NV9642
NV9000 Control Panel
User's Guide
UG0047-02
20 Nov 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Grass Valley NV9000 and is the answer not in the manual?

Questions and answers

Related Manuals for Belden Grass Valley NV9000

Summary of Contents for Belden Grass Valley NV9000

  • Page 1 NV9642 NV9000 Control Panel User’s Guide UG0047-02 20 Nov 2014...
  • Page 2 Copyright & Trademark Notice Copyright © 2014 Grass Valley. All rights reserved. Belden, Belden Sending All The Right Signals, and the Belden logo are trademarks or registered trademarks of Belden Inc. or its affiliated companies in the United States and other jurisdictions.
  • Page 3 NV9642 User’s Guide Change History Rev. Date Description Approved 24 Nov 09 16114 Initial release D. Cox 6.0.8 05 Nov 10 17286 Updated to conform to SE . Virtual level expand, D. Cox contract buttons added. 20 Nov 14 19357 Reformatted.
  • Page 4 Restriction on Hazardous Substances (RoHs) Grass Valley is in compliance with EU Directive RoHS 2002/95/EC governing the restricted use of certain hazardous substances and materials in products and in our manufacturing processes. Grass Valley has a substantial program in place for RoHS compliance that includes significant investment in our manufacturing process, and a migration of Grass Valley product electronic components and structural materials to RoHS compliance.
  • Page 5 NV9642 User’s Guide General Warnings A warning indicates a possible hazard to personnel which may cause injury or death. Observe the following general warnings when using or working on this equipment: • Heed all warnings on the unit and in the operating instructions. •...

  • Page 7: Table Of Contents

    Table of Contents 1 Preface ..........1 Chapter Structure .
  • Page 8 Table of Contents Selection................. . 36 XY Mode —...
  • Page 9 NV9642 User’s Guide Page Up ................55 Panel Lock .
  • Page 10 Table of Contents 7 Technical Details ........75 Power Specifications .

  • Page 11: Preface

    Preface Chapter 1 is an introduction to the NV9642 User’s Guide. Topics Chapter Structure ............... . . 1 The PDF Document .

  • Page 12: Terms, Conventions And Abbreviations

    Preface Terms, Conventions and Abbreviations Use the ‘First Page’ , ‘Previous Page’ , and ‘Next Page’ , and ‘Last Page’ buttons to go to the first, previous, next, or last page within a PDF file. Note To display the navigation buttons, right-click the Tool Bar area, and check ‘Navigation’ . •...

  • Page 13: Introduction

    Introduction Chapter 2 provides a basic functional description of the NV9642. Topics Summary ................. 3 Panel Organization .

  • Page 14: Panel Organization

    Introduction Panel Organization We use the term “button page” or “page” to mean the set of 34 button functions at any partic- ular level in the tree. Configurers will use ‘Navigate’ buttons to create new button pages (subtrees). During operation, NV9642 users will press a ‘Navigate’...

  • Page 15: Alphanumeric Display

    NV9642 User’s Guide Panels that use multi-destination mode will probably require ‘Page Up’ and ‘Page Down’ buttons. Alphanumeric Display The 4×22 alphanumeric display provides real-time feedback for the operators as they press buttons to execute takes and other operations. The panel functions in two modes: X-Y or multi- destination and the display changes according to the mode: X–Y Dest X–Y Dest...

  • Page 16: Flags

    Introduction Panel Organization In MD mode, the status column represents the sources routed to each of the destinations in the ‘Level/Dest’ column. Again, these are the current sources. In X-Y mode, the display uses its top row to show the selected destination. Therefore, in X-Y mode, the display scrolls 3 lines at a time.

  • Page 17: Modes Of Operation

    NV9642 User’s Guide Modes of Operation The panel operates in either X-Y mode or multi-destination (MD) mode. A single button (XY/MD) can toggle between the modes. A third mode — called “single-bus, ” “single-destination, ” or “button-per-source” mode — can be emulated in either X-Y mode or MD mode. The primary modes of operation are: •...

