasks within the lifecycle of the device. User role Typical tasks Submenu Content/Meaning Operator Tasks in the ongoing process: "Language"...
  • Page 52 Operating options Levelflex FMP50 WP SIM DISPL Spare part: FMP52X-AB 02.01.03 Dev_R ex works SW update #1 SW update #2 A0013132 1. Unscrew the lid from the compartment for the display and operating module. 2. Slightly turn the display and operating module to remove it from the compartment.

  • Page 53: Display And Operating Module

    Levelflex FMP50 Operating options Display and operating module 8.3.1 Display appearance User ABC_ DEFG HIJK LMNO PQRS TUVW A0012635 Appearance of the display and operation module for on-site operation å 18 Measured value display (1 value max. size) 1.1 Header containing tag and error symbol (if an error is active) 1.2 Measured value symbols...
  • Page 54 Operating options Levelflex FMP50 Display symbols for the submenus Symbol Meaning Display/operation Is displayed: • in the main menu next to the selection "Display/operation" A0011975 • in the header, if you are in the "Display/operation" menu Setup Is displayed: • in the main menu next to the selection "Setup"...
  • Page 55 Levelflex FMP50 Operating options Measured value symbols Symbol Meaning Measured values Level A0011995 Distance A0011996 Current output A0011998 Measured current A0011999 Terminal voltage A0012106 Temperature of the electronics or the sensor A0012104 Measuring channels Measuring channel 1 A0012000 Measuring channel 2...

  • Page 56: Operating Elements

    Operating options Levelflex FMP50 8.3.2 Operating elements Meaning Minus key For menu, submenu Moves the selection bar upwards in a picklist. A0013969 For text and numeric editor In the input mask, moves the selection bar to the left (backwards). Plus key For menu, submenu Moves the selection bar downwards in a picklist.

  • Page 57: Entering Numbers And Text

    Levelflex FMP50 Operating options 8.3.3 Entering numbers and text Numeric editor Text editor A0013941 A0013999 Editing view Display area of the entered values Input mask Operating elements Input mask The following input symbols are available in the input mask of the numeric and text editor:...
  • Page 58 Operating options Levelflex FMP50 Confirms selection. A0013985 Switches to the selection of the correction tools. A0013987 Exits the input without applying the changes. A0013986 Clears all entered characters. A0014040 Operating symbols in the numeric editor A0016621 A0013985 A0013986 Confirms selection.

  • Page 59: Envelope Curve On The Display And Operating Module

    Levelflex FMP50 Operating options 8.3.4 Envelope curve on the display and operating module In order to assess the measuring signal, the envelope curve and - if a mapping has been recorded - the mapping curve can be displayed: (2s) A0014277...

  • Page 60: Integration Into A Foundation

    Integration into a FOUNDATION Fieldbus network Levelflex FMP50 Integration into a FOUNDATION Fieldbus network Device Description (DD) You require the following to configure a device and integrate it into an FF network: • An FF configuration program • The Cff file (Common File Format: *.cff) •...

  • Page 61: Block Model

    Levelflex FMP50 Integration into a FOUNDATION Fieldbus network – EH_Levelflex_xxxxxxxxxx – RESOURCE_xxxxxxxxxxx (RB2) SETUP_ xxxxxxxxxxx (TRDSUP) ADV_SETUP_ xxxxxxxxxxx (TRDASUP) DISPLAY_ xxxxxxxxxxx (TRDDISP) DIAGNOSTIC_ xxxxxxxxxxx (TRDDIAG) EXPERT_CONFIG_ xxxxxxxxxxx (TRDEXP) EXPERT_INFO_ xxxxxxxxxxx (TRDEXPIN) SERVICE_SENSOR_ xxxxxxxxxxx (TRDSRVSB) SERVICE_INFO_ xxxxxxxxxxx (TRDSRVIF) DATA_TRANSFER_ xxxxxxxxxxx (TRDHROM)

  • Page 62: Block Configuration When Device Is Delivered

    The guideline provides an overview of the standard function blocks that are described in FOUNDATION Fieldbus Specifications FF 890 - 894. It is designed to help operators use the blocks implemented in the Endress+Hauser field devices. 9.4.2 Block configuration when device is delivered Device_01 4841.000...

  • Page 63: Index Tables Of Endress+Hauser Parameters

    Noise of signal 33107 Upper interface thickness Index tables of Endress+Hauser parameters The following tables list the manufacturer-specific device parameters for the Resource Blocks. For the FOUNDATION Fieldbus parameters, see the document BA062S "Guidline - FOUNDATION Fieldbus Function Blocks", which can be downloaded from www.endress.com.

