Berkel 919A Specifications

Model 919A
C
Safety and Convenience Features
Berkel Model 919A automatic gravity feed slicer features
Berkel's time proven hollow ground stainless steel knife,
built-in, single lever, dual-action sharpener and many safety
features. The permanent, tapered guard covers the non-
slicing portion of the knife even when the sharpener and
center plate are removed. The gauge plate interlock
prevents the product table from being removed unless
it is in the full forward or home position and the gauge
plate is closed. Removing the product table locks the
gauge plate in the closed position. The center plate
interlock prevents the slicer from operating if the center
plate is removed. A built-in timer automatically shuts off
the unit after 15 seconds of non-use. The unit is easy to
clean and disassembles quickly without tools.
Accessories
Stainless steel vegetable
chute with pusher
Skewers with coring tool
Sharpening kit
Receiving tray
Product fence
Approved By:
Date
Berkel Company • 4406 Technology Drive • South Bend, IN 46628-9700
574-232-8222 • 800-348-0251 • FAX 888-888-2838 • www.berkel.com
Form #SPC10-0902N
Item #
Model 919A
Automatic Gravity Feed Slicer
Standard Features
2-speed, 1/2 HP, totally enclosed and permanently
lubricated knife motor
2-speed, automatic carriage; low speed is 40 SPM,
high speed is 60 SPM
Furnished in 115/60/1, 5.5/4.5 amp, AC, ETL listed; also
available in 1/3 HP, 230/60/1, 2.9 amp, AC, ETL listed
Low 12/5 VDC circuitry for added operator protection
Finish is stainless steel and sanitary burnished aluminum;
unit disassembles quickly without tools for easy cleaning
Nominal 12-1/2" (318 mm) diameter, hollow ground,
hardened and polished forged stainless steel knife
The carriage handles food up to 11" (280 mm) wide,
by 6" (152 mm) high or 8" (203 mm) diameter
Rear-mounted, stainless steel meat pusher extends over
the entire length of the product table; a fence is provided
to control the product on the table
Precise slice adjustment to a thickness of
27/32" (21 mm)
Ergonomic style handle for ease of use
Built-in, top-mounted, two stone knife sharpener with
single lever, dual-action system
Permanent, tapered knife ring guard covers non-slicing
portion of knife even when the sharpener and center
plate are removed
Center plate interlock prevents the slicer from running
when center plate is removed
No-Volt release prevents activation of the slicer in
the event of power interruption; operator must
restart the slicer
Gauge plate interlock prevents removal of the product
table until it is in the full forward or home position and the
gauge plate is fully closed; once table is removed, gauge
plate cannot be reopened
Built-in timer automatically shuts the slicer off after15
seconds of non-use
4" Extension NSF
Q-P-Q nickel plated transport slide rod with reservoir wick
legs (set of 4)
for reduced wear
SURE-LOCK LIFT™
On/off, 3-position, moisture protected switch, with power
light
Slaw tray
Attached 6-foot, flexible, 3-wire cord and plug for
Juice cup
grounded receptacle
Options
1/3 HP, 230/60/1, 2.9 amp, AC, ETL listed
