READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
DIRECT FIRED
PORTABLE HEATER
If the information in this manual is not followed exactly, a fire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— Service must be performed by a qualified service agency.
This is an unvented portable heater. It uses air (oxygen) from the area in which it is used. Adequate
combustion and ventilation air must be provided.
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001
Model #
HS3500DF
HS6000DF
05-15 JM 50125
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HeatStar HS 3500DF
Summary of Contents for HeatStar HS 3500DF
- Page 1 Model # OPERATING INSTRUCTIONS HS3500DF AND OWNER’S MANUAL HS6000DF READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to assemble, light, adjust or operate the heater. DIRECT FIRED PORTABLE HEATER If the information in this manual is not followed exactly, a fire or explosion...
-
Page 2: Table Of Contents
WARNING: WARNING: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS, NOT FOR HOME OR RECREATIONAL VEHICLE USE SO PLEASE READ THESE INSTRUCTIONS BEFORE YOU OPERATE THIS HEATER. WARNING: GENERAL HAZARD WARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD. KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING MA- FAILURE TO COMPLY WITH THE PRECAUTIONS AND TERIALS, PAPER OR CARDBOARD, A SAFE DISTANCE INSTRUCTIONS PROVIDED WITH THIS HEATER, CAN... -
Page 3: Specifications
• Make sure sufficient fresh outside air is provided according to the heater requirements. Direct combustion heaters should only be used in well vented areas in order to avoid carbon monoxide poisoning. TECHNICAL SPECIFICATIONS HS 3500DF HS 6000DF Heat input [kBTU/h] Air flow [cfm] 2.500... -
Page 4: Operation
OPERATION Before any attempt of starting the heater is made, check that • Install the heater on a flat, level floor in a steady position. your electrical supply conforms to the data on the model plate. • It is forbidden to connect direct-fired heaters to air ducts. WARNING Control Board •... -
Page 5: Maintenance
The hot air generators with wheels must be wheeled. The suspended version which has no wheels must be transported with adequate machinery. MAINTENANCE Preventive and regular maintenance will ensure a long trouble free life to your heater. WARNING • Never service heater while it is plugged in, operating or hot. Severe burns or electrical shock can occur. -
Page 6: Troubleshooting
TROUBLESHOOTING TROUBLE CAUSE SOLUTION Motor does not start, no ignition No electrical current Check mains (should be 120 V – 1~ – 60 Hz) Check proper positioning and functioning of switch Check fuse Wrong setting of room ther- Check correct setting of heater control. If thermostat, make mostat or other control sure selected temperature is higher than room temperature Thermostat or other control... -
Page 7: Wiring Diagrams
WIRING DIAGRAM 3500 AND 6000 SERIES MODELS DRAWING LEGEND Fuse Room Thermostat Transformer H.V. Relays Overheat Thermostat Control Box Solenoid Valve 1° Air pressure control Photocell Heater filter Condenser Fan thermostat Fan Motor Ground Electric pilot Control ENERCO GROUP, INC. |Direct Fired Portable Heater Operating Instructions and Owner’s Manual... - Page 8 3500DF Series Direct-Fired Portable Heater ENERCO GROUP, INC. |Direct Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 9 3500DF Series Direct-Fired Portable Heater POS P/N ALT # DESCRIPTION 50319 E10930 H.T. Transformer 50320 E40124 Flame control box 40494 G06408-9010 Outlet cone G06073 Support plate 50446 G06230 Combustion chamber 50013 E10102-P Switch 50447 G06233-9010 Upper body 50012 E20640 Thermostat plug 40495 G06409-9010 Lower body...
- Page 10 6000DF Series Direct-Fired Portable Heater ENERCO GROUP, INC. |Direct Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 11 6000DF Series Direct-Fired Portable Heater POS P/N ALT # DESCRIPTION 50097 E1 1125 Relay 50731 E20305 Terminal board 50027 G06139-9010 Outlet cone 50099 E10917-2 H.T. Transformer 50460 G06232 Combustion chamber 50320 E40124 Flame control box G06143-9010 Panel G06073 Support plate 50461 G06235-9010 Upper body...
-
Page 12: Parts Ordering Information
DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE AGENCY. PARTS ORDERING INFORMATION: PURCHASING: Accessories may be purchased at any HeatStar local dealer or direct from the factory FOR INFORMATION REGARDING SERVICE Please call Toll-Free 800-251-0001 • www.enerco.com Our office hours are 8:00 AM –... - Page 13 GUIDE D’UTILISATION ET INSTRUC- Model # HS3500DF TIONS DE FONC TIONNEMENT HS6000DF LISEZ SOIGNEUSEMENT LES INSTRUCTIONS : Lisez et observez toutes les instructions. Conservez les in- structions pour vous y référer ultérieurement. Interdisez à quiconque n’ayant pas lu les présentes instructions d’assembler, d’allumer, de régler ou de faire fonctionner cet appareil de chauffage.
