Setup
(4) Remove the self tapping screws which are marking by the red circle holding the bottom part of outer
panels.
Self tapping screw
Self tapping screw
Self tapping screw
Self tapping screw
(5) Lift up the outer panels, and then detach the outer panels from the bottom of packing box.
LCX603-UM-651-9370
2-3
