Instructions Manual
Positive Input Ventilation Unit - Everdri XEL & XELH
Product Number: 110015 Everdri XEL
110022 Everdri XELH
Glen Dimplex UK LTD, trading as,
Glen Dimplex Heating & Ventilation
Web: www.gdhv.co.uk
Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF.
Customer Service Tel: +44 [0]344 879 3588
www.xpelair.co.uk
© Glen Dimplex. All rights reserved. Material contained in this publication may not be reproduced in whole or in part, without
prior permission in writing of Glen Dimplex
Advertisement
Table of Contents
Related Manuals for Xpelair Everdri XEL
Summary of Contents for Xpelair Everdri XEL
- Page 1 Instructions Manual Positive Input Ventilation Unit - Everdri XEL & XELH Product Number: 110015 Everdri XEL 110022 Everdri XELH Glen Dimplex UK LTD, trading as, Glen Dimplex Heating & Ventilation Web: www.gdhv.co.uk Millbrook House, Grange Drive, Hedge End, Southampton, SO30 2DF.
-
Page 2: Important Notes
Important Notes In this manual, especially important notes are marked as WARNING! or NOTE! WARNING: Warnings against hazards and errors that can cause severe or fatal injuries or can have serious consequences for the product. NOTE! Useful notes and additional information. This manual forms part of the ventilation unit and must be kept readily available at all times. -
Page 3: Installer Information
Installer Information WARNING: READ THE ENTIRE INSTRUCTION MANUAL BEFORE COMMENCING THE INSTALLATION Everdri XEL Ventilation Unit 125mm Solid Duct 125mm to 150mm Adapter 150mm Jubilee Clip 150mm Flexible Duct 150mm to 200mm Adapter 200mm Diffuser Mounting Ring 200mm Supply Air Diffuser... -
Page 4: Installing The Diffuser
Installing the Diffuser Prepare a hole in the ceiling. Using the mounting ring as a template, drill 4 holes and fix using the screws provided. Finally, screw the valve body into the ceiling mounted ring. Location of the Ventilation Unit Locating the ventilation unit in a well-ventilated loft space is recommended to ensure sufficient fresh air is available. -
Page 5: Installing The Ventilation Unit
Installing the Ventilation Unit The ventilation unit must always be firmly fixed through the four mounting points provided Ensure the unit is installed by either of the following methods: Using suitable wood screws with a head size ≥8mm Using threaded bolts ≤5mm with a head size ≥8mm NOTE: The ventilation unit is well balanced however, if desired, antivibration mounts with threaded bolts ≤5mm could be used. - Page 6 If you have any queries regarding the installation of this product, please call the Technical Hotline. Our engineers are there to help during normal office hours (UK only) and may be faxed at all times. Customers outside the UK please contact your local Xpelair distributor, details of which are available from the UK office. December 2020...
- Page 7 Commissioning and Speed Control The Everdri has potentiometer speed control, this enables the air flow to be set for your specific systems requirements, while maximising energy efficiency. Each speed (trickle, speed 1 and speed 2) has an individual potentiometer which is adjustable from 0-100% of the total fan performance.
- Page 8 Alternative Switch Option Connection with a three speed selector switch Connection with sensors or several change over switches December 2020 08/100245/0...
- Page 9 Installation of Smoke Detector or CO Detector (optional) To enable the safe cut-out of the ventilation system in case of fire, the ventilation unit can be connected to an optional smoke detector or CO detector with a volt free output. The smoke or CO detector must be normally closed (NC) and will go open circuit (OC) in the event of a fire.
-
Page 10: User Information
The fan is designed to run continuously 24 hours a day. It is fitted with an energy efficient electronic motor. Manual Override Switch Control Options The Everdri XEL system is supplied with a Manual over-ride switch, allowing you to switch between a low trickle speed (in Automatic mode) and 2 additional speeds in Manual mode. The high-speed setting is a boost position to allow for the extract of cooking smells or moisture-laden air. -
Page 11: Hours Run Meter
Hours Run Meter Both XEL and XELH ventilation units incorporate an hour run meter that allows the installer to measure the actual running time of the fan after installation. The meter records continuous power supply on time and displays this via an on-board red LED that always flashes to indicate the total number of hours the supply has been on. -
Page 12: Additional Information
Additional Information Technical Data Speed Air flow rate (l/s) Power (W) Trickle Sp.1 Sp.2 Switches and Controller Options Change Over Switch COS Passive Infrared Sensor XPIRA Manual Override Switch MOS (Supplied) Ref. 90108AW Ref. 21871AA Ref. 90199AW Remote Humidistat XRH Time Delay Unit DT20B Air Quality Sensor AQS Ref. -
Page 13: Customer Service And Warranty
Guarantee UK: This ventilation unit is guaranteed against defects for 5 years from date of purchase. Xpelair reserve the right to repair or replace the unit. Keep your purchase receipt. Any problems, contact the address below. Outside the UK: See International section. -
Page 14: Environment And Disposal
International Guarantee – Contact your local distributor or Xpelair direct. Technical advice and Service – Contact your local Xpelair distributor. NOTE: Please be prepared to tell us the exact device type and serial number S/N, for your ventilation unit so that we can process your enquiry, customer service order or complaint correctly.
