R32 (Hi-Eff) 12,000 - 42,000 Btu/h
R32 (STD.) 18,000 - 60,000 Btu/h
R410A (STD.) 18,000 - 60,000 Btu/h
MCC Series 50 Hz
R32
Hi-Eff Models
Cooling Only
MCCE 12 2B5
MCCE 18 2B5
MCCE 24 2B5
MCCE 30 2B5
MCCE 36 2B5
MCCE 42 2B5
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified pers on could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
May 2020 (Rev.F)
R32
STD. Models
Cooling Only
MCCE 18 2B
MCCE 24 2B
MCCE 30 2B
MCCE 36 2B
MCCE 42 2B
MCCE 48 2B
MCCE 60 2B
SAFETY WARNING
MCC-SVU01A
Confidential and proprietary Trane information
R410A
STD. Models
Cooling Only
MCCA 18 2B
MCCA 24 2B
MCCA 30 2B
MCCA 36 2B
MCCA 42 2B
MCCA 48 2B
MCCA 60 2B
R410A
R32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CASSETTE MCCE 12 2B5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trane CASSETTE MCCE 12 2B5

Summary of Contents for Trane CASSETTE MCCE 12 2B5

  • Page 1 Improperly installed, adjusted or altered equipment by an unqualified pers on could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are attached to the equipment. MCC-SVU01A May 2020 (Rev.F) Confidential and proprietary Trane information...
  • Page 2 MCC-SVU01A...
  • Page 3 MCC-SVU01A...
  • Page 4 MCC-SVU01A...
  • Page 5 MCC-SVU01A...
  • Page 6 MCC-SVU01A...
  • Page 7 ON/OFF : MODE : • • • • • • MCC-SVU01A...
  • Page 8 FAN : LIGHT: LOCK : TIMER : ELECTRIC HEATING : TURBO : ECO : C(77 SLEEP : MCC-SVU01A...
  • Page 9 • • • • • • 40°C • • • • • • • • • • • MCC-SVU01A...
  • Page 10 • • • • • • • • • • • MCC-SVU01A...
  • Page 11 • • • • • • • MCC-SVU01A...
  • Page 12 • • • • • • • • • • • • • • • • MCC-SVU01A...
  • Page 13 • • • • • • • • • • • • • MCC-SVU01A...
  • Page 14 Improperly installed, adjusted or altered equipment by an unqualified pers on could result in death or serious injury. When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are attached to the equipment. MCC-SVU01A May 2020 (Rev.F) Confidential and proprietary Trane information...

  • Page 15: General Information

    (including electrical data) to insure The Trane Company will not this manual. the proper unit was shipped. assume any responsibility for unit For installing the unit to operate...

  • Page 16: Table Of Contents

    Contents General Information Safety Precaution System Appearance Control Operation Maintenance System Operation Commonly found in operated but not the problem When you think that trouble has occurred Troubleshooting MCC-SVU01A...

  • Page 17: Safety Precaution

    System Precautions Please read and follow the instructions and Refrigerant R32 is environmentally friendly. warnings in the manual carefully before High cooling efficiency and ignite at low rates. installation or mantenance air conditioner. WARNING WARNING This symbol indicates the possibility of death or serious injury. Be sure to use the part provided or specified parts for the installation work.

  • Page 18: System Appearance

    System Appearance Indoor Unit Water Pump (Built-in) Drain Pipe Front Panel Air Outlet Return Air Air Filter (Inside) Air Outlet Display Lights High Pressure Remote Control Copper Tube Low Pressure Remote Control Holder Copper Tube Connection Wire between Indoor Unit & Outdoor Unit Refrigerant Tube Air Inlet Drain Pipe...

  • Page 19: Control Operation

    Control Operation Infrared Remote Control Instructions of remote controller Turbo “ON/OFF” Turbo not able for MCC model Open or close the air-conditioner Temperature addition increase the setting temperature. Automatically setting 26°C in cooling or heating mode. Mode Select modes, including automatic, cooling, dehumidification, fan and heating mode.
  • Page 20 Control Operation The icon meaning of remote controller Button function of remote controller ON/OFF : Press this key to switches by “ON,OFF,ON” circularly. Mode : 1. When pressing this key, the remote controller switches by “automatic, cooling, dehumidification, fan, heating, automatic”...
  • Page 21 Control Operation Button function of remote controller Light 1. When the first power on, the remote controller is set This button has no response function. to the automatic wind speed by default. In dehumi- Lock dification mode, the wind speed is fixed to low wind There is no lock by default.

  • Page 22: Maintenance

    Maintenance Replacing Air Purifying filter Information (Option) Airflow volume is reduced when Recommend once every three an air purifying filter have been months. installed. PULL Cleaning the Air Filters Before inspection and maintenance • Swing up the grille until the latches of the unit, always set the main click into the positions.

  • Page 23: System Operation

    System Operation Suggestion Caution • • The temperature should not be set lower than what Check electrical system (voltage and frequency). you need. This would result to increse energy lost. Use the proper power supply indicated on the unit to operate the air conditioner and only fuses with •...

  • Page 24: Commonly Found In Operated But Not The Problem

    Commonly found in operated but not the problem The following cases are not abnormal problems and you may just continue using it. Case Explanation • Mist is discharged from the air The cool air from the unit rapidly cools moisture in the air inside the outlet of the indoor unit room, and it turns into mist.

  • Page 25: When You Think That Trouble Has Occurred

    When you think that trouble has occurred Symptom Explanation & Check points. • The room cannot be cooled Is the temperature setting appropriate? sufficiently. • Are the airflow rate and the air direction set appropriate? • Are the air filters clean? •...

  • Page 26: Troubleshooting

    Troubleshooting Check the following before contact the service man. You may find the solution to your problems. After checking, if it still does not operate, please contact your local dealer. Problem Causes • No operation Check if electrical wire is damaged & check if breaker switch if still ON. •...
  • Page 27 Note MCC-SVU01A...
  • Page 28 For more information, please visit trane.com or tranetechnologies.com. Trane has a policy of continuous product and product data improvement and reserves the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