  • Page 64: Advanced Setup Transducer Block

    Integration into a FOUNDATION Fieldbus network Levelflex FMP50 Name Label Index Data type Size Storage Write MODE_BL Description (Bytes) Class access distance_unit Distance unit ENUM16 Static (® ä 118) interface Interface FLOAT Dynamic level_unit Level unit ENUM16 Static (® ä 129)

  • Page 65: Display Transducer Block

    Levelflex FMP50 Integration into a FOUNDATION Fieldbus network Name Label Index Data type Size Storage Write MODE_BL Description (Bytes) Class access level_correction Level correction FLOAT Static (® ä 130) level_unit_ro Level unit ENUM16 Static (® ä 129) assign_limit Assign limit...

  • Page 66: Diagnostic Transducer Block

    Integration into a FOUNDATION Fieldbus network Levelflex FMP50 Name Label Index Data type Size Storage Write MODE_BLK Description (Bytes) Class access decimal_places_3 Decimal places 3 ENUM16 Static AUTO (® ä 147) decimal_places_4 Decimal places 4 ENUM16 Static AUTO (® ä 148)

  • Page 67: Expert Configuration Transducer Block

    Levelflex FMP50 Integration into a FOUNDATION Fieldbus network Name Label Index Data type Size Storage Write MODE_BLK Description (Bytes) Class access linearization_type Linearization type ENUM16 Static (® ä 131) unit_after_linearization_ro Free text STRING Static AUTO (® ä 132) decimal_places_menu Decimal places menu...
  • Page 68 Integration into a FOUNDATION Fieldbus network Levelflex FMP50 Name Label Index Data type Size (Bytes) Storage Class Write access MODE_BLK present_reference_distance Present reference distance FLOAT Dynamic history_reset History reset ENUM16 Static safety_distance Safety distance FLOAT Static history_learning_control History learning ENUM16...

  • Page 69: Expert Information Transducer Block

    Levelflex FMP50 Integration into a FOUNDATION Fieldbus network 9.6.6 Expert Information Transducer Block The parameters of the Expert Information Transducer Block are described in GP01015F: "Levelflex FMP5x - Description of Device Parameters - FOUNDATION Fieldbus" Name Label Index Data type...

  • Page 70: Service Sensor Transducer Block

    Endress+Hauser service personnel. 9.6.8 Service Information Transducer Block The parameters of the Service Information Transducer Block can only be operated by authorized Endress+Hauser service personnel. 9.6.9 Data Transfer Transducer Block The parameters of the Data Transfer Transducer Block are described in GP01015F: "Levelflex FMP5x - Description of Device Parameters - FOUNDATION Fieldbus"...
  • Page 71 Levelflex FMP50 Integration into a FOUNDATION Fieldbus network Name Label Index Data type Size (Bytes) Storage Class Write access MODE_BLK present_probe_length_ro Present probe length FLOAT Dynamic AUTO trend_operation_hours UINT32 Static trend_package_size UINT8 Static AUTO trend_storage_time Trend storage time UINT32 Static...

  • Page 72: Methods

    Integration into a FOUNDATION Fieldbus network Levelflex FMP50 Name Label Index Data type Size (Bytes) Storage Class Write access MODE_BLK bdt_transferred_ctrl UINT8 Static AUTO bdt_cfg_rdwr_ctrl UINT16 Static AUTO Methods The FOUNDATION Fieldbus Specification includes the use of methods to make device operation easier.

  • Page 73: Commissioning Via Operating Menu (On-Site Display, Fieldcare)

    Levelflex FMP50 Commissioning via operating menu (On-site display, FieldCare) Commissioning via operating menu (On-site display, FieldCare) 10.1 Installation and function check Make sure that all final checks have been completed before you start up your measuring point: • Checklist "Post-installation check" (® ä 41) •...

  • Page 74: Setting The Operating Language

    Commissioning via operating menu (On-site display, FieldCare) Levelflex FMP50 10.4 Setting the operating language 10.4.1 Setting the operating language via the display module A0013637 10.4.2 Setting the language via operating tool (FieldCare) A0015305-EN Endress+Hauser...

  • Page 75: Configuration Of A Level Measurement

    "Tank type" = "Bypass/pipe" If required, lower DCs can ben entered into "Setup ® Advanced Setup ® Level ® Medium property". However, for DC<1.6 the measuring range may be reduced; for details please contact Endress+Hauser. Endress+Hauser...

  • Page 76: Configuration Of The On-Site Display

    Commissioning via operating menu (On-site display, FieldCare) Levelflex FMP50 10.6 Configuration of the on-site display 10.6.1 Factory settings of the on-site display for level measurements Parameter Factory setting for devices with 1 current Factory setting for devices with 2 current...

