iaq+
Indoor Air Quality Monitoring System
CM000SP043
User manual
NO POWER
& SIGNAL
CABLES
TOGETHER
READ CAREFULLY IN THE TEXT!
H i g h
E f f i c i e n c y
S o l u t i o n s

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the iaq+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Carel iaq+

  • Page 1 iaq+ Indoor Air Quality Monitoring System CM000SP043 User manual NO POWER & SIGNAL CABLES TOGETHER READ CAREFULLY IN THE TEXT! H i g h E f f i c i e n c y S o l u t i o n s...
  • Page 3 Without excluding proper compliance with further warnings present in the incorrect disposal of such may have negative effects on human health and manual, it is stressed that in any case it is necessary, for each CAREL product: on the environment;...
  • Page 5: Table Of Contents

    Content 1. INTRODUCTION Main Features ......................7 Components and accessories ................7 2. INSTALLATION Mounting the Unit ....................8 Input/Output Configuration ................8 3. SET UP Single Zone ........................9 Multi-Zone ........................9 Central Monitoring ....................9 Software Update ......................9 4. WEB INTERFACE Home Screen ......................10 Menu Icon .........................10 Assigning a name to the zone ...............10 Alarms..........................10 PGD Display Emulator ..................11...
  • Page 7: Introduction

    1. INTRODUCTION iaq+ Monitoring System is the CAREL solution for monitoring Main Features Single 'plug and play' box for monitoring single zone and management of indoor air quality. The iaq+ monitoring Standard sensors are temperature, humidity, VOC and CO2 system allows continuous monitoring of temperature, Hardware 1 c.pCO.mini...
  • Page 8: Installation

    2. INSTALLATION 2.2 Input/Output Configuration The iaq+ hardware is delivered in a self-contained box which requires no configuration. By default, the system is The default is to use a RS485 sensor. For analog inputs, the designed to use sensors that are pre-wired. default configuration are as listed below: 2.1 Mounting the Unit Universal...
  • Page 9: Set Up

    Path Settings --> USB Settings --> PCconnection. Local trending and monitoring of several iaq+ units can be performed using a CAREL boss mini. The boss system can ( See c.pCO manual code +0300057EN.) be scaled up from monitoring 1 device up to 300 devices.
  • Page 10: Web Interface

    4. WEB INTERFACE 4.2 Menu Icon A PC can be connected to the IAQ monitor by Ethernet port and a browser can be used to access all the information. To access the IAQ+ web interface menu, select the gear The IAQ monitor defaults to address 192.168.1.77. Adjust icon at the upper left corner.
  • Page 11: Pgd Display Emulator

    • Here you will find the user interface, which you will 4.5 PGD Display Emulator need to use the on-screen buttons to navigate. Press the “PROGRAM” button: If you need to change the IP of the iaq+ to attach to a building network, use the PGD1 display emulator.
  • Page 12: Trend Icon

    4.6 Trend Icon At the top menu bar, select the TREND icon to access. All sensors are logged at a 1 minute rate and stored in monthly logs the current months log can be reviewed on the this screen. FTP can be used to retrieve previous months trends.
  • Page 13: Web Pgd1 Layout

    5. WEB PGD1 LAYOUT 5.1 Quick and Main Menu Overview 5.2 Quick Menus 5.2.2 SET QUICK MENU Quick menus are accessed from the main display by pressing the UP or DOWN arrow and ENTER to select. The SET quick menu item gives access to high/low alarms for each sensor.
  • Page 14: Main Menu

    5.2.3 INFO QUICK MENU The INFO quick menu displays the software version, board information, some application data and the last time the power was off. 5.4 Alarm Logs The ALARM log displays the last 200 alarms. Record is the current displayed alarm (1-200). The second line shows the alarm ID number and the date and time it occured.
  • Page 15 Import/Export: First screen import/export parameters, so if you have several units you can configure one, export to USB and then import to the other units. The next two screens allow you to export the alarm log and the data log. Initialization: First screen allows for the alarm log to be cleared.
  • Page 16: Communications Sub Menu

    5.6 Communications Sub Menu +03U0095EN Rel 1.1 20201022...
  • Page 17 “license not found” and the protocol will not work. DisplayPort default operations is to communicate to CAREL displays. It will default to this when the protocol is set to “NONE”. Error will show "NotUsed", "Offline" or "Online".
  • Page 18 +03U0095EN Rel 1.1 20201022...
  • Page 19: Technical Specifications

    6. TECHNICAL SPECIFICATIONS Physical Specifications Dimensions in(mm) 4.63" (117.5) L x 7.45" (120) W x 7.09 " (180) H Packaged 10" (254) L x 10" (254) W x 10" (254) H Environmental conditions Operating conditions Operating conditions 0-+50C , 0– 95 rH (without dewing formation), IP30 rating Electrical Specifications Operating power supply voltage 24V 36W 1500mA...
  • Page 20 Agenzia / Agency: CAREL INDUSTRIES S.p.A. Via dell’Industria, 11 - 35020 Brugine - Padova (Italy) Tel. (+39) 049.9716611 - Fax (+39) 049.9716600 e-mail: carel@carel.com - www.carel.com...
