Billion BiGuard S3000 Specifications

Features & Specifications
BiGuard S6000
Gigabit Dual-WAN SSL/IPSec VPN Security Gateway
Recommended organizations Medium-sized enterprises with 500 to 1,000 employees
Concurrent SSL VPN tunnels Up to 200, basic 50 tunnels
Concurrent NAT sessions 120,000
Processor / Flash Multi-Core MIPS64 / 64MB
1GB
Memory
SSL VPN
Access Connections
• Network Extender • Application Proxy
• Standalone Network Extender client • Personalized Web Portal
• Transport Extender (TCP / UDP) • Single Sign-On (SSO)
• Network Place • SSL hardware accelerator
Applications & Management
• Network File Share (CIFS) • WOL (Wake On LAN)
• Supports Citrix • AD / LDAP account import
• Terminal services (RDP5, RDP6) • Account membership
• File Transfer Protocol (FTP) • Granular user policy management
• Telnet • Supports mobile devices (Microsoft
• Supports MS Outlook Web Access (OWA) Windows Mobile 5.0 / 6.0 or compatible)
• Virtual Network Computing (VNC) • Supports MS IIS NTLM
• Secure Shell (SSH, SSHv2) support (NT LAN Management) authentication
• SRDP (Single Remote Desktop Protocol) • SSL event log and monitor
• Web based data (HTTP, HTTPS)
Security
• User access control • Digital certificate
• Web cache cleaner • Authentication domains: RADIUS,
• End Point Security (EPS) checking LDAP, Active Directory, NT Domain,
• Host security checking Local database
• Self-Signed certificate • SSL encryption
Compatible Web Browsers *1
• Microsoft Internet Explorer 6.0 and • Firefox 1.5 and newer versions
newer versions • Safari 2.0 and newer versions
• Netscape 7.0 and newer versions • Mozilla 1.7 and newer versions
• Opera 9.0 and newer versions • Sun JRE 1.3 and newer versions
Supported Operating Systems *1
• Microsoft Windows, Linux, and Apple Macintosh
Firewall & Content Filtering
• Stateful Packet Inspection (SPI) • Intrusion detection
• Denial of Service (DoS) prevention • URL filter
• Packet filter • Java Applet/Active X/Cookie
blocking
Quality of Service Control
• Supports DiffServ approach • Traffic prioritization and bandwidth
management based on IP protocol,
port number and IP address
Web-Based Management
• Easy-to-use web based user interface • Multi-language web interface
• Group account settings on access • Remote dial-in configuration (RS-232)
applications (CLI for RS-232 port)
• Firmware upgrades through web-based • Supports BiGuard CMS for centralized
interface management
• Local and remote management through
HTTP and HTTPS
*
Notes:
1. Please refer to http://www.billion.com/product/biguard/sslvpnbrowser.htm for updates of all supported browsers and OS platforms.
2. Users are strongly recommended to register the products on www.biguard.com in order to be able to use the update feature and firmware upgrades.
Copyright © Billion Electric Co., Ltd. All rights reserved. V.123008
TEL: +886-2-29145665
Billion Electric Co., Ltd.
