Spirit Commercial CIC850 Owner's Manual

Hide thumbs Also See for CIC850:

Advertisement

Quick Links

CIC850
FITNESS BIKE
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the CIC850 and is the answer not in the manual?

Questions and answers

Related Manuals for Spirit Commercial CIC850

Summary of Contents for Spirit Commercial CIC850

  • Page 1 CIC850 FITNESS BIKE OWNER’S MANUAL...
  • Page 2 Spirit Fitness...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS PRODUCT REGISTRATION IMPORTANT SAFETY INSTRUCTIONS IMPORTANT OPERATION INSTRUCTIONS CIC850 ASSEMBLY INSTRUCTIONS CONSOLE INSTRUCTIONS TROUBLESHOOTING GENERAL MAINTENANCE MANUFACTURER’S LIMITED WARRANTY EXPLODED DRAWING PARTS LIST Thank you for purchasing our product, please save these instructions. Please do not perform or attempt any customizing, adjustments, repair or maintenance that is not described in this manual.
  • Page 4 Congratulations on your new Indoor Cycle and welcome to the Spirit Fitness family! Thank you for your purchase of this quality group indoor cycle from Spirit Fitness. Your new is backed by one of the most comprehensive warranties available. Through your dealer, Spirit Fitness will do all we can to make your ownership experience as pleasant as possible for many years to come.
  • Page 5 RECORD YOUR SERIAL NUMBER product in the space provided below. Serial Number Location Serial Number: REGISTER YOUR PURCHASE The self-addressed product registration card must be completed in full and returned to Spirit Fitness. You can also go to www.spiritfitness.ca/warranty under the Support tab to register online.

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY In a home setting, keep children away from the bike • when it is not in use. Keep children and pets away INSTRUCTIONS from the unit while it is in use. Do not attempt to perform dip movements on •...

  • Page 7: Important Operation Instructions

    Failure to follow all guidelines may compromise the effectiveness of the exercise experience, expose yourself (and • possibly others) to injury, and reduce the longevity of the equipment. SAVE THESE INSTRUCTIONS - THINK SAFETY! IMPORTANT OPERATION INSTRUCTIONS NEVER expose the bike to rain or moisture. This product is NOT designed for use outdoors, near a pool or spa, or in any other high humidity environment.
  • Page 8 Spirit Fitness...
  • Page 9 CIC850 PRE-ASSEMBLY www.spiritfitness.ca...
  • Page 10 CIC850 STEP ONE Spirit Fitness...
  • Page 11 www.spiritfitness.ca...
  • Page 12 CIC850 STEP THREE HARDWARE FOR STEP 3 PART TYPE DESCRIPTION KNOB STAR-POP-PIN (104) Spirit Fitness...
  • Page 13 CIC850 STEP FOUR HARDWARE FOR STEP 4 PART TYPE DESCRIPTION CONSOLE DT-3268F CONSOLE BRACKET SCREW M5*15L HANDLEBAR WATER BOTTLE HOLDER BLACK TABLET HOLDER BLACK SCREW M6*P1.0*20L FLAT WASHERS M6(D16*d6.5*1.0t) 1 1 0 www.spiritfitness.ca...
  • Page 14 CIC850 STEP FIVE HARDWARE FOR STEP 5 PART TYPE DESCRIPTION SAFETY PIN HANDLEBAR POST Spirit Fitness...
  • Page 15 CIC850 STEP SIX HARDWARE FOR STEP 6 PART TYPE DESCRIPTION 136R/L PEDAL JD-304 1. Remove pedals from the components box. 2. Look at the end of the pedal axle and notice each pedal is marked with an R and L on the spindle.
  • Page 16 CONSOLE INSTALLATION: 1. Ensure the Console Clamp is securely mounted on the back of the console. Insert the mounting screw through the Console Clamp into the Console. 2. Place the CONSOLE BRACKET on the back of the console and secure using the 1 SCREW . Tighten with Combination Cross Wrench (C).
  • Page 17 CIC850 CONSOLE OPERATION www.spiritfitness.ca...
  • Page 18 CADENCE & S DISPLAY WINDOW Cadence is the rotating in RPM can also be disp In addition to th display a bar gr SPEED the approximate HEART RATE Average Caden after the rider s DISTANCE TIME DISTANCE Distance is the LOW BETTERY KCAL distance achiev...
  • Page 19 CONSOLE BATTERY INSTALLATION: 1. Remove the battery cover from the back of the computer. 2. Insert 2 AAA batteries into the battery compartment and reinstall the battery cover. 3. When battery voltage is low, the ‘Low battery’ indicator will show up on the Console display. SPEED SENSOR TRANSMITTER BATTERY INSTALLATION 1.
  • Page 20 In Power Saving Mode”, pressing Page key will bring the console to “Quick Start” active state. MODE SELECT Press MODE key to select the DIST, KCAL display. RESETTING ALL MEASURED VALUES To clear all the measured values, press and hold key under the TIME Mode for 3 seconds. All the measured value for AVG SPEED, AVG PULSE, TIME, DIST, KCAL will reset to zero.
  • Page 21 HEART RATE TARGET ZONES Hold the PAGE key for 3 seconds to enter the settings screen. Press MODE and choose the heart rate icon, then press the PAGE key to select the heart rate target zones window. Press the MODE key to increase the maximum heart rate limit.
  • Page 22 PAIRING CONSOLE TO BION FITNESS APP 1. Download the Bion Fitness App (Google Play) 2. Open the app and press the smartphone icon on your bike console. 3. The app will search for the console, and the bike console will display the pairing interface. 4.
  • Page 23 PAIRING THE CONSOLE AND TRANSMITTER NOTE: ALL TRANSMITTERS ARE PAIRED WITH THE CONSOLE BEFORE SHIPPING. THESE STEPS SHOULD ONLY NEED TO BE USED IN CIRCUMSTANCES WHERE THE DEVICES HAVE BEEN UN- PAIRED. 1. Hold both MODE and SET keys on the console for 3 seconds. 2.

