- Page 1 Pedestal Assembly Instructions COMPONENTS Part # 800-862-0899 www.kc-store-fixtures.com 1 of 2...
- Page 2 Pedestal Assembly Instructions Cam and Cam Bolt Construction Cam Bolt: (Figure 1) Screw the cam bolt into the predrilled hole. Tighten until snug and the non-threaded portion of the bolt (A) touches the surface. Cams: (Figure 2) Make sure the hex drive on the cam faces up, then push the cam down into large hole.
