2 Hardware overview

2.5 Technical data

2.5 Technical data
Technical data
Supply voltage
Description
Voltage range
Input current, Digital base, 24V SYS
Input current, Digital base, 24V
Process
Input current, Digital add-on, 24V
Process
Input current, Analog add-on, 24V
Process
Input current, Relay add-on, 24V
Process
Plug-in current
Surge protected
Reverse polarity protected
Digital outputs
Description
Rated current
Max current
Typical short circuit current
Leakage current
Rated voltage
Max voltage
Max voltage drop
Max inductive load
Max capacitive load
Recommended cable area
Surge protected
Thermal protection
Max delay time
Digital inputs
Description
Input voltage level Lo
Input voltage level Hi
Typ switch voltage
Continues on next page
38
Data
20.4 – 28.8 VDC
100 mA (TBC)
8 A
8 A
100 mA (TBC)
100 mA (TBC)
<2 A @ 1ms
Yes
Yes
Data
500 mA
600 mA
1200 mA
< 100 uA
24 VDC
30 VDC
0.5V at 500 mA
1000 mH
10 mF
1 mm
Yes
Yes
0.5 ms
Data
-30 - 5 V
15 - 30 V
10 V