  • Page 18: Other Nv9642 Functions

    Introduction Other NV9642 Functions Other NV9642 Functions The NV9642 can be configured to perform the following additional functions: • Previous source, free source, “quick” source, and source/destination buttons. • Return to a pre-defined (or default) state. • Hold breakaway levels. •...

  • Page 19: Installation

    Installation Chapter 3 provides installation and connection instructions. Topics Package Contents ............... . . 9 Installation .

  • Page 20: Installation

    Installation Installation Installation Follow these steps to install a NV9642 control panel: 1 Mount, and secure, the panel in the rack. The NV9642 is designed to mount in a 19” rack. Rack-mounting is not a requirement. Place the panel in position in your rack. Attach the panel to the rack frame, using screws appropriate for your rack.

  • Page 21: Initialization

    NV9642 User’s Guide Initialization Before your system controller can communicate with an NV9642, you must give the NV9642 a panel ID. Follow these steps for each NV9642 you are installing: 1 Power up the NV9642. Do not connect its Ethernet cable. (Disconnect it if it is connected.) After a few seconds, the alphanumeric display will show ‘Acquire IP Address’...
  • Page 22 Installation Testing tion exists for that panel and the buttons appropriate for that configuration should light in the colors appropriate for the top-level button page of that configuration. If you continue to see “No Server, ” “Acquiring IP Address, ” or “Locating Network” on button 2, you have a problem.

  • Page 23: Configuration

    Configuration Chapter 4 provides configuration instructions for the NV9642. Topics Summary ................13 Adding a Panel to an NV9000 Configuration .
  • Page 24 Configuration Adding a Panel to an NV9000 Configuration After launching NV9000-SE Utilities, choose ‘Control Panels’ from the Configuration pane in the navigation area. The ‘Control Panels’ configuration page appears: Click ‘Add Control Panel’ at the bottom of the configuration page. The ‘Add Control Panel’ page appears: Choose “NV9642”...
  • Page 25 NV9642 User’s Guide  There are 2 other buttons: ‘Suffix’ and ‘Navigate’ . Pressing either of these buttons creates a button page template, not a panel configuration. See Global Navigation on page 39. Return to the ‘Control Panels’ page to view your new entry. To edit an NV9642 configuration, either double-click its list entry or select the entry with a check in the checkbox and then click ‘Edit Selected Control Panels’: You will then see the panel configuration page for the selected NV9642.

  • Page 26: Nv9642 Panel Configuration Page

    Configuration NV9642 Panel Configuration Page NV9642 Panel Configuration Page This is the default NV9642 panel configuration page in NV9000-SE Utilities: Panel Image Button Definition Section Button Page Table GPIO Defi- nitions Panel Display Options Options Fig. 4-1: NV9642 Configuration Page (Default) Similar pages exist for NV9642 suffix templates and for NV9642 global navigation templates.

  • Page 27: Regions Of The Configuration Page

    NV9642 User’s Guide Regions of the Configuration Page Above the ‘Revert to Saved’ and ‘Save’ buttons (always present) there are 5 main regions: • A graphic representation of the NV9642 panel. On the right are 34 function button images. Click on a button to assign a function to it. In some cases, you can click or double-click certain buttons to execute the button function.

  • Page 28: Configuration Tasks

    Configuration NV9642 Panel Configuration Page For example, if your NV9000 configuration has levels HD, SD, AES12, AES34, AES56, AES78, timecode, and ‘Ctrl’ defined, and you specify that HD, AES12, AES34 are to appear on lines 1, 2, and 3, that will always happen. Then levels SD, AES56, and AES78 will appear on page 2, and ‘timecode’...

  • Page 29: Commitment Buttons

    NV9642 User’s Guide Commitment Buttons Two buttons at the bottom of the configuration page are self-explanatory and present on most configuration pages: • Revert to Saved. Press this button if you want to discard any recent changes you have made. •...
  • Page 30 Configuration Panel Options XY Data Automatic If a machine control (i.e., data) level is involved in a route, the sys- Routing Mode tem makes the route on the control level even if the control port is in use on the source or destination device. It breaks the previous control connection and then makes a new control connection for the route in progress.