FAX: +886-2-29186731, +886-2-29182895
8F, No. 192, Sec. 2, Chung Hsing Road,
E-mail: sales@billion.com
Hsin Tien City, Taipei County, Taiwan
BiGuard S3000
Gigabit Dual-WAN SSL/IPSec VPN Security Gateway
Small and medium sized businesses with 150 to
500 employees, or enterprise departments
Up to 50, basic 10 tunnels
80,000
Multi-Core MIPS64 / 64MB
512MB
IPSec VPN
• 30 IPSec VPN tunnels • IP Authentication Header (AH)
• Internet Key Exchange (IKE) • IP Encapsulating Security Payload (ESP)
authentication and Key Management • Dynamic VPN (FQDN) support
• Authentication (MD5/SHA-1) • Supports remote access and office-to-
• DES/3DES encryption office IPSec connections
• AES 128/192/256 encryption
Availability and Resilience
• Load balancing • Automatic fail-over and VPN fail-over
- Traffic management • High availability (device redundancy)
- Protocol binding
Logging and Monitoring
• Centralized logs • E-mail alerts and intrusion logs
• System log • System status monitoring
Network Protocols and Features
• Static IP, PPPoE and DHCP client • DHCP server
connection to ISP • SNTP
• NAT, static routing and RIP1/2 • SNMP
• Dynamic Domain Name System (DDNS) • Multi-NAT
• Router mode • Transparent bridging
• Virtual server • Port-based VLAN
Hardware Specifications
Physical Interface
• 2 x 10/100/1000Mbps Gigabit WAN ports • 2 x USB 2.0 hosts (future extension)
• 8 x 10/100/1000Mbps Gigabit LAN ports • RS232 console port
• 1 x RS232 Serial port • Power switch
• Reset button
Physical Specifications
• 1U rack-mount • Dimensions: 19" x 8.27" x 1.73"
(482 x 210 x 44mm with bracket)
(390 x 210 x 44mm without bracket)
Power Requirements
• Input Voltage (Operation): • Efficiency: 80% @115Vac/60Hz or
90 to 264VAC full range 230Vac/50Hz at max. load
• Input Frequency (Operation): • Output power: 12V/3.5A (42W)
47 to 63Hz • Power Supply MTBF 100,000 hours
• Input Current: at 25°C (110Vac & 220Vac)
Max. 0.95A @115Vac/60Hz at max. load
Operating Environment
• Operating temperature: 0 to 40°C • Humidity: 20 to 95% non-condensing
• Storage temperature: -20 to 70°C
Support and Services
*2
• Feature and Firmware Upgrades for 1 year • Hardware Warranty for 1 year
www.billion.com
Gigabit Dual-WAN SSL/IPSec VPN SME
Appliance Series
Great Mobility and Productivity
The BiGuard Gigabit Dual-WAN SSL/IPSec VPN SME Appliance Series integrates cutting-edge SSL VPN technology for
SMEs to establish private encrypted tunnels, without the need for VPN software pre-installation on client PCs, through the
public Internet to securely access corporate resources from any location, such as a branch office, hotel, home, cyber café, or
even a public kiosk. It offers corporate-class advanced SSL VPN connections such as Network Extender, Transport Extender,
and Application Proxy. Remote users using different kinds of browsers, platforms and operating systems can all access files in
the central office. External business partners or business travelers, even using just MS Outlook Web Access (OWA), can be
authorized to access the corporate network from a remote site as if they never left the office. A business traveler using a
mobile device like a PDA can access the corporate network, the SOHO or a freelancer on a Macintosh can even connect his
Mac to customers' networks to remotely collaborate on a project. Secure remote Intranet access with BiGuard Gigabit
Dual-WAN SSL/IPSec VPN SME Appliance Series is possible via any device from anywhere any time.
Powerful Gigabit Connectivity
Not only sharing files, checking e-mail, and downloading documents, but also remote access to applications like Enterprise
Resources Planning (ERP) applications or remote surveillance; all of which are needed by today's SMEs and enterprise
departments for diverse remote access needs. Billion continues to provide advanced enterprise-class BiGuard SSL VPN
appliances. Imbedded with high-performance CPUs, the BiGuard Gigabit Dual-WAN SSL/IPSec VPN SME Appliance Series
Key Features
features Gigabit capability for LAN, WAN and DMZ ports, enabling faster transmission speeds, no matter for remote access,
internal connections or outbound networking. This design gives small-and-medium sized enterprises an edge in today's
• Dual WAN
business environments where mobile workers, business partners and traveling employees are increasingly on the road, and
for whom connectivity problems and data security should be the last thing on their mind.
• Auto fail-over and load balancing
• Device redundancy for high availability
Flexibility, Scalability and Resilience
• Both LAN and WAN Gigabit connectivity
Both SSL VPN and IPSec VPN are remote access solutions and complementary technologies. The BiGuard Gigabit
• SSL VPN gateway plus solid router
Dual-WAN SSL/IPSec VPN SME Appliance Series offers both IPSec VPN and SSL VPN capabilities combined in a single
platform. This design provides excellent deployment flexibility to SMEs for meeting the requirements of both remote access
functions
and Lan-to-Lan branch office connections. Load balancing and auto fail-over features are integrated to ensure optimal
• Clientless connectivity
bandwidth sharing for multiple PCs in your office, or provide network redundancy in case one connection should fail. All of
• Wide range of web browsers supported these are to keep your business online for mission-critical or important Internet-based applications.