  • Page 77: Commissioning With A Foundation Fieldbus Configuration Program

    Levelflex FMP50 Commissioning with a FOUNDATION Fieldbus configuration program Commissioning with a FOUNDATION Fieldbus configuration program 11.1 Function check Carry out a post-installation and a post-connection check as per the checklist before commissioning the device: • "Post-installation check" checklist (® ä 41) •...

  • Page 78: Configuring The Analog Input Blocks

    Commissioning with a FOUNDATION Fieldbus configuration program Levelflex FMP50 11.2.4 Configuring the Analog Input Blocks The device has 2 Analog Input Blocks that can be assigned as required to the various process variables. Default settings Analog Input Block CHANNEL AI 1...

  • Page 79: Language Selection

    Levelflex FMP50 Commissioning with a FOUNDATION Fieldbus configuration program XD_SCALE OUT_SCALE EU_100 EU_0 EU_100 EU_0 OUT_VALUE A0017338 Scaling of the measured value in an AI Block å 24 • If you have selected the Direct mode for the L_TYPE parameter, you cannot change the values and units for XD_SCALE and OUT_SCALE.

  • Page 80: Configuration Of A Level Measurement

    Commissioning with a FOUNDATION Fieldbus configuration program Levelflex FMP50 11.5 Configuration of a level measurement The Setup method can also be used to configure the measurement. It is called up via the SETUP (TRDSUP) transducer block. 20 mA 100% 4 mA...

  • Page 81: Configuration Of The On-Site Display

    "Tank type" = "Bypass/pipe" If required, lower DCs can ben entered into the "DC value (dc_value)" parameter. However, for DC<1.6 the measuring range may be reduced; for details please contact Endress+Hauser. 11.6 Configuration of the on-site display 11.6.1...
  • Page 82 Commissioning with a FOUNDATION Fieldbus configuration program Levelflex FMP50 Parameter: Configuration management (configuration_management) Functions of the parameter options Options Description 33097: Execute backup A backup copy of the current device configuration in the HistoROM is saved to the display module of the device. The backup copy comprises the transmitter data of the device.
  • Page 83 Levelflex FMP50 Commissioning with a FOUNDATION Fieldbus configuration program 11.8 Configuration of the event behavior according to the FOUNDATION Fieldbus specification FF912 The device complies with the FOUNDATION Fieldbus specification FF912. This has - among other things - the following consequences: •...

  • Page 84: Configuration Of The Event Behavior According To The Foundation Fieldbus Specification Ff912

    Commissioning with a FOUNDATION Fieldbus configuration program Levelflex FMP50 11.8.1 Groups of events The diagnostic messages are classified into 16 groups according to the source and severity of the respective event. A default diagnostic category is allocated to each group. Each group is also represented by one bit of the allocation parameters.
  • Page 85 Levelflex FMP50 Commissioning with a FOUNDATION Fieldbus configuration program Severity of the Default diagnostic category Source of the Events within the group event event Configuration S441: Current output 1 Process • S801: Energy too low • S825: Operating temperature • S921: Change of reference •...

  • Page 86: Allocation Parameters

    Commissioning with a FOUNDATION Fieldbus configuration program Levelflex FMP50 11.8.2 Allocation parameters The allocation of event categories to the event groups is controlled by the allocation parameters. They reside in the RESOURCE (RB2) block: • FD_FAIL_MAP: for the Failure (F) event category •...
  • Page 87 Levelflex FMP50 Commissioning with a FOUNDATION Fieldbus configuration program A0017618 Use the FieldCare navigation window to navigate to the the following screen: Expert ® Communication ® Field diagnostics ® Alarm detection enable. A0017621 Default state of the "Fail Map" and "Check Map" columns å...
  • Page 88 Commissioning with a FOUNDATION Fieldbus configuration program Levelflex FMP50 Make sure that for each group the corresponding bit is set to 1 in at least one of the allocation parameters. Otherwise no event category is transmitted with the event message.

  • Page 89: Configurable Area

    Levelflex FMP50 Commissioning with a FOUNDATION Fieldbus configuration program 11.8.3 Configurable area An event category can be individually defined for the following parameters - irrespective of the group of events they belong to by default. • F941: Echo lost • S942: In safety distance Prior to changing the event category, the event must be allocated to one of the bits 1 to 15.

  • Page 90: Transmission Of The Event Meassages To The Bus

    Commissioning with a FOUNDATION Fieldbus configuration program Levelflex FMP50 A0017620 Got to the Offspec Map column and activate the checkbox of the respective bit (in the example: Configurable Area Bit 1). Confirm the selection by pressing the Enter key. A change of the error category of In safety distance does not affect an error which is already present.

  • Page 91: Trouble Shooting

    Levelflex FMP50 Trouble shooting Trouble shooting 12.1 Trouble-shooting instructions Parametrization errors for level measurements Error Possible cause Remedial action Measured value wrong If measured distance(Setup ® • Check the Empty calibration Distance) matches the real distance: parameter and adjust it if Calibration error necessary(®...