  • Page 31: Checkbox Options

    NV9642 User’s Guide Checkbox Options The checkbox options section is just below the panel options section, enclosed in the same region: A check in the box enables the option. Clearing the checkbox disables the option. By default, all the check box options are clear except ‘Src/Dst Immediate Take’ . That particular option is enabled by default.
  • Page 32 Configuration Panel Options • Enable destination protect. Check ‘Enable Destination Protect’ so that any ‘Destination Protect’ button on the panel will function. • Source master default. Makes a control-level source the controlling device (or master device) by default. Otherwise, the destination is the master by default. (The option is specifically for use with NV9000 series machine control routers.)

  • Page 33: Button Definitions

    NV9642 User’s Guide clear, the button sets up the take and the operator must press a ‘Take’ button to complete the take. Button Definitions There are four classes of button functions: • Dedicated functions, such as ‘Default State’ or ‘Chop’ . •...
  • Page 34 Configuration Button Definitions The controls vary according to the button type. Button Type A pull-down menu where you may select a button type. Button Caption Three text boxes in which you can enter three lines of button text up to 8 characters each.

  • Page 35: Button Types

    NV9642 User’s Guide Button Types Note that different subsets of these button types are available when you are defining a global suffix template or a global navigation template. See Global Navigation on page 39. These are the button types available for NV9642 configurations: Type Description Back...
  • Page 36 Configuration Button Definitions Type Description Destination Sets or removes a “lock” on the current destination device. The lock can be Lock removed only by the user that originally set the lock, or by a panel that has “Force Release” enabled. In MD mode, an “L”...
  • Page 37 NV9642 User’s Guide Type Description Name Set The button toggles the panel between its default name set and the “system Toggle name” set. One or the other becomes the active name set. The button definition has no fields to configure. If the default name set is the system name set, the button would be a no-op.
  • Page 38 Configuration Button Definitions Type Description Quick Source A quick source button selects a source and performs an immediate take. When you assign a quick source button, a drop-down menu appears in which you choose a source device. The ‘None’ entry is merely a placeholder. Do not choose ‘None’ . Salvo Executes a salvo.
  • Page 39 NV9642 User’s Guide Type Description Selection Selection buttons have many functions, not the least of which is to give feedback (e.g., source and destination mnemonics) when the operator is performing takes. When the panel is in XY mode, a set of selection buttons presents a set of virtual levels for the selected destination device.
  • Page 40 Configuration Button Definitions Type Description Source Means “source is the master” and makes the source device the master. Other- Master wise, the destination is the master. It applies to machine control routes. The button is a toggle: Press it once to make the source the master (it goes high- tally);...

  • Page 41: Edit Navigation Button' Dialog

    NV9642 User’s Guide ‘Edit Navigation Button’ Dialog During configuration, when you choose ‘Navigate’ for a selected button, NV9000-SE Utilities displays an ‘Edit Navigate Button’ dialog in which you specify navigation button details: Button text Navigation Choices Automatic Fill Options At the top, this dialog presents 3 lines on which you can enter text for the button caption. In this dialog, The 3 lines you enter here are concatenated to form the name of the page in the button page table and might be the button caption, depending on context.

  • Page 42: Automatic Fill Options

    Configuration Button Definitions • Use “auto fill” to create a new button page. NV9000-SE Utilities (SE) creates at least one new button page, filling the page(s) with button functions according to the fill options you specify. Automatic fill has several suboptions: Source buttons Salvo Source category buttons Destination buttons...

  • Page 43: Button Page List

    NV9642 User’s Guide • Quick Source Devices Automatic fill using quick source buttons for source devices is the same as for source devices, except that quick source buttons are used. In the case of manual fill, blank quick source buttons are created. •...
  • Page 44 Configuration Button Page List The button page at the top (or root) of the tree is called “Default. ” Initially, the tree has just the default page, until you add other pages. To delete a page or pages from the tree, select the pages in the button page list, right-click the list, and choose one of the deletion commands from the context menu that appears.

