READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and
follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has
not read these instructions to assemble, light, adjust or operate the heater.
UNVENTED NATURAL GAS FIRED ROOM HEATER
HSSVFRD20NGBT
HSSVFRD30NGBT
WARNING: If the information in this manual is not followed exactly, a fire or explosion may
result causing property damage, personal injury, or loss of life.
- Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
- Installation and service must be performed by a qualified installer, service agency or the gas supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to Fresh Air for
Combustion and Ventilation section on page 4 of this manual.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is
not convertible for use with any other gas.
Enerco Technical Products, INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 · 866-447-2194
Unvented Natural Gas Vent Free Room Heaters
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
Plaque Heaters
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Blue Flame Heaters
1
Installation Instructions and Owner's Manual
Model #
HSSVFRD20NGBT
HSSVFRD30NGBT
HSSVFBF20NGBT
HSSVFBF30NGBT
HSSVFBF20NGBT
HSSVFBF30NGBT
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HeatStar HSSVFRD30NGBT
Summary of Contents for HeatStar HSSVFRD30NGBT
- Page 1 OPERATING INSTRUCTIONS Model # HSSVFRD20NGBT HSSVFRD30NGBT AND OWNER’S MANUAL HSSVFBF20NGBT HSSVFBF30NGBT READ INSTRUCTIONS CAREFULLY: YOUR SAFETY IS IMPORTANT TO YOU AND TO OTHERS Read and follow all instructions. Place instructions in a safe place for future reference. Do not allow anyone who has not read these instructions to assemble, light, adjust or operate the heater.
- Page 2 SOCIAL MEDIA In order to provide the best service possible HEATSTAR is now giving you more ways to get in touch with us: WEBSITE: Heatstar Products’s full line of product are now at: WWW.HEATSTARBYENERCO.COM YouTube: youtube.com/heatstarTV Unvented Natural Gas Vent Free Room Heaters Installation Instructions and Owner’s Manual...
-
Page 3: Table Of Contents
1. An unvented room heater having an input rating of more than 10,000 BTU (2931 W) (i.e. the HSSVFRD20NGBT, Early signs of carbon monoxide poisoning resemble the HSSVFRD30NGBT, HSSVFBF20NGBT, and flu, with headaches, dizziness, or nausea. If you have these HSSVFBF30NGBT) shall not be installed in a bedroom or signs, the heater may not be working properly. -
Page 4: Ignition System Battery Installation
PRODUCT FEATURES FRESH AIR FOR COMBUSTION AND VENTILATION WARNING: This heater shall not be installed in a confined Ignitor Button Fan Blower space or unusually tight construction unless provisions are Switch* provided for adequate combustion and ventilation air. Read Control Knob (located on back of heater) the following instructions to insure proper fresh air for this... -
Page 5: Determining The Type Of Heater Location Space
DETERMINING THE TYPE OF HEATER LOCATION C. Install a lower Btu/hr heater if lower Btu/hr size makes room unconfined. SPACE: If actual Btu/hr used is less than the maximum Btu/ Use this method to determine if you have a confined or hr the space can support, the space is an unconfined unconfined space. -
Page 6: Installation
WARNING: Never install the heater: This will help circulate the heat throughout the house. In • In a bedroom (HSSVFRD20NGBT, HSSVFRD30NGBT, the event of a power outage, you can use this heater as HSSVFBF20NGBT, HSSVFBF30NGBT) your primary heat source for the duration of the outage. - Page 7 Decide which way best suits your needs. Either method will provide a secure hold for the mounting bracket. Tape mounting bracket to wall where heater will be located. Make sure mounting bracket is level. 10”(25.4cm) 36”(91.4cm) For wall stud mounting locate one end of the from sides min from ceiling mounting bracket over a wall stud.
-
Page 8: Floor Mounting Away From Wall
5. Place mounting bracket onto wall. Line up holes on checking for leaks. each end of bracket with wall anchors. FLOOR MOUNTING AWAY FROM WALL: 6. Insert mounting screws through bracket and into Installing Support Feet (See figure 11.) wall anchors. Lay heater onto table on its back with bottom Tighten screws until mounting bracket is firmly edge overhanging table edge. - Page 9 *A CSA/AGA certified equipment shutoff valve with 2. Cap off open end of gas pipe where equipment shutoff 1/8” NPT tap is an acceptable alternative to test gauge valve was connected. connection. Purchase the CSA/AGA certified equipment 3. Pressurize supply piping system by either using shutoff valve from your dealer.
