1.2 Preparation items before the setup

The printing test and the cutting test will be performed when the LCX603 is installing, prepare the following
items to setup for the LCX603.
Items
PC
USB cable
Media: FNS Mat N50-1310B
Ink ribbon: RP120-B-R4A, Resin
Ink ribbon: RP120-BL-R4A, Resin
Ink ribbon: RP120-R-R4A, Resin
Ink ribbon: WD120-B-R4A, Semi-Resin
Ink ribbon: WD120-BL-R4A, Semi-Resin Semi-Resin ink ribbon printing test for the head 2, (Blue ribbon)
Ink ribbon: WD120-R-R4A, Semi-Resin
Laminate: PET16-1110R4A
Bobbin
Blade: CB09UA
Blade holder: PHP32-CB09N-HS
Cleaning Kit
LCX603-UM-651-9370
To print out the test pattern.
To print out the test pattern.
Media for printing test
Resin ink ribbon printing test for the head 1, (Black ribbon)
Resin ink ribbon printing test for the head 2, (Blue ribbon)
Resin ink ribbon printing test for the head 3, (Red ribbon)
Semi-Resin ink ribbon printing test for the head 1, (Black ribbon)
Semi-Resin ink ribbon printing test for the head 3, (Red ribbon)
Laminating test
To rewind the laminate and the separated media.
To cutting test
To cutting test
To clean the print head.
1-2
1 Preparation before the setup
Usage Q'ty
1
1
1 roll
1 roll
1 roll
1 roll
1 roll
1 roll
1 roll
1 roll
2
1
1
1 set
