  • Page 1 USER AND MAINTENANCE BOOK MANUEL D’UTILISATION ET DE MAINTENANCE HSP500ID-A...
  • Page 2 CONSTRUCTION HEATER GENERAL HAZARD WARNING READ INSTRUCTIONS CAREFULLY. READ AND FOLLOW ALL INSTRUCTIONS. PLACE INSTRUC- TIONS IN A SAFE PLACE FOR FUTURE REFERENCE. DO NOT ALLOW ANYONE WHO HAS NOT READ THESE INSTRUCTIONS TO ASSEMBLE, LIGHT, ADJUST OR OPERATE THE HEATER. IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
  • Page 3 AVERTISSEMENTS GÉNÉRAUX DE SÉCURITÉ RELATIFS À L’UNITÉ DE CHAUFFAGE DE CONSTRUCTION LIRE ATTENTIVEMENT LES INSTRUCTIONS. LIRE ET SUIVRE LES INSTRUCTIONS. RANGER LES INSTRUCTIONS DANS UN ENDROIT SÛR POUR CONSULTATION FUTURE. NE PERMETTRE À AUCUNE PERSONNE QUI N’AIT PAS TOUT D’ABORD LU CES INSTRUCTIONS D’ASSEMBLER, ALLUMER, RÉGLER NI OPÉRER L’UNITÉ DE CHAUFFAGE.
  • Page 4 100mm WARNING This appliance is equipped with a three-prong (grounding) plug for your protection against electric shock hazard and should be plugged directly into a grounded three-prong receptacle. - The heater must be grounded. - The requirements of local authorities having jurisdiction shall be followed. - This unit is not suitable for use with an external tank.
  • Page 5 TECHNICAL DATA TABLEAU DES DONNÉES TECHNIQUES HSP500ID-A 500000 Btu/h 3.6 Gal/h 2.75 GPH 60° STEINEN Type S 4032 cfm K-1 Kerosene No. 1 or No. 2 Fuel Oil ~120 V 60 Hz 13.4 A 174 PSI 1200 kPa 12 bar 1.08”...
  • Page 6 PICTURES FIGURE Vers. Radial...
  • Page 7 PICTURES FIGURE...
  • Page 8 PICTURES FIGURE...
  • Page 9 NOTE:_________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________...
  • Page 10 IMPORTANT: READ AND UNDERSTAND THIS OPERATIONAL MANUAL PRIOR TO ASSEMBLING, STARTING UP OR CONDUCTING MAINTENANCE ON THIS HEATER. USING THE HEATER INCORRECTLY CAN CAUSE SERIOUS OR FATAL INJURIES. KEEP THIS MANUAL FOR FURTHER REFERENCE. 1. DESCRIPTION and/or nausea. These symptoms could (Pic.

  • Page 11: Operating Principles

    •••2.2.5. Only use in well-ventilated authorised technical support centre areas. Set-up a suitable opening in to prevent any risk. line with current standards, with the •••2.2.21. Use original spare parts purpose of introducing fresh air from when replacing the burner, strictly outdoors.

  • Page 12: Installation Instructions

    5. INSTALLATION INSTRUC- 6. FUEL TIONS WARNING: The heater only works with DIESEL or KEROSENE. CAUTION: Closely follow all the opera- tions described in this paragraph. Instal- Only use diesel or kerosene. To avoid any lation must only be carried out by profes- fire or explosion hazard, never use petrol, sionally qualified personnel.

  • Page 13: Connecting The Room Thermostat

    9. STORAGE AND TRANSPORT ►►7.3. START-UP IN VENTILATION MODE: Before handling, the heater must be •••7.3.2. Press the fan button. switched off following the proper procedure with the power disconnected. Wait for the ►►7.4. SWITCH-OFF: heater to cool. Before handling, make sure that the IMPORTANT: Never unplug the heater to support used to move the heater is switch it off.

  • Page 14: Maintenance Frequency

    •••10.1.3. Remove the gaskets installed ►►10.2. CLEANING THE FAN: and do not reuse them. Only use new Use compressed air for routine cleaning and original gaskets (Pic. 12). of the fan, blowing the air through the rear •••10.1.4. Spray high pressure water inside grille.

  • Page 15: Troubleshooting

    12. TROUBLESHOOTING PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The heater 1. No power supply 1a. Check that there is electric power does not start 1b. Check that the heater is connected to or does not the correct power supply remain on 1c.

  • Page 16: Informations Sur La Sécurité

    IMPORTANT : VEUILLEZ LIRE ET COMPRENDRE CE MANUEL D'UTILISATION AVANT DE PROCÉDER À L'ASSEMBLAGE, À LA MISE EN SERVICE OU À L'ENTRETIEN DE CET APPAREIL DE CHAUFFAGE. L'UTILISATION INCORRECTE DU RÉCHAUFFEUR PEUT CAUSER DES LÉSIONS GRAVES OU FATALES. CONSERVER CE MANUEL POUR TOUTE CONSULTATION FUTURE. 1.