  • Page 45: Tally (Gpio) Window

    NV9642 User’s Guide operation. (The exception is the default page which is always available after reset. It might become unavailable in a configuration that has subpages with no ‘back’ buttons.) Tally (GPIO) Window Below the tree window is the tally section of the configuration page. It has two sections: inputs and outputs.

  • Page 46: Md Mode

    Configuration Selection Buttons selection button is high-tally, the level is selected. If a selection button is low-tally, the level is not selected. If there are more levels than selection buttons, the operator can scroll through the levels using ‘Page Up’ and ‘Page Down’ buttons. The levels list scrolls module the number of selection buttons.

  • Page 47: Md Mode - Hold Mode

    NV9642 User’s Guide MD Mode — Hold Mode In hold mode, selection buttons are not mutually exclusive. To perform MD takes, the operator selects one or more MD devices. All of them turn on (high-tally). The operator then selects a source (which becomes preset for all the selected devices).

  • Page 48: How To Configure Selection Buttons

    Configuration Single-Destination Mode How to Configure Selection Buttons Follow these steps to assign virtual levels and MD devices to selection buttons. 1 Decide how many selection buttons you want on the button page. We strongly recommend 8 selection buttons. Create those selection buttons by clicking on the buttons and choosing ‘Selection’...

  • Page 49: Global Navigation

    NV9642 User’s Guide Global Navigation NV9000-SE Utilities supports what are known as “global navigation” pages for NV9642 control panels. Global navigation pages are templates — patterns — that may be used and reused in the creation of NV9640 configurations. There are two types of global navigation pages: ‘Suffix’ and ‘Navigate’ . A navigate template may define a single button page or an entire subtree of pages.

  • Page 50: Referencing A Suffix Template

    Configuration Global Navigation Referencing a Suffix Template Suffix pages can be accessed through ‘Category’ buttons. When you create a ‘Category’ button, the button type region displays a checkbox option: ‘Use global suffix page to select devices’: Suffix Suffix checkbox template selection When you check the option, an addition ‘Suffix Page’...

  • Page 51: Referencing A Navigate Template

    NV9642 User’s Guide Referencing a Navigate Template Navigate pages can be accessed through ‘Global Navigate’ buttons. When you create a ‘Global Navigate’ button, the button definition has a ‘Navigation Btn’ field: Choose a navigate template in that field. The global navigation page and any of its subpages appears in the panel configuration’s button page list: Global navigation page(s) ...

  • Page 52: Template Changes

    Configuration Global Navigation numeral or a suffix on the button page. When the operator presses a numeral or a suffix, the numeral or suffix is appended to the mnemonic of the device being identified.  It is an NV9000-SE Utilities feature that certain numerals become disabled if there is no device index in the category that contains that numeral.

  • Page 53: Operation

    Operation Chapter 5 provides operating instructions for the NV9642 control panel. Topics Summary ................43 Operating Concepts .

  • Page 54: Modes Of Operation

    Operation Summary At any particular time, some of the buttons are enabled or disabled. Some are high-tally; some are low-tally; and some might be off (undefined). The buttons have different colors, the choices of which depend on the configurer’s intentions. ...

  • Page 55: Button Legends

    NV9642 User’s Guide Button Legends There are many different button function types (about 31) and the legend that appears on any button varies with the type and depends on the configurer’s intentions. Button legends have 3 lines of 8 characters. One or more lines of a button legend can be blank. Buttons are also color-coded.

  • Page 56: Level Mapping

    Operation Summary In X-Y mode, the selection buttons represent levels. Each displays 3 lines of text: –––––––– –––––––– CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 CAM--1 –––––––– –––––––– VTR--2 VTR--2 VTR--2 VTR--2 VTR--2 VTR--2 VTR--2 VTR--2 VTR--2 VTR--2 VTR--2...

  • Page 57: Lists

    NV9642 User’s Guide In this example, the displays shows that two sources, CAM--4 and CAM--5, were preset to 2 desti- nations, VTR--2 and VTR--3, respectively: The preset sources are not visible on the display, but are visible on the selection buttons when the MD CAM––1 CAM––1 VTR––1...

