Installation and maintenance instructions
DX100
DX100PC
DX100T
DX100H
DX100HP
DX100PIR
DX100VTD
Toilet/Bathroom 100mm/4" Fan Range
Retain for future reference
Standard
Pull Cord
Time
r
Humidistat
Humidistat and Pull Cord
Integral Body Movement Sensor
Delay Timer