  • Page 92: Diagnostic Information On Local Display

    Trouble shooting Levelflex FMP50 12.2 Diagnostic information on local display 12.2.1 Diagnostic message Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the measured value display. Measured value display in alarm condition...

  • Page 93: Calling Up Remedial Measures

    Levelflex FMP50 Trouble shooting Diagnostics event and event text The fault can be identified using the diagnostics event. The event text helps you by providing information about the fault. In addition, the corresponding symbol is displayed before the diagnostics event.

  • Page 94: Diagnostic Event In The Operating Tool

    Trouble shooting Levelflex FMP50 Ã The message for the remedial measures for the diagnostic event opens. 2. Press S + O simultaneously. Ã The message about the remedial measures closes. 12.3 Diagnostic event in the operating tool If a diagnostic event is present in the operating tool, the status signal appears in the top left status area along with the corresponding symbol for event level in accordance with NAMUR NE 107: •...

  • Page 95: Diagnostic Messages In The Diagnostic Transducer Block (Trddiag)

    Levelflex FMP50 Trouble shooting 12.4 Diagnostic messages in the DIAGNOSTIC Transducer Block (TRDDIAG) • The Actual diagnostics parameter displays the message with the highest priority. Every message is also output as per the FOUNDATION Fieldbus Specification by means of the XD_ERROR and BLOCK_ERROR parameters.

  • Page 96: Electronic Failures

    Trouble shooting Levelflex FMP50 Diagnostic event Maintenance instructions Error behavior Code Description F105 HF cable 1. Tighten HF cable connection. Alarm 2. Change HF cable. F106 Sensor 1. Check probe isolation. Alarm 2. Change sensor. 12.6.2 Electronic failures Diagnostic event...

  • Page 97: Process Induced Failures

    Levelflex FMP50 Trouble shooting Diagnostic event Maintenance instructions Error behavior Code Description M438 Data set 1. Check data set file. Warning 2. Check device configuration. 3. Up- and download new configuration. S441 Current output 1 1. Check process. Warning 2. Check current output settings.

  • Page 98: Event Logbook

    Trouble shooting Levelflex FMP50 12.7 Event logbook 12.7.1 Event history A chronological overview of the event messages that have occurred is provided in the Events list submenu. Navigation path Diagnostics ® Event logbook ® Events list / ../Eventlist I1091 Config. change I1157 Mem.err.

  • Page 99: Overview Of Information Events

    Levelflex FMP50 Trouble shooting 12.7.3 Overview of information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnose list. Information Event text event I1000 -------- (device OK) I1089 PowerOn I1090...

  • Page 100: Repairs

    13.1.1 Repair concept The Endress+Hauser repair concept assumes that the devices have a modular design and that repairs can be done by the Endress+Hauser service or specially trained customers. Spare parts are contained in suitable kits. They contain the related replacement instructions.

  • Page 101: Spare Parts

    Levelflex FMP50 Repairs 13.2 Spare parts • A few interchangeable measuring device components are identified by a spare part nameplate. This contains information about the spare part. • The connection compartment cover of the device contains a spare part nameplate that includes the following information: –...

  • Page 102: Maintenance

    Maintenance Levelflex FMP50 Maintenance The measuring device requires no special maintenance. 14.1 Exterior cleaning When exterior-cleaning the device, always use cleaning agents that do not attack the surface of the hosuing and the seals. Endress+Hauser...

  • Page 103: Accessories

    Levelflex FMP50 Accessories Accessories 15.1 Device-specific accessories Accessory Description Weather protection cover mm (in) A0015466 298.5 (11.8) 273.8 (10.8) 164 (6.46) 255.1 (10) mm (in) A0015472 37.8 mm (1.49 in) 54 mm (2.13 in) The weather protection cover can be ordered together with the device (product structure, feature 620 "Accessory Enclosed", option PB "Weather Protection...
  • Page 104 Accessories Levelflex FMP50 Accessory Description Mounting bracket for the electronics housing 122 (4.8) 140 (5.5) 175 (6.9) 158 (6.2) Ø 42 ... 60 mm (inch) (1-1/4 ... 2) A0014793 Wall mounting Pipe mounting For the "Sensor remote" device version (see feature 060 of the product structure), the mounting bracket is part of the delivery.
  • Page 105 Levelflex FMP50 Accessories Accessory Description Mounting kit, isolated A0013586 Insulating sleeve Eye-bolt For reliably insulated fixing of the probe. Maximum process temperature: 150 °C (300 °F) For rope probes 4 mm (1/6 in) or 6 mm (1/4 in) with PA>steel: •...

