Refer to the following to install the memory modules.
1. Push the latches on each side of the RIMM slot down.
2. Align the memory module with the slot. The RIMM
slots are keyed with notches and the RIMMs are keyed
with cutouts so that they can only be installed correctly.
3. Check that the cutouts on the RIMM module edge
connector match the notches in the RIMM slot:
Latch
Cutouts
4. Install the RIMM module into the slot and press it firmly
down until it seats correctly. The slot latches are lev-
ered upwards and latch on to the edges of the RIMM.
5. Install any remaining RIMM modules.
6. After installing your RIMM modules, insert the C-RIMM
modules in the unoccupied slots:
Notches
Latch