  • Page 24: Troubleshooting

    count up or count down after 3 seconds. TROUBLESHOOTING Cadence number jumps high or low 1. Separate bikes that may be paired to the same No Display on Console console code and are cross-talking, or simply run 1. Press any key to bring the console to ‘Quick Start’ transmitter pair stage again on the bike.
  • Page 25 The pitch of the saddle can be adjusted to accommodate all users. Loosen the horizontal bolt under the seat to adjust the pitch, then retighten. TRANSPORTATION The indoor cycle is equipped with two transport wheels, which are engaged when the rear of the CIC850 indoor cycle is lifted. www.spiritfitness.ca...
  • Page 26 Take some time to learn how to properly adjust the bike to your body; it will make your workouts more pleasant and a safer experience too. Riding the bike when it is incorrectly adjusted can result in discomfort and increase your risk of injury.
  • Page 27 HANDLE BAR ADJUSTMENT HANDLEBAR HEIGHT ADJUSTMENT 1. The handlebar height is a matter of preference. Start with a handlebar height that is the same as the seat’s height. Adjusting the handlebar higher will give the rider a more upright posi- tion;...
  • Page 28 RESISTANCE ADJUSTMENT Resistance can be adjusted easily at any time while riding to change the intensity of workout. Turn the knob clockwise (+) to increase resistance. Turn the knob counterclockwise (-) to decrease resistance. EMERGENCY BRAKE In case of emergency or before dismounting the indoor cycle, presses directly DOWN on PEDAL STRAP ADJUSTMENT Place the ball of you feet in the toe clip till the front of the shoe is snugly in the cage.
  • Page 29 BELT TENSION ADJUSTMENT you may need to make the minor tension adjustment over time. NOTE: keep in alignment with the frame. ADJUST THE BELT TENSION 1. Remove the 2 Guard (Top) Cover (122) on the Guard (top) (121) . Remove the 4 Screws (125) and 2 Screws (126) .

  • Page 30: General Maintenance

    GENERAL MAINTENANCE 1. Wipe down all areas in the sweat path with a damp cloth after each workout. 2. If a squeak, thump, clicking or rough feeling develops the main cause is most likely one of two reasons: during assembly need to be tightened as much as possible. It may be necessary to use a larger wrench than the one department for noise issues can be traced to loose hardware.
  • Page 31 INDOOR CYCLE WARRANTY Spirit Fitness warrants all its Indoor Cycle parts for a period of time listed below from the date of retail sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date.
  • Page 32 EXCLUSIONS This warranty does not cover the following: 1. CONSEQUENTIAL, COLLATERAL, OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY. Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation or exclusion may not apply to you.
  • Page 33 SERVICE Keep your bill of sale. Twelve (12) months from the date on the bill of sale or eighteen (18) months from the date of factory shipping as determined by the serial number establishes the labor warranty period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This written under this warranty must be obtained by following these steps, in order: 1.

  • Page 34: Exploded Drawing

    CIC850 Exploded Drawing CIC850 19 23 20 72 26 125 28 128 118 119 71 71 71 135L 125 123 25 25 120 59 136R 64 67 Spirit Fitness...

  • Page 35: Parts List

    CIC850 PARTS LIST DESCRIPTION DESCRIPTION Frame Brake knob--cover Outer circle tube assembly Flat cross head screw (UCP)M4*P0.7*10L Front stabilizer assembly Knob bolt block Transportation wheel Pop pin knob( short) Flat washer SUS304 M8(D19*d8.5*1.0t) Flat cross head screw SUS304 M3*P0.5*6L Nylon nut SUS304 M8*P1.25 Flat cross head screw SUS304 M4*P0.7*8L...
  • Page 36 DESCRIPTION DESCRIPTION Bearing-6203ZZ Flat cross head screw SUS304 M8*P1.25*12L Flywheel set C type clip Aluminum Ring Idler pully adjust screw Flywheel AXIS Idler pully positioning nut Flat cross head screw SUS304 M5*P0.8*16L Flat cross head screw SUS304 M8*P1.25*55L Flat cross head screw M8*P1.25*10L Flat washer M8(D16*d8.2*1.0t) Permanent magnet Idler pully casing...
  • Page 37 DESCRIPTION DESCRIPTION Brake Spring Square plastic bushing Brake line Flat washer SUS304 M8(D16*d8.1*1.6t) PE Wahser Flat cross head screw SUS304 M6*P1.0*20L Nylon nut SUS304 M8*P2.0 Star-type pop pin knob Slider block Water bottle holder Nylon nut SUS304 M5*P0.8 Tablet Holder Fixed pulley Fixed base assembly Nylon bushing (black)
  • Page 38 DESCRIPTION Chian guard up Chian guard up cover Brake guard right Brake guard left Flat cross head screw M5*P0.8*14L Flat cross head screw M5*P0.8*25L Round head Phillips tapping screws Flat washer M5(φ5.3*φ10*1t) Nylon nut SUS304 M10*P1.5 Flat washer (D16*d10.2*1.0t) Hex screw M6*P1.0*20L Hex nuts (UCP)M6*P1.0*5.0t Hex nuts (UCP)M16*P1.5*7.8t Flat cross head screw M8*P1.25*15L...
  • Page 39 www.spiritfitness.ca...
  • Page 40 1.888.707.1880 Dyaco Canada Inc. sales@dyaco.ca 5955 Don Murie St. Niagara Falls, ON www.spiritfitness.ca L2G0A9 Canada CIC850 Owners Manual © 2020 All Rights Reserved...