  • Page 106: Communication-Specific Accessories

    For details refer to the document SD01007F. 15.2 Communication-specific accessories Accessory Description Commubox FXA291 Connects Endress+Hauser field devices with CDI interface (= Endress+Hauser Common Data Interface) to the USB interface of a computer. For details refer to Technical Information TI405C/07 Accessory Description Field Xpert SFX100 Compact, flexible and robust industry handheld terminal for remote parametrization and measured value inspection via the HART output or via FOUNDATION Fieldbus .

  • Page 107: Service-Specific Accessories

    Accessory Description FieldCare Endress+Hauser's FDT-based Plant Asset Management tool. Helps to configure and maintain all field devices of your plant. By supplying status information it also supports the diagnosis of the devices. For details refer to Operating Instructions BA027S/04 and BA059S/04 15.4...

  • Page 108: Return

    +Hauser, as an ISO-certified company, is required to follow certain procedures when handling returned products that are in contact with medium. To ensure swift, safe and professional device returns, please read the return procedures and conditions on the Endress+Hauser website at www.services.endress.com/return-material Endress+Hauser...

  • Page 109: Disposal

    Levelflex FMP50 Disposal Disposal In case of disposal please separate the different components according to their material consistence. Endress+Hauser...

  • Page 110: Overview Of The Operating Menu

    Overview of the operating menu Levelflex FMP50 Overview of the operating menu Language (® ä 114) Display/operation ® Access status display (® ä 115) Locking status (® ä 115) Format display (® ä 115) Contrast display (® ä 117) Display interval (®...
  • Page 111 Levelflex FMP50 Overview of the operating menu Maximum value (® ä 132) Diameter (® ä 133) Intermediate height (® ä 133) Table mode (® ä 133) Table number (® ä 134) Level (® ä 134) Customer value (® ä 135) Activate table (®...
  • Page 112 Overview of the operating menu Levelflex FMP50 Header (® ä 149) Header text (® ä 149) Separator (® ä 150) Number format (® ä 150) Decimal places menu (® ä 150) Setup ® Advanced setup ® Config. backup display ®...
  • Page 113 Levelflex FMP50 Overview of the operating menu Out value (® ä 161) Units index (® ä 161) Diagnostics ® Measured value ® Digital input 1...3 ® Block tag (® ä 161) Channel (® ä 161) Output state (® ä 161) Out value (®...

  • Page 114: Description Of Device Parameters

    Description of device parameters (operating menu) Levelflex FMP50 Description of device parameters (operating menu) • : Marks the navigation path to the parameter via the display and operating module. • : Marks the navigation path to the parameter via an operating tool (e.g. FieldCare).

  • Page 115: Display/Operation" Menu

    Levelflex FMP50 Description of device parameters (operating menu) 19.1 "Display/operation" menu This menu only appears if the device has a local display. Access status display Display/operation ® Access stat. disp. Navigation Setup ® Advanced setup ® Access stat. disp. Description Use this function to view the access authorization to parameters via onsite operation.
  • Page 116 Description of device parameters (operating menu) Levelflex FMP50 Navigation Display/operation ® Format display Setup ® Advanced Setup ® Display ® Format display Description Use this function to select how the measured value is shown on the local display. The display format (size, bar graph etc.) and number of measured values displayed simultaneously (1 to 4) can...
  • Page 117 Levelflex FMP50 Description of device parameters (operating menu) Additional information 1 value, max. size A0011948-EN 1 bargraph + 1 value A0012011-EN 2 values A0012013-EN 1 value large + 2 values A0012016-EN 4 values A0012019-EN Contrast display Display/operation ® Contrast display...

  • Page 118: Setup" Menu

    Description of device parameters (operating menu) Levelflex FMP50 Factory setting 30 % Display interval Navigation Display/operation ® Display interval Setup ® Advanced Setup ® Display ® Display interval Description Use this function to set the length of time the measured values are displayed if the values alternate on the display.
  • Page 119 Levelflex FMP50 Description of device parameters (operating menu) Selection • Metallic • Bypass/pipe • Non metallic • Mounted outside Depending on the probe there may be further options. Factory setting Depending on the type of probe. Tube diameter Setup ® Tube diameter...
  • Page 120 Description of device parameters (operating menu) Levelflex FMP50 Description Defines the empty calibration E. E is the distance between the reference point (lower edge of the flange or threaded connection) and the minimum level (0%). A0013178 Input range Depending on the selected distance unit and the probe.
  • Page 121 Levelflex FMP50 Description of device parameters (operating menu) Description Displays the measured level L (before linearization) A0013194 Additional information The value is displayed in the selected "Level unit" (® ä 129). Distance Setup ® Distance Navigation Diagnostics ® Measured val. ® Distance...
  • Page 122 Description of device parameters (operating menu) Levelflex FMP50 Display options • Strong The evaluated echo exceeds the threshold by at least 10 mV • Medium The evaluated echo exceeds the threshold by at least 5 mV. • Weak The evaluated echo exceeds the threshold by less than 5 mV.