  • Page 58: Breakaway

    Operation Operating Concepts A source can be routed to a destination if it has the same set of levels, i.e., it belongs to the same named level set. A source can be routed to a destination in a different level set if the NV9000 configuration has the appropriate level mapping.

  • Page 59: Multi-Destination Mode

    NV9642 User’s Guide Multi-Destination Mode In multi-destination mode, hold mode allows you to select more than one MD destination at a time. In addition, MD selections are retained after a take. Category Selection In the NV9000 system, devices are assigned to categories, where the devices within the catego- ries are either numbered or identified by alphanumeric suffixes.

  • Page 60: Back

    Operation Operating Concepts page. ” See Global Navigation on page 39. A device list, if it is long, spans more than one but- ton page. At present, there are 35 button types, not including “undefined” which is not a true button type: Back Hold Source is Master...

  • Page 61: Chop

    NV9642 User’s Guide The button text is normally the category name, but the configurer can give it any text. Category names tend to be short. It is a common convention that buttons for source categories and devices are green and buttons for destination categories and devices are amber.

  • Page 62: Destination

    Operation Operating Concepts Destination This button selects a destination. A destination button can occur on any page, but destination buttons often appear in destina- tion lists. Destination lists can occur either (1) in automatically configured, but static, pages or (2) as a result of pressing a destination category button, in which case, the destinations buttons are generated dynamically.

  • Page 63: Free Source

    NV9642 User’s Guide The ‘Destination Protect’ button text is normally “Dest Protect” and when a selected MD desti- nation is protected, the button legend becomes “Dest Unprotect. ” MD Mode In MD mode, a protected destination has a “P” next to it when it appears in the display. When you select a protected MD destination with a button, the ‘Destination Protect’...

  • Page 64: Information

    Operation Operating Concepts is still on when you press ‘Take’ , the selected destinations remain selected and the display reflects the selected destinations. The buttons for the selected destinations remain high-tally. Without hold enabled, the panel has no destinations selected after an MD take and the buttons for the selected destinations go low-tally.

  • Page 65: Name Set Toggle

    NV9642 User’s Guide Name Set Toggle An ‘Name Set Toggle’ button toggles the panel between its default name set and the “system name” set. Whichever name set you select becomes the “active” name set.  ‘Name Set Toggle’ buttons are disabled while a category selection is in progress. ...

  • Page 66: Panel Lock

    Operation Operating Concepts Panel Lock A panel lock button prevents changes to the panel settings, especially router crosspoints. When the panel is locked, the button array becomes blank except for the ‘Panel Lock’ button which becomes high-tally red. The button is a toggle: press the ‘Panel Lock’ button to lock the panel. Press it again to unlock the panel.

  • Page 67: Save Preset

    NV9642 User’s Guide Save Preset This button is a toggle: it enables or disables “save preset” mode. When this function is enabled (and the button is high tally), whatever is on preset is retained on preset after a take. When the function is disabled (its button is low tally), whatever is on preset is discarded after a take.

  • Page 68: Source

    Operation Operating Concepts If the configurer has turned on the option, you may redefine any MD destination. To do so is simple: (1) select an MD destination on a selection button, (2) choose a destination that is not on a selection button. You might have to navigate or scroll through a destination list to choose one. Source A source button selects a source.

  • Page 69: Undefined

    NV9642 User’s Guide Undefined An undefined button cannot be used and appears dark (unlit) on the panel. The term “unde- fined button” has meaning primarily to the configurer and not the operator. Virtual Level Expander In X-Y mode, this button causes the alphanumeric display to show virtual levels at the lowest level of grouping (with the most detail).

  • Page 70: Takes

    Operation Operating Concepts Destination lockNo one can route to the destination. Destination protectNo one but the owner can route to the destination. ReleaseTo remove a lock or protect. Some control panels can lock or protect both sources and destinations. However, The NV9642 provides locks and protects for destinations only.