-
Page 10: Operating Your Heater
OPERATING YOUR HEATER Control Valve FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. To gas meter A. This appliance has a pilot that must be lighted by hand. When lighting the pilot, follow these instructions exactly. - Page 11 SHUTTING OFF BURNER ONLY (PILOT STAYS LIT) Turn control knob clockwise to the PILOT/IGN position. THERMOSTAT CONTROL OPERATION FOR HSSVFRD20NGBT / HSSVFRD30NGBT: The thermostatic control used simply turns on and off the burner. FOR HSSVFBF20NGBT / HSSVFBF30NGBT: The thermostatic control used modulates the flame size as the temperature gets closer to set point, then it turns off the burner upon reaching temperature.
-
Page 12: Cleaning And Maintenance
CLEANING AND MAINTENANCE Pilot Air Inlet Hole WARNING: Turn off heater and let cool before servicing. For maintenance of the inside cabinet or to access the burner Pilot Assembly and pilot assembly for cleaning or service. Remove the four screws(two located on each side) that secure the front shell Figure 18 to the unit (Figure 6). - Page 13 PAGE LEFT INTENTIONALLY BLANK Unvented Natural Gas Vent Free Room Heaters Installation Instructions and Owner’s Manual...
-
Page 14: Troubleshooting
TROUBLESHOOTING NOTE: All troubleshooting items are listed in order of operation and likely occurrence. WARNING: Only a qualified service person should service and repair heater. CAUTION: Never use a wire needle, or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Make sure grille guard is in place before running heater. - Page 15 OBSERVED SYMPTOM POSSIBLE CAUSE REMEDY Burner orifice is clogged Clean burner orifice (see Cleaning and Maintenance on page 11), or replace burner orifice Burner does not light after Burner orifice diameter to small Replace burner orifice ODS/pilot is lit Inlet gas pressure is too low Contact local gas company Manifold pressure is too low Contact local gas company...
-
Page 16: Parts List And Diagram
PARTS LIST AND DIAGRAM MODEL: HSSVFRD20NGBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION Thermostat Valve Mounting 80094 Wire Guard 80010 Bracket 80096 Front Panel (Beige) 80011 Igniter Module Mounting Bracket 80205 Front Panel (White) 80058 Floor Mounting Feet (Beige) 80086 Reflector 80214 Floor Mounting Feet (White) ODS Assembly w/ Thermocouple... - Page 17 PARTS LIST AND DIAGRAM MODEL: HSSVFRD30NGBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION Thermostat Valve Mounting 80041 Wire Guard 80010 Bracket 80065 Front Panel (Beige) 80011 Igniter Module Mounting Bracket 80208 Front Panel (White) 80058 Floor Mounting Feet (Beige) 80023 Reflector...
- Page 18 PARTS LIST AND DIAGRAM MODEL: HSSVFBF20NGBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80122 Wire Guard 70640 Thermostat Valve 80096 Front Panel (Beige) 80014 Igniter Wire 80205 Front Panel (White) 80019 Igniter Module 80087 Reflector 80011 Igniter Module Mounting Bracket Thermostat Valve Mounting 80088 Front Heat Shield 80010...
- Page 19 PARTS LIST AND DIAGRAM MODEL: HSSVFBF30NGBT ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80123 Wire Guard 70640 Thermostat Valve 80065 Front Panel (Beige) 80014 Igniter Wire 80208 Front Panel (White) 80019 Igniter Module 80025 Reflector 80011 Igniter Module Mounting Bracket Thermostat Valve Mounting 80029 Front Heat Shield 80010...
-
Page 20: Warranty
LIMITED WARRANTY Enerco Group, Inc. (EGI) warrants Heatstar Vent free heaters to be free from defects in material and workmanship for a period of five years from the date of manufacture. • During the first two years, EGI will repair or replace this product if it is proven to be defective within the first two years and it is returned at customer expense with proof of purchase to the location of EGI’s choice.
