User Manual
Geneva water heater
Models
50 litres | 80 litres | 100 litres
Please read this manual carefully before installation and operation. Please keep this manual for future
reference and your product guarantee conditions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Geneva 050DHW4 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rointe Geneva 050DHW4

  • Page 1 User Manual Geneva water heater Models 50 litres | 80 litres | 100 litres Please read this manual carefully before installation and operation. Please keep this manual for future reference and your product guarantee conditions.
  • Page 2: Table Of Contents

    Thank you for choosing this product. Please read this manual carefully before operation and retain for further use. ROINTE water heaters have passed the most stringent quality controls to meet all necessary safety requirements. It is therefore imperative that this product is only installed by a trained and competent person as defined in the relevant regulations.
  • Page 3 IMPORTANT: To disconnect the product from the main power supply, remove the plug from the socket. Do not pull the cable. WARNING: If the power cable is damaged, it must be replaced by ROINTE or its authorized personnel in order to avoid any damage.
  • Page 4: Components

    All taps and fittings incorporated in the unvented system should have a rated operating pressure of 0.7 MPa or above. We recommend using a Rointe Trusted Supplier. Find your nearest one by calling us on 0203 321 5928 or using the locator at www.rointe.co.uk.
  • Page 5 WARNING: Do not install the product directly below a fixed socket outlet or connection box. Do not install or use outdoors. Do not install directly underneath a shelf. This product is designed for internal wall-mounted installation using the ROINTE template, installation kit and fixing items provided.
  • Page 6: Installation - Plumbing

    4. INSTALLATION - PLUMBING Figure 2 - Cylinder connection arrangement DESCRIPTION Mains cold water supply Stop Cock (not included) Pressure reducing valve* Check valve* Expansion relief valve* Discharge pipe (22 mm) Drain Cock (not included) Tundish* Expansion vessel* T/P relief valve (included) Electrical fittings (included) * Available in installation kit 4.1.
  • Page 7 GENEVA UNVENTED WATER HEATER 4.4. Temperature and pressure relief valve The temperature and pressure relief valve (T/P Valve) is supplied (Figure 2). Once the T/P valve is fitted it should not be removed from the cylinder or tampered with in any way. The valve is pre calibrated to lift at 0.7 MPa or 90oC and any attempt to adjust it will render the guarantee null and void and could affect the safety performance of the unit.
  • Page 8 a) Be at least one pipe size larger than the normal outlet size of the safety device unless its total equipment hydraulic resistance exceeds that of a straight pipe 9m long, i.e. discharge pipes between 9m and 18m equivalent resistance length should be at least two sizes larger then the normal outlet size of the safety device, between 18m and 27m at least three sizes larger and so on.
  • Page 9 GENEVA UNVENTED WATER HEATER Figure 3 - Typical discharge pipe arrangement Table 1 - Sizing of copper discharge pipe “D2” for common temperature relief valve outlet sizes Valve outlet Max. resistance Min. size of Min. size of Resistance size allowed (length of discharge discharge created by each...
  • Page 10: Installation - Electrical

    Calculated Example 1 The example is for a 1/2” diameter temperature relief valve with a discharge pipe (D2) having 4 x 22 mm elbows and a length of 7 m from the tundish to the point of discharge. The maximum resistance allowed for a straight length of 22 mm copper discharge pipe (D2) from a 1/2”...
  • Page 11: Filling, Commissioning And Operation

    If water is seen dripping through the tundish at any time switch off the electricity supply immediately and call the installer or the Rointe Technical Service department on 0203 321 5929.
  • Page 12: Troubleshooting

    6.3. Operation To turn the product on/off, press the red switch on the front of the product. A light will come on when the product is switched on. To adjust the temperature, use the temperature dial located next to the on/off switch. To increase temperature turn the dial to the right.
  • Page 13: Maintenance And Cleaning

    Before any work is carried out on the installation, it MUST first be isolated from the mains electricity supply. Only use spare parts authorised by Rointe. The use of other parts will invalidate the warranty.
  • Page 14: European Directive (Weee) 2012/19/Ue

    The symbol of the container crossed out over a horizontal line is marked on all of ROINTE products to remind the consumer of the obligation to separate them on disposal. The consumer should contact their local authority or council office, or original point of sale to learn about the correct method of disposal for this product.
  • Page 15 Any accidents that are deemed outside the control of ROINTE, such as (but not limited to): lightning, fires, floods, natural disasters, public disorder, atmospheric or geologic phenomena etc.
  • Page 16: How To Register

    2.8. The product has not been subjected to excessive pressure or electrolytic actions from dissimilar materials or attack from salt deposits. 3. The ROINTE Technical Support department will advise you if you need to purchase any parts not covered under this guarantee or out of guarantee.
  • Page 17 GENEVA UNVENTED WATER HEATER IMPORTANT: It’s important to register your ROINTE product as part of our guarantee service, in case you wish to make a claim. You can register your ROINTE product in the following ways: WEBSITE Go to www.rointe.com/uk/register-your-guarantee/.
  • Page 18: Commissioning And Service Record

    11.1. Commissioning record CUSTOMER DETAILS Model: Telephone: Address: PRODUCT DETAILS Model: Product ref: Capacity (litres) Serial no: INSTALLER DETAILS Company name: Date: Address: Telephone: Installer name: Registration no. COMMISSIONING ENGINEER (IF DIFFERENT) Company name: Date: Address: Telephone: Installer name: Registration no. 11.2.
  • Page 19: Technical Specification & Data

    GENEVA UNVENTED WATER HEATER 12. TECHNICAL SPEC 050DHW4 080DHW4 100DHW4 MODEL Volume (L) MATERIALS Vitrified steel tank CFC-free ployurethane foam Basic control panel made of PP Copper heating elements DIMENSIONS, WEIGHTS & FINISHES Diameter (mm) Height (mm) Installed depth (mm) Distance between connections (mm) Water connection (““) Empty weight (kg)
  • Page 20 6 Rue Duret, 75116 Paris T. 01 73 05 70 01 ª ” ~ “ ± Copyright © Rointe Heating 2020. All rights reserved. As part of our continuous improvement policy, we reserve the right to alter or modify any product or specifications without notice.

This manual is also suitable for:

Geneva 080dhw4Geneva 100dhw4