  • Page 71: Name Sets

    NV9642 User’s Guide Name Sets NV9000-SE Utilities allows configurers to define multiple name sets. Each name set contains aliases (alternate names) for any and all devices in the NV9000 system. The aliases can appear in the displays of your panel. Further, your panel can have a ‘Name Set Toggle’...

  • Page 72: Removing Broadcast Routes

    Operation Operating Concepts Implicit in the ‘Broadcast’ button is the “source is master” mode. It is not necessary to press ‘Source is Master’ repeatedly. The reason you must press ‘Source is Master’ the first time is that “broadcast mode” is not yet active. Removing Broadcast Routes To cancel a route, route the source to another destination normally.

  • Page 73: Chop

    NV9642 User’s Guide If neither of the control ports for the source or destination are in use, the take occurs naturally without any further action required. Note that the ports will become “in use” after the take you are performing. Follow these steps to take the data level as a breakaway: 1 Select a destination.

  • Page 74: Software Versions

    Operation Menu Mode The menu has 4 menu choices and an exit button: SOFTWARE SOFTWARE VERSIONS VERSIONS USER USER PANEL PANEL CONTROL CONTROL EXIT EXIT • • • Press ‘Exit’ when you want to leave the menu and return to the previous button page. Software Versions Press the ‘Software Versions’...

  • Page 75: Lcd Control

    NV9642 User’s Guide If the ‘Panel ID’ button is high-tally, you may change the panel ID. Normally, only your system administrator would do that. Press ‘Exit’ on the right to return to the menu. LCD Control Press the ‘LCD Control’ button to view and change LCD brightness. When you do, the current LCD button state appears on the 14 top left buttons: LCD HI LCD HI...
  • Page 76 Operation Setup Mode In addition, the display shows the panel ID: ACQUIRE IP ADDRESS ACQUIRE IP ADDRESS NV9642 NV9642 PANEL ID: 23 PANEL ID: 23 In this illustration, the panel ID was already set to 23. The “Acquire IP Address” is a status message during initialization.
  • Page 77 NV9642 User’s Guide Each time you press the button, the panel illuminates all its LCD buttons in a single color, changing the color each time you press the button. Keep pressing the button until all 7 col- ors (high and low tally) have been displayed and ‘Button Number’ appears on the display. Press any button.
  • Page 78 Operation Setup Mode...

  • Page 79: Gpio

    GPIO Chapter 6 provides information about the tally (GPIO) interface. Topics The Interface ................69 GPIO Configuration Concepts .

  • Page 80: Output

    GPIO GPIO Configuration Concepts When the input transitions off or transitions on, the NV9642 notifies the router control system, which carries out the task defined for the input (if a task has been configured). During contact closure, a current of 1.2mA flows. A maximum of 48VDC can be applied to the tally input for less than 5 seconds without failure.

  • Page 81: Configuring Outputs

    NV9642 User’s Guide Click on a button under ‘Outputs’ to configure one of the 4 tally outputs. Click on a button under ‘Inputs’ to configure one of the 8 tally inputs.  There are no actual GPIO buttons on the NV9642 control panel. Configuring Outputs Clicking an output button (one of 4) displays a “Relay Rule”...
  • Page 82 GPIO Configuring Outputs The relay will turn on when the entire expression is true. That is, when the switch occurs and either of the inputs (3 or 8) transitions from off to on. (To allow a relay to switch when an input transitions from on to off, precede the input term by “NOT.

  • Page 83: Configuring Inputs

    NV9642 User’s Guide Configuring Inputs Clicking an input button (one of 8) displays the GPI input dialog: An event is signalled when a transition occurs on the input from on to off or from off to on. You can configure the NV9642 to recognize either occurrence on any of the 8 inputs, and specify one of 4 behaviors for each event or both: 1 Execute a salvo.
  • Page 84 GPIO Configuring Inputs...

  • Page 85: Technical Details

    Technical Details Chapter 7 provides electrical and mechanical specifications for the NV9642. Topics Power Specifications ..............75 NV9642 Specifications .

