ASSEMBLY INSTRUCTIONS
PARTS LIST
(A) 32 - 4-way connector
(B) 12 - 14" x 14" square glass panels
(C) 16 - 14" x 14" quarter round
glass panels
BASE SOLD SEPARATELY.
GLASS UNIT, BULLIT TOP
#14229C, 14229B, 14229CL
(A)
www.kc-store-fixtures.com
7400 E. 12th Street, Kansas City, MO 64126 • 1-800-862-0899
(B)
(C)
PAGE 1 OF 3
