READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference.
UNVENTED LP-GAS FIRED ROOM HEATER
WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Shut off gas supply
• Do not try to light any appliance
• Do not touch an electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
WARNING: This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to Fresh Air for Combustion and
Ventilation section on page 4 of this manual.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Refer to this manual for correct installation and operational procedures. For assistance or additional
information consult a qualified installer, service agency, or gas supplier.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home, where not prohibited
by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with any other gas.
Unvented Liquid Propane Fired Room Heater
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
Plaque Heaters
HSSVFRD10LPT
HEATSTAR, 4560 W. 160
TH
ST., CLEVELAND, OHIO 44135 · 866-447-2194
Blue Flame Heaters
HSSVFBF10LPT
1
Installation Instructions and Owner's Manual
Model #
HSSVFBF10LPT
HSSVFRD10LPT
2017 - CB
Advertisement
Table of Contents
Related Manuals for HeatStar HSSVFRD10LPT
Summary of Contents for HeatStar HSSVFRD10LPT
- Page 1 This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with any other gas. 2017 - CB HEATSTAR, 4560 W. 160 ST., CLEVELAND, OHIO 44135 · 866-447-2194 Unvented Liquid Propane Fired Room Heater...
-
Page 2: Table Of Contents
WARNINGS IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fire, explosion, electrical shock, and carbon monoxide poisoning. • Young children should be carefully supervised WARNING: This appliance is equipped for propane when they are in the same room with heater. -
Page 3: Specifications
SPECIFICATIONS MODEL HSSVFRD10LPT HSSVFBF10LPT BTU (Available) 10,000 10,000 Type of Gas LP-Gas Only LP-Gas Only Ignition Electronic Pulse (AA Battery) Electronic Pulse (AA Battery) Pressure Regulator Setting 10 Inches of Water 10 Inches of Water Inlet Gas Pressure (Maximum) 14 Inches of Water... -
Page 4: Thermostatic Control
SAFETY DEVICE atmosphere have a continuous water vapor retarder with a rating of one perm (6 x 10 kg per pa-sec-m This heater has a pilot with an Oxygen Depletion or less with openings gasketed or sealed and Sensor (ODS) safety shut off system. The ODS/pilot shuts off the heater if there is not enough fresh air. -
Page 5: Installation
3. Add the Btu/hr of all the fuel-burning appliances in the space such as, Vent–free heater, Gas water heater, Gas furnace, Vented gas heater, Gas fireplace logs, and Other gas appliances* 12” *Do not include direct-vent gas appliances. Direct- vent draws combustion air from the outdoors and vents to the outdoors. -
Page 6: Fastening Heater To Wall
• WARNING: A qualified service person must install Where there is easy access for operation, heater. Follow all local codes. inspection, and service. • CHECK GAS TYPE In the coldest part of the room. Use only LP-gas. If your gas supply is not LP-gas, do CAUTION: If you install the heater in a home garage: not install heater. - Page 7 Attaching to Wall using Anchor: For attaching mounting bracket to hollow walls (wall areas between studs) or solid walls (concrete or masonry) (2) Screws Note: Wall anchors, mounting screws, and spacer (2) Screws are in hardware package. The hardware package is provided with heater.
-
Page 8: Floor Mounting Away From Wall
Note: Use of floor mounting feet will require you to use a 3/8 NPT street elbow to make gas Screw Screw connection. hole hole CONNECTING TO GAS SUPPLY WARNING: A qualified service person must connect Figure 10 heater to gas supply. Follow all local codes. 2. - Page 9 3. Check all joints from the propane/LP supply valve to equipment shutoff valve (see figure 13). Apply mixture of liquid soap and water to HEATER CABINET gas joints. Bubbles forming show a leak. 3/8” NPT Pipe Nipple Pressure 4. Correct all leaks at once. Regulator Ground Joint Union 5.
-
Page 10: Operating Your Heater
OPERATING YOUR HEATER information above. If you do not smell gas, go to the next step. FOR YOUR SAFETY READ BEFORE LIGHTING 5. Push in gas control know slightly and turn WARNING: If you do not follow these instructions counterclockwise to PILOT/IGN and exactly, a fire or explosion may result causing depress for five (5) seconds. -
Page 11: Cleaning And Maintenance
A yellow tip on the pilot flame indicates dust and dirt in the pilot assembly. To clean the pilot assembly find the small pilot air inlet hole about two inches from where the pilot flame comes out of the pilot assembly (see Figure 17). -
Page 12: Troubleshooting
TROUBLESHOOTING NOTE: All troubleshooting items are listed in order of operation and likely occurrence. WARNING: Only a qualified service person should service and repair heater. CAUTION: Never use a wire needle, or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Make sure grille guard is in place before running heater. - Page 13 OBSERVED SYMPTOM POSSIBLE CAUSE REMEDY Heater shuts off in use (ODS operates) 1. Not enough fresh air is available 1. Open window and/or door for ventilation 2. Low line pressure 2. Contact local gas company 3. ODS/pilot is partially clogged 3.
-
Page 14: Parts List And Diagram
PARTS LIST AND DIAGRAM MODEL: HSSVFBF10LPT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80040 Wire Guard 80058 Floor Mounting Feet 80051 Front Panel 80052 Back Panel 80038 Glass 80036 Wall Mounting Bracket 80024 Reflector Heat Shield 80026 Reflector Back Panel Back Heat Shield Burner Left Bracket 70640 Thermostat Valve... - Page 15 PARTS LIST AND DIAGRAM MODEL: HSSVFRD10LPT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80040 Wire Guard Regulator Connection 80051 Front Panel 80058 Floor Mounting Feet 80024 Reflector 80052 Back Panel 80030 Burner Assembly 80036 Wall Mounting Bracket 80056 ODS Pilot Assembly w/ Thermocouple (LP)
-
Page 16: Warranty
LIMITED WARRANTY Enerco Group, Inc. (EGI) warrants Heatstar Vent free heaters to be free from defects in material and workmanship for a period of five years from the date of manufacture. • During the first two years, EGI will repair or replace this product if it is proven to be defective within the first two years and it is returned at customer expense with proof of purchase to the location of EGI’s choice.
