INSTRUCTIONS

RIGID HEDDLE TABLE STAND

Ashford Guarantee

Thank you for purchasing this Ashford product. In the unlikely event there is

any fault in manufacture we will replace the item. To validate our guarantee

please visit our website or write to us.

RHTS05112015V2

Table of Contents

Need help?

Do you have a question about the RIGID HEDDLE TABLE STAND and is the answer not in the manual?

Page 1 Ashford Guarantee Factory and Showroom: 415 West Street Thank you for purchasing this Ashford product. In the unlikely event there is PO Box 474, Ashburton 7700 New Zealand any fault in manufacture we will replace the item. To validate our guarantee Telephone 64 3 308 9087 Facsimile 64 3 308 8664 please visit our website or write to us.
Page 2 Ø 6mm (¼") tree is a native of New Zealand and has a lovely variety of colour and grain. For a silky smooth matt finish, use the Ashford Finishing Wax Polish to enhance the natural colours and character of this 15mm ( ⅝...
Page 3 Attach the 4 rubber feet to the legs with 12mm (1/2”) screws Secure the shaped legs A to the front holes in the loom side with 45mm (1 ¾”) bolts, washers and knobs. Back Front Loom side Washer...
Page 4 Reed Support Block Push the 75mm (3”) bolt through the reed support block and side as illustrated followed by the spacer. Spacer Then locate a leg B as illustrated and secure with a washer and knob. Repeat for the other side.
Page 5 Push a 40mm (1 ½”) bolt through the slot in leg A, through the hole in leg B and secure with a washer and knob. Repeat for the other side. Push the new reed support block firmly against the original reed support block and tighten both knobs.
Page 6 DOWN DOWN Ashford Handicrafts Limited Factory and Showroom: 415 West Street PO Box 474, Ashburton 7700 New Zealand Telephone 64 3 308 9087 Facsimile 64 3 308 8664 Email: sales@ashford.co.nz Internet: www.ashford.co.nz...