• Rich in SSL VPN access connections
Single Box with Low Cost of Ownership
• Granular access policy management
Billion's BiGuard Gigabit Dual-WAN SSL/IPSec VPN SME Appliance Series integrates SSL VPN, IPSec, firewall and router
• Windows / Linux / Macintosh supported
functions in one single box. Thanks to integrated IPSec VPN access technology, the additional cost for deploying extra
platforms for IPSec VPN is eliminated. Aimed at a low total cost of ownership, the BiGuard SSL VPN box is affordable for
• Mobile devices supported
SMEs. IT administrators no longer need to buy an extra device to manage remote Intranet access, nor install and maintain
• AD / LDAP account import
additional equipment for data security. The integrated router and firewall functions provide administrators with a perfect
• Group account setting solution to manage all connections and file sharing of remote access. It is easier to simply integrate these functions into one
BiGuard SSL VPN device instead of buying several independent networking devices.
• WOL (Wake On LAN)
• Personalized web portal
Ease of Management
• Data encryption, user authentication
Managing various groups of remote users for certain access applications and policies and maintaining the user accounts in a
SME are a hassle for IT administrators. Group Account Setting featured in the BiGuard Gigabit Dual-WAN SSL/IPSec VPN
and access control
SME Appliance Series address administrators' concerns. AD/LDAP Account Import makes it easy for IT administrators of
• End Point Security (EPS) checking
enterprises to manage intranets by importing existing accounts from AD/LDAP servers into a BiGuard SSL VPN device. IT
• Host security checking administrators configure the gateway to control the resources and applications available to different groups of users. Access
policies, authorizations and authentication mechanisms can all be set up as well. After this setting, each user will have an
• IPSec VPN capabilities
easy-to-manage Personalized Web Portal, which displays the applications according to the user's access settings.
• Robust firewall security
• Quality of Service control Comprehensive Security
The security of remote access is even more concerned by IT administrators. The BiGuard Gigabit Dual-WAN SSL/IPSec VPN
Other Options
SME Appliance Series supports rich advanced security features. The support of cache cleaner function makes sure that the
user's data will be cleaned up without record after user's log out from a remote site. The End Point Security (EPS) function
enables IT administrators to check the identity of a remote PC and its security policy settings when a user logs in from that
• InstantChat Support 24 x 7 Service
device. Granular Access Control makes setting up different users allowed to access different applications possible. One-Time
• Feature and Firmware Upgrades
Password enforces the user to input different password every time when log in. Access Policy settings enable administrators
• BiGuard SSL VPN Tunnel Upgrades to set up different users with different access rules. Strong firewall security provides access protection from hackers and other
attacks. Access security with the BiGuard Gigabit Dual-WAN SSL/IPSec VPN SME Appliance Series, no matter locally or from
• BiGuard Central Management System
remote sites, is assured with these comprehensive security features.
• BiGuard One-Time Password
Management Options for Growth
A total SSL VPN solution is made possible by offering optional support: SSL VPN Tunnel Upgrades, BiGuard's Central
Management System, and BiGuard One-Time Password (OTP). In case of a growing need for remote access, just upgrade
the BiGuard SSL VPN gateway by adding more SSL VPN tunnels. The Central management System enables
administrators in the head office or service providers to centrally manage all the BiGuard SSL VPN devices,
which enable remote configuration from a central site to save on maintenance efforts. In addition, the
BiGuard OTP, a car-key sized token, is used to create a two-factor authentication by using a
dynamically generated 6-digit PIN. Combined with your existing static password this results
in a greatly reduced risk of unauthorized access to corporate network resources by
intruders. The Feature and Firmware Upgrades and BillionCare services
are also available for a certain duration from purchase date
and continues optionally after that.
