8 Right-hand direction indicator (switches itself off
automatically after 30 seconds)
9 Drive lever

3.6.1 Status Display

The ON/OFF diode is used as a fault display (status
display). It will flash if there is a problem with the
scooter. The number of flashes indicates the type
of error. Refer to 11.1.2 Error codes and diagnostic
codes, page 54.

3.6.2 Battery charge display

All diodes illuminate:
Only red and yellow diodes
illuminate:
Only red LEDs
illuminate/blink, electronic
beeps 3x:
22
Maximum driving range
Reduced driving range.
Recharge the batteries at
the end of your journey.
Battery reserve = severely
restricted driving range.
Recharge batteries
immediately!
Overdischarge protection: after a certain drive time
on reserve battery power the electronics system
switches the drive off automatically and brings the
Scooter to a standstill. If you do not drive your
Scooter for a while the batteries will "recuperate"
and allow a further, but short, journey. However,
after a very brief journey the red diodes will
illuminate again and the electronic system will beep
three times. This procedure leads to battery damage
and should be avoided if possible!
