YOODA LINEO Series Quick Start Manual

www.sukcesgroup.pl
In order to fully explore available functions of LINEO series please take a moment and read this manual before using the device.
LINEO transmitters are compatible with all YOODA brand devices.

1. General information

Radio receiver range is a variable value and can differ from declared values depending on conditions in which device
operates. Possible sources of changes in range are building construction, interference caused by other radio transmitters
etc.

2. Detailed description

Single-channel transmitter
(front)
LINEO_1R | LINEO_15R
UP button
STOP button
DOWN button
15-channel transmitter
(front)
1. Control:
can control single motor, or a group
of up to 20 motors on each channel
2. Range:
200 meters outdoor,
35 meters indoor
3. Battery:
CR2450
4. Power supply:
3 V
5. Dimensions:
130 x 45 x 17 mm
6. Transmitting power::
10 mW
7. Operating temperature:
from 0°C to 50°C
8. Protection degree:
IP 30
Illustrations (from the top):
Fig. 1. Single-channel LINEO remote control, white (LINEO_1R)
Fig. 2. 15-channel LINEO remote control, white (LINEO_15R)
LCD display
UP button
STOP button
DOWN button
CHANNEL + button
CHANNEL - button
1
UP
P2
P2
programming button
CR 2450
battery
3V
M
Single or 15-channel transmitter
(back)
P2