  • Page 123: Mapping" Sequence

    Levelflex FMP50 Description of device parameters (operating menu) 19.2.1 "Mapping" sequence Confirm distance Setup ® Mapping ® Confirm distance Navigation Description Confirmation whether the measured distance matches the actual distance. Depending on the selection, the device automatically determines the range over which the mapping will be recorded.

  • Page 124: Advanced Setup" Submenu

    Description of device parameters (operating menu) Levelflex FMP50 Description Definition of the distance up to which the mapping curve will be recorded. Input range 0.1 m (0.33 ft) to length of probe (LN) Factory setting 0.1 m (0.33 ft) Additional information The distance is measured from the reference point, i.e.
  • Page 125 If no key is pressed for 10 minutes, or the user goes from the navigation and editing mode back to the measured value display mode, the device automatically locks the write-protected parameters after another 60 s . Please contact your Endress+Hauser Sales Center if you lose your access code Input range 0 to 9 999 Define access code Setup ®...
  • Page 126 Description of device parameters (operating menu) Levelflex FMP50 Description Use this function to enter a unique name for the measuring point so it can be identified quickly within the plant. The name is displayed in the header: XXXXXXXXX A0013375 Header text Input range Max.
  • Page 127 Factory setting Unknown Additonal information Dielectric constants of important media commonly used in the industry are summarized in the document SD106F, which can be downloaded from the Endress+Hauser web page (www.endress.com). Process property Navigation Setup ® Advanced Setup ® Level ® Process property...
  • Page 128 Description of device parameters (operating menu) Levelflex FMP50 Options For "Medium type" = "Liquid" • Fast > 1 m(40")/min • Standard < 1 m(40")/min • Medium < 10 cm(4")/min • Slow < 1 cm(0.4")/min • No filter For "Medium type" = "Solid"...
  • Page 129 Levelflex FMP50 Description of device parameters (operating menu) Level unit Setup ® Advanced setup ® Level ® Level unit Navigation Description Defines the level unit Options • % • m • mm • ft • in Factory setting Additional information The level unit may differ from the distance unit as defined in the Distance unit parameter (®...
  • Page 130 Description of device parameters (operating menu) Levelflex FMP50 Level correction Setup ® Advanced setup ® Level ® Level correction Navigation Description Defines a level correction Input range Depending on the selected level unit: • -100,0 to 100,0 % • -200,0 to +200,0 m •...
  • Page 131 Levelflex FMP50 Description of device parameters (operating menu) The "Linearization" submenu Linearization type Navigation Setup ® Advanced setup ® Linearization ® Linearization type Description Defines the type of linearization Selection • None The level is transmitted to the output without 100% linearization.
  • Page 132 Description of device parameters (operating menu) Levelflex FMP50 Description Defines the unit of the linearized value. Selection • Free text • t • lb • ton • kg • impGal • UsGal • cf • cm • dm • m •...
  • Page 133 Levelflex FMP50 Description of device parameters (operating menu) Factory setting Diameter Navigation Setup ® Advanced setup ® Linearization ® Diameter Condition Only visible if one of the following linearization types has been selected: • Horizontal cylinder • Sphere Description Definition of the tank diameter Input range 0 ...
  • Page 134 Description of device parameters (operating menu) Levelflex FMP50 Navigation Setup ® Advanced setup ® Linearization ® Table mode Condition Only visible if the "Table" linearization type has been selected. Description Defines the method used to enter linearization points into the table.
  • Page 135 Levelflex FMP50 Description of device parameters (operating menu) Additional information For Table mode = Manual: Level is a writable parameter. For Table mode = Semi-automatic: Level is a read-only parameter. Customer value Setup ® Advanced setup ® Linearization ® Customer value...
  • Page 136 Description of device parameters (operating menu) Levelflex FMP50 The "Safety settings" submenu Output echo lost Navigation Setup ® Advanced setup ® Safety settings ® Output echo lost Description Defines the output signal in the case of a lost echo. Selection •...
  • Page 137 Levelflex FMP50 Description of device parameters (operating menu) Description Defines the slope of the ramp in the case of a lost echo. 100% A0013269 Delay echo lost Ramp echo lost (positive value) Ramp echo lost (negative value) Input range -9999999,0 to + 9999999,0 %/min...
  • Page 138 Description of device parameters (operating menu) Levelflex FMP50 The "Probe length correction" sequence The Probe length correction sequence helps to ensure that the end of probe signal within the envelope curve is correctly assigned by the evaluation algorithm. The assignment is correct if the length of probe indicated by the device matches the acutal lenght of the probe.
  • Page 139 Levelflex FMP50 Description of device parameters (operating menu) Present length Setup ® Advanced setup ® Probe length corr. ® Pres. length Navigation Description Depending on the parametrization: • In most cases: Displays the measured length of probe (according to the detected end of probe signal).
  • Page 140 Description of device parameters (operating menu) Levelflex FMP50 Description Allocates a DI block to the switch output. Options • Off No digital block is allocated. • Digital output 1 • Digital output 2 • Digital output 3 • Digital output 4...
  • Page 141 Levelflex FMP50 Description of device parameters (operating menu) Setup ® Advanced setup ® Switch output ® Switch-on value / Switch-off value Navigation Only visible for Switch output function = Limit and Assign limit ¹ Off. Prerequisite Description Define the switch-on point and switch-off point for the limit evaluation.
  • Page 142 Description of device parameters (operating menu) Levelflex FMP50 Additional information The switching behavior depends on the relative position of the two switch points. Switch-on point > Switch-off point: The output is closed if the measured value exceeds the switch-on point.
  • Page 143 Levelflex FMP50 Description of device parameters (operating menu) Only visible for Switch output function = Limit and Assign limit ¹ Off. Prerequisite Description Defines the delay for the switching on of the output. Range of values 0 to 100 s...
  • Page 144 Description of device parameters (operating menu) Levelflex FMP50 Invert output signal Setup ® Advanced setup ® Switch output ® Invert output signal Navigation Description Allows to invert the behavior of the switch output. Options • No The behavior of the switch output is as described above.
  • Page 145 Levelflex FMP50 Description of device parameters (operating menu) The "Display" submenu For operating tools: The Display submenu is only visible if a display module is connected to the device. Format display (® ä 115) Value 1 display Setup ® Advanced setup ® Display ® Value 1 display...
  • Page 146 Description of device parameters (operating menu) Levelflex FMP50 Value 2 display Setup ® Advanced setup ® Display ® Value 2 display Navigation Description Use this function to select one of the measured values to be shown on the local display. If several measured values are displayed at once, the measured value selected here will be the second value to be displayed.
  • Page 147 Levelflex FMP50 Description of device parameters (operating menu) Description Use this function to select one of the measured values to be shown on the local display. If more than two measured values are displayed at once, the measured value selected here will be the third value to be displayed.
  • Page 148 Description of device parameters (operating menu) Levelflex FMP50 Options • None • Level linearized • Distance • Current output 1 • Current output 2 • Measured current • Terminal voltage • Electronics temperature Factory setting For level measurements and 1 current output...
  • Page 149 Levelflex FMP50 Description of device parameters (operating menu) Header Setup ® Advanced setup ® Display ® Header Navigation Description Use this function to select the contents of the header of the local display. The header text only appears during normal operation.
  • Page 150 Description of device parameters (operating menu) Levelflex FMP50 Additional information User entry The number of characters displayed depends on the characters used. Separator Setup ® Advanced setup ® Display ® Separator Navigation Description Use this function to select the decimal separator.
  • Page 151 Levelflex FMP50 Description of device parameters (operating menu) The "Configuration backup display" submenu The Configuration backup display submenu is only visible if a display module is connected to the device. The configuration of the device can be saved to the display module at a certain point of time (backup).
  • Page 152 Description of device parameters (operating menu) Levelflex FMP50 Options • Cancel No action is executed and the user exits the parameter. • Execute backup A backup copy of the current device configuration in the HistoROM (built-in in the device) is saved to the display module of the device.

