Trane NEW STYLUS MCX Series Owner's Manual
1-5 tons convertible type 50/60 hz
Hide thumbs
Also See for NEW STYLUS MCX Series:
- Installation manual (24 pages) ,
- Owner's manual (16 pages)
Advertisement
SVU-MCXA_GB-EX (R410A).indd
Owner Manual
NEW STYLUS
Split System, 1-5 Tons
Convertible Type
MCX Series 50/60 Hz
50 Hz Models
Cooling Only
MCXA 12 GB
MCXA 18 GB
MCXA 24 GB
MCXA 30 GB
MCXA 36 GB
MCXB 42 GB
MCXB 48 GB
MCXB 60 GB
60 Hz Models
Cooling Only
MCXA 12 G1
MCXA 18 G1
MCXA 24 G1
MCXA 30 G1
MCXA 36 G1
MCXB 42 G1
MCXB 48 G1
MCXB 60 G1
November 2017
1
R410A
TM
50 Hz Models
Cooling/Heating
MCXA 12 GBE
MCXA 18 GBF
MCXA 24 GBB
MCXA 30 GBH
MCXA 36 GBJ
MCXB 42 GBJ
MCXB 48 GBK
MCXB 60 GBL
60 Hz Models
Cooling/Heating
MCXA 12 G1E
MCXA 18 G1F
MCXA 24 G1B
MCXA 30 G1H
MCXA 36 G1J
MCXB 42 G1J
MCXB 48 G1K
690825030001
MCXB 60 G1L
SVU-MCXA_GB-EX (R410A)
21/11/2017, 11:26 AM
Rev.A
Advertisement
Table of Contents
Related Manuals for Trane NEW STYLUS MCX Series
Summary of Contents for Trane NEW STYLUS MCX Series
- Page 1 R410A Owner Manual NEW STYLUS Split System, 1-5 Tons Convertible Type MCX Series 50/60 Hz 50 Hz Models 50 Hz Models Cooling Only Cooling/Heating MCXA 12 GB MCXA 12 GBE MCXA 18 GB MCXA 18 GBF MCXA 24 GB MCXA 24 GBB MCXA 30 GB MCXA 30 GBH MCXA 36 GB...
-
Page 2: General Information
About this Manual note, and send a registered letter of and liabilities by The Trane Company. Cautions appear at appropriate protest to the last carrier of the Important places in this Instruction Manual. - Page 3 Contents Wireless Remote Control SVU-MCXA_GB-EX (R410A) SVU-MCXA_GB-EX (R410A).indd 21/11/2017, 11:26 AM...
-
Page 4: Control Operation
Control Operation Infrared Remote Control Unit Display and One-touch Control Switch Display Panel Cooling Only Cooling/Heating Four lamps on the unit show Four lamps on the unit show operating status. operating status. 1. FAN Lamp 1. FAN Lamp This lamp lights when the fan is This lamp lights when the fan is operating. -
Page 5: Wireless Remote Control
Wireless Remote Control Infrared Remote Control • Do not use rechargeable (Ni-Cd) batteries, because such batteries may differ from standard dry cell batteries Name and function of buttons in shapes, dimensions, or performance. • Take out all batteries if you are not going 1. - Page 6 Wireless Remote Control 4. Transmission Indicator COOL Mode - Press FAN SPEED button to select the The transmission indicator lights when - Press Mode button to select the desired fan speed level and the display remote control transmits signal to the operation mode.
- Page 7 Wireless Remote Control • User can confirm CLOCK setting during CLOCK setting and return to ON/OFF • In case of power failure, OFF TIMER will CLOCK setting process by pressing TIMER. be automatically cancelled as there is SEND button. • In case of power failure, ON TIMER will no electricity in the air-conditioner;...
- Page 8 Wireless Remote Control Note: - To cancel SLEEP mode, press SLEEP - To cancel ECONO mode, press ECONO mode button again. or MODE button again. • SWEEP function will be cancelled in case LOUVER is selected. ECONO MODE (COOLING) Temperature COOL MODE The unit will operate at low fan speed and raise temperature by 1ºC FRONT BLADE Function...
- Page 9 Digital Wired Control 1. CLOCK Note: Name and function of buttons Displays present time. • In FAN mode, the LCD display will not 2. ON TIMER show set temperature and cannot 1. Infrared Signal Receiver (op- Display ON TIMER when ON TIMER adjust set temperature, SLEEP, tional) is set.
- Page 10 Digital Wired Control HEAT Mode - Press either button to set the • In case of power failure, ON TIMER will - Press Mode button to select the clock to the present minute. be automatically cancelled as there is operation mode. - Press MENU button again to confirm no electricity in the air-conditioner.
- Page 11 Digital Wired Control Note: - After one hour operation of SLEEP - The air-conditioner will accelerate mode, the unit will automatically reduce capacity up totally 20 minutes or until • ECONO mode operates only in COOL set temperature by 0.5ºC. room temperature is lower than 18ºC.
-
Page 12: System Operation
• Temperature setting is adjusted Trane dealer. control will automatically resume back and forth. its operation with the same setting • ON/OFF switch is turned ON... -
Page 13: Safety Precautions
Since the fan revolves at high speed, If you have any questions or it is very dangerous. Be especially problems with your air conditioning careful with children. system, please consult Trane dealer or The Trane Company. SVU-MCXA_GB-EX (R410A) SVU-MCXA_GB-EX (R410A).indd 21/11/2017, 11:27 AM... -
Page 14: Maintenance
Maintenance Regular Maintenance 2. Cleaning the front panel 1.2 How to clean the air filter Be sure to disconnect the power Do not pour water directly on the Wash away dust from the air before inspection or maintenance of front panel to clean it. Dust or filter with clean water or air conditioner. -
Page 15: Troubleshooting
Troubleshooting Before calling for service, please Cooling is insufficient: check the following. - Check whether the air filter is clogged. Clean it. The air conditioner does not - Check whether the thermostat operate at all: setting is too high. Set the - Check if the control ON/OFF thermostat to lower temperature. - Page 16 Stocking Location: Bangkok, Thailand 999/1 Mu 9, Bangna-Trad K.M. 19 Road Bangchalong, Bangplee Trane has a policy of continuous product and product data improvement and reserves the right to change Samutprakarn 10540 design and specifications without notice. http://www.tranethailand.com A Business of American Standard Company SVU-MCXA_GB-EX (R410A).indd...