- Page 14 AVERTISSEMENT : AVERTISSEMENT : NON CONÇU POUR UNE VOTRE SÉCURITÉ UTILISATION DANS LA MAISON OU UN VÉHICULE PERSONNELLE ÉTANT IMPORTANTE POUR TOUS, VEUILLEZ LIRE LES INSTRUCTIONS AVANT RÉCRÉATIF. D’UTILISER CET APPAREIL DE CHAUFFAGE. AVERTISSEMENT : DANGER D’INCENDIE, DE BRÛLURE, D’EXPLOSION ET D’INHALATION. AVERTISSEMENT GÉNÉRAL DE CONSERVEZ LES MATÉRIAUX COMBUSTIBLES TELS QUE DANGER :...
- Page 15 écrites sur la plaque de fabrication. les produits de combustion; • le générateur soit installé près d’une cheminée pour TECHNICAL SPECIFICATIONS HS 3500DF HS 6000DF Puisance termique en entrée [kBTU/h] Débit d’air [cfm] 2.500...
- Page 16 Tableau de commande • REMPLISSEZ TOUJOURS LE RÉSERVOIR À L’EXTÉRIEUR, LOIN D’UNE FLAMME NUE. • N’UTILISEZ PAS DE SOURCE DE COMBUSTIBLE EX- TERNE. • NE FAITES PAS FONCTIONNER L’APPAREIL DE CHAUFFAGE SI DES VAPEURS OU DES LIQUIDES IN- FLAMMABLES RISQUENT D’ÊTRE PRÉSENTS. •...
- Page 17 et provoque l’interruption de l’alimentation du fuel si le générateur surchauffe: le thermostat se réarme automatiquement quand la température de la chambre de combustion diminue jusqu’à rejoindre la valeur maximale admise. Avant de remettre en marche le générateur il faut trouver et éliminer la cause qui a produit la surchauffe (par ex.
- Page 18 ANOMALIES DE FONCTIONNEMENT CAUSES ET SOLUTIONS ANOMALIE CAUSE SOLUTION DEFONCTIONNEMENT Le ventilateur ne démarre pas et Le courant électrique n’arrive pas Vérifier les caractéristiques de l’installation electrique (120 V – 1~ – 60 Hz) la flamme ne s’allume pas Vérifier le fonctionnement et la position de i’interrupteur Vérifier l’efficacité...
-
Page 19: Wiring Diagram
WIRING DIAGRAM 3500 AND 6000 SERIES MODELS DESSIN DE LA LÉGENDE Fusible 20A Prise thermostat d’ambiace Transformateur H.T. Relais Thermostat de surchauffe Coffret de securite Electrovanne 1° Thermostat ventilateur Electrovanne 2° Connecteur Photoresistance Filtre gasoil rechauff Condensateur Thermostat de securite de surchauffe Moteur du ventilator Terre... - Page 20 3500DF Series Direct-Fired Portable Heater ENERCO GROUP, INC. |Direct Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 21 3500DF Series Direct-Fired Portable Heater DESCRIPTION 50319 E10930 Transformateur H.T. 50320 E40124 Disp. Contrôle flamme 40494 G06408-9010 Embout conique G06073 Plaque support 50446 G06230 Chambre de combustion 50013 E10102-P Interrupteur 50447 G06233-9010 Carrosserie sup. 50012 E20640 Fiche thermostat 40495 G06409-9010 Carrosserie Inf.
- Page 22 6000DF Chauffage Portatif Direct-tiré ENERCO GROUP, INC. |Direct Fired Portable Heater Operating Instructions and Owner’s Manual...
- Page 23 6000DF Series Direct-Fired Portable Heater ALT # DESCRIPTION 50097 E1 1 125 Relais 50731 E20305 Barrette de connection 50027 G06139-9010 Embout conique 50099 E10917-2 Transformateur H.T. 50460 G06232 Chambre de combustion 50320 E40124 Disp. Contrôle flamme G06143-9010 Panneau G06073 Plaque support 50461 G06235-9010 Carrosserie sup.
- Page 24 ENERCO GROUP, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 800-251-0001 Heatstar is a registered trademark of Enerco Group, Inc. © 2004, ENERCO GROUP, INC. All rights reserved ENERCO GROUP, INC., 4560 W.
