- Page 1 CV610-U2 Silver/Black CV610-UB All Black Full HD USB 2.0 PTZ Camera Operating Instructions Version V3.6...
-
Page 2: Table Of Contents
CV610-U2 / CV610-UB Operation Manual Accessories IMPORTANT SAFETY INSTRUCTIONS: • Remove lens cover before plugging camera into power source. Table of Contents • Before starting operation, please fully read and follow all instructions in the manual. For your safety, always keep this manual with the camera for reference. -
Page 3: Quick Start
SW-6 Instruction The Marshall CV610-U2 acts as a UVC command slave to Teleconference, U.C. or Video Capture Software programs Working mode that use it as a USB capture device. Once selected as an available camera, these software platforms send commands... -
Page 4: Camera Interface
CV610-U2 / CV610-UB Operation Manual IR Remote Controller CAMERA INTERFACE IR REMOTE CONTROLLER LED Function Instruction Press any button and shows in red color: Current selection is to control CAM1; Press any button and shows in green color: Current selection is to control CAM2;... -
Page 5: 3. In The Sub Menu, Once Again Press The Up/Down Navigate Buttons To Scroll And Select, Use Left/Right
CV610-U2 / CV610-UB Operation Manual IR Remote Controller / OSD menu EXP MODE AUTO/MANUAL/IRIS/SHUT/BRI. CV610-U2 OSD MENU EXPLAINED Shutter time: 1/1~1/10K SHUT TIME (Valid when EXP MODE set to MANUAL or SHUT) Iris value: 0-13 IRIS (Valid when EXP MODE set to MANUAL or IRIS) Gain value: 0dB~15dB 1. -
Page 6: Visca In (Rs232) Port
CV610-U2 / CV610-UB Operation Manual VISCA Protocol 4. All Button Sending Mode: long press (3seconds) the Menu+ number “3” button simultaneously, the remote will Error Messages enter all button sending mode. 5. Similar operation for the TV control mode learning. - Page 7 CV610-U2 / CV610-UB Operation Manual VISCA Protocol Part 2 - Camera Control Command Command Funnation Command Packet Note Command Funnation Command Packet Note Reset 8x 01 04 04 00 FF Manual Control of B Gain CAM_3D Direct 8x 01 04 54 0p FF...
- Page 8 CV610-U2 / CV610-UB Operation Manual VISCA Protocol VISCA PAN / TILT ABSOLUTE POSITION VALUE Pan Angle VISCA Value Tilt Angle VISCA Value -170 0xF670 0xFE50 y0 50 00 FF Auto -135 0xF868 0x0000 y0 50 01 FF Indoor mode 0xFAF0...
-
Page 9: Ir Transfer (Ir Pass)
CV610-U2 / CV610-UB Operation Manual IR Transfer (IR PASS) IR TRANSFER (IR PASS) 60/30mode 50/25mode 1/10000 1/10000 close 1. Currently the camera support NEC code format. For customization with other codes, please contact us. 1/6000 1/6000 sfer function via sending COM command. -
Page 10: Wall Mount Installation
1. Secure the CV610-U2-WM to the wall with 4 M4 screws (included). M4 screws 2. Disconnect all cables from the camera. Align the CV610-U2 camera’s ¼-20UNC tripod screw hole with the wall mount screw hole. Use the ¼-20UNC screw (included) to secure the camera onto the wall mount.
