Summary of Contents for Rointe Capri CWI700DHWU4
- Page 1 Capri Water heater INSTRUCTION & INSTALLATION GUIDE...
-
Page 3: Table Of Contents
3. Hydraulic installation.................................7 4. Electric installation................................8 5. Safety precautions..................................9 6. Use (Putting into operation)..............................9 7. Maintenance ...................................11 8. Rointe Product Guarantee...............................11 9. European Directive..................................13 10. Dimensions & Technical Characteristics..........................13 11. Certificate of Guarantee................................15 ATTENTION Thank you very much for choosing the CAPRI water heater model, made with the highest quality components designed for you. -
Page 4: Important Rules
1. IMPORTANT RULES Attention! Improper installation and connection of the appliance may make it hazardous for the health and life of consumers. It may cause grievous and permanent consequences, including but not limited to physical injuries and/or death. Improper installation and connection of the appliance may also lead to damage to the consumers’... -
Page 5: Installation And Connecting
2. INSTALLATION AND CONNECTING Attention! Improper installation and connection of the appliance may make it hazardous for the health and life of consumers. It may cause grievous and permanent consequences, including but not limited to physical injuries and/or death. Improper installation and connection of the appliance may also lead to damage to the consumers’... - Page 6 Fig.2 · Place the holder onto the wall and mark the holes for attaching · Drill holes and install the fixing plugs in them. Place the holder, tighten the screws then place the ornamental caps on top of the screws ·...
-
Page 7: Hydraulic Installation
2.4. IN LINE models The incoming and the leading-out pipes of the appliance have R1/2” fastening thread.The inlet and the outlet are indicated by arrows on the back lid of the appliance (or on the tubes themselves). The arrows show the direction of the water flow. -
Page 8: Electric Installation
the flexible hose)! After connecting the appliance and before turning on the electric supply, open the tap until steady jet of water starts running from the shower head! 3.4. IN Line models – fig. 5 The incoming and the leading-out pipes of the appliance have R1/2” fastening thread.The inlet and the outlet are indicated by arrows on the back lid of the appliance (or on the tubes themselves). -
Page 9: Safety Precautions
The connecting of the conductors of the supply cord of the appliance has to be carried out as follows: · Conductor with brown insulation – to the phase conductor of the electrical wiring (L) · Conductor with blue insulation - to the neutral conductor of wiring (N) ·... - Page 10 · Switch off power to the appliance- if the model is fitted with a cord and a plug – unplug it from the socket. For the other models – switch off the shut-down device built into the wiring of the appliance (see item 3.1 and item 3.2 from section VI) ·...
-
Page 11: Maintenance
ROINTE. Any incident that you might detect in your ROINTE product can be sorted by the product seller or quickly by the manufacturer. Please contact ROINTE by telephoning 0203 321 5929 for Technical Support. Alternatively, you can email ROINTE at support@rointe.co.uk, through which we will instruct you on how to solve the... - Page 12 ROINTE as well as incorrect installation or use of the product that may not comply with the current technical standards of safety.
-
Page 13: European Directive
The symbol of the container crossed out over a horizontal line is marked on all of ROINTE products to remind the consumer of the obligation to separate them on disposal. The consumer should contact the local authority or original point of sale to learn more about the correct disposal of this product. - Page 17 NOTES...
- Page 18 NOTES...
- Page 19 NOTES...
- Page 20 Capri Water heater Rointe Spain & Portugal P.I. Vicente Antolinos C/ E, parc. 43 30140 Santomera (Murcia) T. (ES) 902 158 049 T. (PT) 221 200 114 www.rointe.com www.rointe.pt sat@rointe.com Rointe UK & Ireland Catalyst House, 720 Centennial Court, Centennial Park, Elstree, Herts, WD6 3SY T.