  • Page 153: The "Diagnostics" Menu

    Levelflex FMP50 Description of device parameters (operating menu) 19.3 The "Diagnostics" menu Actual diagnostics Diagnostics ® Actual diagnos. Navigation Description Use this function to display the current diagnostics message. If two or more messages occur simultaneously, the message with the highest priority is shown on the display.
  • Page 154 Description of device parameters (operating menu) Levelflex FMP50 Operating time (® ä 151) Endress+Hauser...

  • Page 155: Diagnsotics List" Submenu

    Levelflex FMP50 Description of device parameters (operating menu) 19.3.1 "Diagnsotics list" submenu Up to 5 diagnostics messages currently pending are displayed in this submenu. If more than 5 messages are pending, the messages with the highest priority are shown on the display.

  • Page 156: The "Event Logbook" Submenu

    Description of device parameters (operating menu) Levelflex FMP50 19.3.2 The "Event logbook" submenu Filter options Diagnostics ® Event logbook ® Filter options Navigation Description Use this function to select the category (status signal) whose event messages are displayed in the events list.
  • Page 157 Levelflex FMP50 Description of device parameters (operating menu) Additional information User interface Example 1 for display format: I 1091 24d12h13m00s Configuration modified Example 2 for display format: S441 01d4h12min30s Current output 1 HistoROM A HistoROM is a "non-volatile" device memory in the form of an EEPROM.