  • Page 17: Principes De Fonctionnement

    matériaux de couverture similaires doivent endommagé, il doit être remplacé par un être séparés de ceux-ci par une distance centre d’assistance technique agréé, afin de sécurité. Il est également conseillé d’éviter tout risque. d’utiliser des matériaux de couverture de •••2.2.21. En cas de remplacement du type ignifuges.

  • Page 18: Instructions Pour L'installation

    5. INSTRUCTIONS POUR de tirage, si celui-ci n’est pas raccordé à une L’INSTALLATION cheminée d’évacuation des fumées externe, en respectant les caractéristiques de ce manuel ATTENTION : Suivre scrupuleusement technique. toutes les opérations décrites dans ce paragraphe. L’installation ne doit être effectuée que par un personnel qualifié...
  • Page 19 8. BRANCHEMENT DU THERMOSTAT AUTOMATIQUEMENT. AU-DESSOUS AMBIANT 105°C (221°F), LE RÉCHAUFFEUR MODULE Pour le branchement du thermostat d’ambiance, LA VENTILATION POUR GARANTIR LE retirer le bouchon de la prise spécifique et relier MEILLEURE TEMPÉRATURE DE SORTIE DE le thermostat d’ambiance (Option) (Fig. 9). L’AIR, SELON LES CONDITIONS AMBIANTES DÉTECTÉES.
  • Page 20 Pour effectuer nettoyage, suivre REMARQUE : AVANT DE RALLUMER LE scrupuleusement la séquence suivante (en RÉCHAUFFEUR, VÉRIFIER D’AVOIR ÉLIMINÉ conservant soigneusement les vis et les LE PLUS D’EAU POSSIBLE A L’INTÉRIEUR rondelles) : DE LA CHAMBRE DE COMBUSTION AFIN •••10.1.1. Enlever le cône pour la canalisation D’ÉVITER DE GRAVES DOMMAGES.

  • Page 21: Identification Du Problème

    12. IDENTIFICATION DU PROBLÈME PROBLÈME CAUSE POSSIBLE SOLUTION POSSIBLE Le réchauffeur 1. Absence d’alimentation 1a. Vérifier la présence d’ alimentation ne s'allume pas électrique ou ne reste pas 1b. Vérifier que le réchauffeur soit raccordé à allumé la bonne alimentation électrique 1c.
  • Page 22 WIRING DIAGRAMS SCHEMAS ELECTRIQUES...
  • Page 23 NOTA:_________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________...
  • Page 25 MODEL HSP500ID-A PARTS LIST UNIT 2 Pos. Code N° Description Rev.- - Sept. 2017 4034.584 MOTOR (BV500 15) 4034.546 MOTOR POWER CORD (BV500 15) 4034.307 FAN (BV500 15) 4033.916 MOTOR FLANGE (BV500 15) 4033.627 MOTOR GRILLE 4034.615 MOTOR SUPPORT 4033.642 FIBER ROPE 4033.636...
  • Page 27 MODEL HSP500ID-A PARTS LIST UNIT 4 Pos. Code N° Description Rev.- - Sept. 2017 4033.786 SPACER 4034.540 PC-BOARD 4034.405 SPACER 4033.770 SPACER 4034.404 CONTROL PANEL BRACKET 4033.430 RELAY 4034.582 LED PC-BOARD 4034.552 LED PC-BOARD WIRES KIT 4034.554 ROOM THERMOSTAT WIRES 4033.906...
  • Page 29 MODEL HSP500ID-A PARTS LIST UNIT 6 Pos. Code N° Description Rev.- - Sept. 2017 4034.214 COTTER PIN 4034.213 WASHER 4034.211 WHEEL 4033.470 WHEEL BUSH 4034.613 COVER 4033.459 LIFTING ARC FOOT 4033.463 LIFTING ARC 4260.246 BREATHE VALVE 4100.810 CLIP 4034.309 CLIP 4104.147...
  • Page 31 MODEL HSP500ID-A PARTS LIST UNIT 8 Pos. Code N° Description Rev.- - Sept. 2017 MOTOR 4614.269 PUMP 4614.270 CAPACITOR 4614.317 4614.043 FILTER 4614.044 NEEDLE VALVE 4614.047 PLATE 4614.272 AIR DAMPER 4614.292 FRONT SHIELD 4614.302 10 a COLLAR 4614.295 11 a ELECTRODE 4034.196...
  • Page 32 NOTA:_________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________...
  • Page 33 NOTE:__________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________...
  • Page 34 NOTA:_________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________...
  • Page 35 NOTE:__________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ________________________________________________________________________ ►en - DISPOSAL OF THE PRODUCT -This product has been designed and manufactured with top-quality materials and components, which can be re-cycled and re-used.
  • Page 36 Enerco Group Inc. 4560 West 160th St. Cleveland, Ohio 44135 1-866-447-2194 4034.648 Edition 17 4033.381 Edition 14...