  • Page 86: Nv9642 Specifications

    Technical Details NV9642 Specifications 2.39 [60.7] 5.24 [133.0] Indicator LED 1.62 [41.0] AC Input DC Output Fig. 7-1: The power output has Molex 4-pin plug. See Power Cord Retention on page 82. NV9642 Specifications NV9642 Physical Specifications Specification Detail Dimensions Height: 1.72 in (43.7 mm), fits EIA 2 RU (1.75 in or 44.5 mm), Width: 19.0 in (482.6 mm).

  • Page 87: Environmental Specifications

    NV9642 User’s Guide Environmental Specifications NV9642 Environmental Specifications Specification Detail Operating temperature 0–40 °C, ambient. Relative humidity 0 to 90%, non-condensing. Cooling No fan required. Defaults Initial Panel State Multi-destination mode or X-Y mode, selectable. Destination: the configured default. Buttons: high-tally is maximum brightness; low-tally is low brightness. Configuration Page The initial button page for a new NV9642 configuration is empty.
  • Page 88 Technical Details Drawings Fig. 7-2: Front and Top Views of the NV9642...
  • Page 89 NV9642 User’s Guide Fig. 7-3: Rear and Top Views of the NV9642...
  • Page 90 Technical Details Drawings...

  • Page 91: Misc. Topics

    Misc. Topics Chapter 8 provides the following: Topics LCD Buttons ................81 Power Cord Retention .

  • Page 92: Power Cord Retention

    Misc. Topics Power Cord Retention Power Cord Retention Use the supplied retention strap to keep the AC power cord firmly connected to the power supply. Follow these steps to use the strap: 1 Firmly insert the AC power cord into the power supply. Examine the last figure in this section to see how the strap should be applied.

  • Page 93: Ordering Information

    NV9642 User’s Guide Ordering Information These are the NV9642 components: PS0001 12V power supply, 4-pin Molex connector, with cord, and cord retention strap. NV9642 NV9000 control panel. 34 button, 1RU, XY/MD, hierarchical. WC0053 Optional breakout cable for the tally interface...
  • Page 94 Misc. Topics Ordering Information...

  • Page 95: Glossary

    Glossary AES/EBU (Audio Engineering Society/European Broadcasting Union). AES and EBU are standards organizations. Breakaway A condition where a destination has multiple sources on different levels. Category A category represents a set of devices. (The concept of categories exists to make it easier to select devices at a control panel.) A category can contain sources, destinations, or devices that are both sources and destinations.
  • Page 96 Glossary A device can be both a source and destination. An example of such a device is a VTR. System The system administrator is the person responsible for installing, configuring, and maintaining a administrator router control system. Tally (1) High or low button illumination. (2) Tally interface to be defined.

  • Page 97: Index

    Index Button add control panel ....... .14 back ..4, 18, 24–25, 32–33, 47, 49–50, 52–53, 55 Acquiring IP address (message) .
  • Page 98 Index X-Y display ......30, 45, 52, 59 7, Technical Details .......75 XY/MD mode .
  • Page 99 NV9642 User’s Guide NV9642 configuration page ....16, 77 Electrical specifications page ..........34 power supply .
  • Page 100 Index GPIO ........10, 13, 17, 77 Jump back after take (option) .
  • Page 101 NV9642 User’s Guide MD (abbreviation for multi-destination) NV9000 router control system ......2 MD (multi-destination) NV9000-SE Utilities ..2, 6, 9–13, 16, 31–32, 42, 44, 56 MD destination .
  • Page 102 Index Panel initial state ........77 IP address .
  • Page 103 NV9642 User’s Guide Source outputs ....... 13, 69–70, 77 categories ........33, 51 Technical support .
  • Page 104 Index...

  • Page 105: Contact Us

    Contact Us Grass Valley Technical Support For technical assistance, please contact the Grass Valley Technical Support center nearest you: Americas Asia Office hours: 9:00 a.m. – 9:00 p.m. (EST) Office hours: 9:30 a.m. – 6:00 p.m. (GMT+8) Telephone: +1-800-547-8949 Telephone: +852 2539 6987 +1 530 478 4148 Fax:...