  • Page 158: Device Information" Submenu

    Use this function to view the serial number of the device. It can also be found on the nameplate. Uses of the serial number • To identify the device quickly, e.g. when contacting Endress+Hauser. • To obtain specific information on the device using the Device Viewer: www.endress.com/deviceviewer...
  • Page 159 Levelflex FMP50 Description of device parameters (operating menu) Description Use this function to display the first, second or third part of the extended order code. On account of length restrictions, the extended order code is split into a maximum of 3 parameters.

  • Page 160: Measured Value" Submenu

    Description of device parameters (operating menu) Levelflex FMP50 19.3.4 "Measured value" submenu Distance (® ä 121) Level linearized Diagnostics ® Measured val. ® Level linearized Navigation Description Displays the linearized level. Switch status (® ä 143) "Analog input 1" ... "Analog input 5" submenu Block tag Diagnostics ®...
  • Page 161 Levelflex FMP50 Description of device parameters (operating menu) Diagnostics ® Measured val.® Analog input 1...5 ® Output state Navigation Description State of the block output value according to the FOUNDATION Fieldbus specification Out value Diagnostics ® Measured val.® Analog input 1...5 ® Out value...
  • Page 162 Description of device parameters (operating menu) Levelflex FMP50 Navigation Diagnostics ® Measured val.® Digital input 1...3 ® Output state Description Status of the block output value according to the FOUNDATION Fieldbus specification Out value Diagnose ® Measured val.® Digital input 1...3 ® Out value...

  • Page 163: Data Logging" Submenu

    Levelflex FMP50 Description of device parameters (operating menu) 19.3.5 "Data logging" submenu Assign channel 1-4 Diagnostics ® Data logging ® Assign channel 1 Navigation Diagnostics ® Data logging ® Assign channel 2 Diagnostics ® Data logging ® Assign channel 3 Diagnostics ®...
  • Page 164 Description of device parameters (operating menu) Levelflex FMP50 Description Definition of the logging interval t for data logging. This defines the interval between the individual data points in the data log, and thus the maximum loggable process time T = 1000 × t •...
  • Page 165 Levelflex FMP50 Description of device parameters (operating menu) Description Use this function to view the measured value trend for the logging channel in the form of a chart. A0013859 • x-axis: depending on the number of channels selected displays 250 to 1000 measured values of a process variable.

  • Page 166: Simulation" Submenu

    Description of device parameters (operating menu) Levelflex FMP50 19.3.6 "Simulation" submenu Assignment of measured variable Diagnostics ® Simulation ® Assign. meas. var. Navigation Description Use this function to select a process variable for the simulation process that is activated. The display alternates between the measured value and a diagnostics message of the "function check"...
  • Page 167 Levelflex FMP50 Description of device parameters (operating menu) Switch status Diagnostics ® Simulation ® Switch status Navigation Prerequisite Only visible for Switch output simulation = On. Description Use this parameter to define the switch status for the simulation. Options • Open •...

  • Page 168: The "Device Check" Submenu

    Description of device parameters (operating menu) Levelflex FMP50 19.3.7 The "Device check" submenu Start device check Diagnostics ® Device check ® Start device check Navigation Description Start of a device check. Selection • No No device check is performed. • Yes A device check is performed.
  • Page 169 Levelflex FMP50 Description of device parameters (operating menu) Diagnostics ® Device check ® Level signal Navigation Conditions Only visible if a device check has been performed. Description Displays the result of the device check for the level signal. Display • Check not done •...

  • Page 170: Device Reset" Submenu

    Description of device parameters (operating menu) Levelflex FMP50 19.3.8 "Device reset" submenu Restart Diagnostics ® Device reset ® Restart Navigation Description Use this function to reset the device configuration - either entirely or in part - to a defined state.

  • Page 171: Index

    Levelflex FMP50 Index Index Designated use ......10 Device check (Submenu) ..... . 168 Access status display (Parameter) .
  • Page 172 Index Levelflex FMP50 Explanation ......92 Manage device configuration ....76, 81 Symbols .
  • Page 173 Levelflex FMP50 Index Reset ........170 Tank type (Parameter) .
  • Page 175 Erklärung zur Kontamination und Reinigung Please reference the Return Authorization Number (RA#), obtained from Endress+Hauser, on all paperwork and mark the RA# clearly on the outside of the box. If this procedure is not followed, it may result in the refusal of the package at our facility.
  • Page 176 www.endress.com/worldwide *71206420* BA01051F/00/EN/02.12 71206420 CCS/COSIMA 71206420...

Table of Contents
