ABB Discrete I/O Applications Manual page 39

Description
Input current level Lo
Input current level Hi
Max voltage
Reverse polarity protected
Surge protected
Delay time
Analog inputs
Description
Input range
Resolution
Inaccuracy
Input impedance
Reverse polarity protected
Surge protected
Delay time
Analog outputs
Description
Output range
Resolution
Inaccuracy
Min load impedance
Surge protected
Short circuit protection
Delay time
Relay outputs
Description
Max switching voltage
Max switching current
Isolation
Application manual - Discrete I/O
3HAC070208-001 Revision: C
Data
<0.5 mA
>2 mA
30 V
Yes
Yes
0.5 – 65 ms
Data
0 – 10 V
12 bits, 2.44 mV
0.5% + 25 mV
100 kOhm
Yes
Yes
2ms
Data
0 – 10 V
12 bits, 2.44 mV
0.5% + 25 mV
1 kOhm
Yes
Yes
2 ms
Data
230 VAC
2 A
Reinforced
© Copyright 20192020 ABB. All rights reserved.
2 Hardware overview
2.5 Technical data
Continued
Note
typically 4mA
programmable
Note
typically
Note
Note
39
