Broan Rangemaster 613004 Specification Sheet

613004 / 619004

RANGE HOOD

An enduring stainless steel design that combines
the flawless look of Italian style with a lasting
impression.
FEATURES
•
Italian design
•
Wall mount
•
Finish: 430 Stainless Steel #4 Brushed
•
Widths: 30", 35-7/16" (90cm)
•
Telescopic flue accommodates 8' to 9' ceilings
•
Convertible to ducted or non-ducted operation
•
6" round duct connector/backdraft damper
•
Halogen lighting (2 x 20 watt, Type JC 12V 20W G4 base,
bulbs included)
•
Concealed three-speed slide control
•
450 CFM centrifugal blower
•
Dishwasher-safe filters feature a quick-release latch and
polished stainless steel cover plate
•
Heat Sentry - automatically turns blower to high speed
TM
when excess cooking heat is detected
OPTIONS
•
Replacement grease filters available
•
Non-ducted filter kit (contains two 6" round filters) (Model
ROUNDFILTER)
•
Flue extension for 10' ceiling (Model RFX6104) (Ducted
only – 31-7/8" long)
•
Exterior blower version available in 35-7/16" (90cm) and 48"
widths, providing 600, 900, 1200, or 1500 CFM exhaust
•
48" wide integral blower version (614804) available,
providing 900 CFM exhaust
REFERENCE QTY.
SPECIFICATIONS
vOLTS
120
REMARKS
SPECIFICATION SHEET
AMPS CFM SONES
3.13 450 9.0
HVI-2100 CERTIFIED RaTINGS comply with new
testing technologies and procedures prescribed
by the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers. Product
performance is rated at 0.1 in. static pressure,
based on tests conducted in AMCA's state-of-
the-art test laboratory. Sones are a measure of
humanly-perceived loudness, based on laboratory
measurements.
Project
Location
Architect
Engineer
Contractor
Submitted by
40F
DUCT
6" round
Date
99043361B
