4. Software Functions

This unit can be used in connection with your computer running the Blood Pressure Analyzer Software. The
software will allow a capacity of monitoring 80 patients, each with 1000 data (Note: overuse will lower system
efficiency). The memory data can be transferred to the computer by connecting the monitor via USB cable with
your computer.
NOTE: The USB cable can be purchased at any electronics store. You will need USB cable Mini-B 5 pin. USB
versions 1.0 or 2.0 will work on this device.
System Requirements:
This software is compatible with Microsoft® Windows® 7 / 8 / 10 and supports 32 and 64 bit operating
systems and Mac OSX 10.10 / 10.11 / 10.12 / 10.13 / 10.14 / 10.15.
To download the software go to www.biosmedical.com. Go to the support page and download BIOS
Diagnostics BP Analyzer Software 3.2.9E for PC and MAC (AFIB). Follow the directions to download the
software.
Once installation is complete connect the monitor via USB cable with the PC. Three horizontal bars will appear
on the display and last for 3 seconds.
The bars will then flash to indicate that the connection between computer and device is successfully made. As
long as the cable is plugged in, the bars will keep flashing and the buttons are disabled.
During the connection, the device is completely controlled by the computer. Please refer to the 'help' file in the
software for detailed instructions.

5. Error Messages / Malfunctions

If an error occurs during a measurement, a long beep followed by two short beeps is generated and the LCD
display the corresponding error code.
Error Possible Cause
No pulse has been detected.
Unnatural pressure impulses influence
the measurement result. Reason: The arm
was moved during the measurement.
The inflation of the cuff takes too long.
The cuff is not correctly seated.
The difference between systolic pressure
and diastolic pressure is too far away
from acceptable and reasonable range.
August 7 2020
Thermor LTD
TH4093
A6PC
Natalia Siguenza
Artwork is not to be amended or scaled. If any changes are
and we will amend here and resend artwork through. PLEASE
X
RETURN WITH SIGNATURE
Revision:
A
Remedy
Ensure that the cuff is being worn correctly,
and that you have your arm at the heart level.
Avoid unnecessary movement or talking.
Repeat the movement keeping your arm still.
Ensure that the cuff is being worn correctly.
An adequate pressure cannot be generated
in the cuff. A leak may have occured. Check
the cuff is correctly connected and its not too
loose.
Ensure that the cuff is being worn
correctly and that you have been inactive
for a sufficient time before making the
measurement.
